Bobcat Fault Codes Explained
Your Bobcat skid steer is sitting in the yard with an error code on the display and a job to finish by end of day. You know something is wrong — the machine tells you that much. What it doesn't tell you, at least not yet, is whether you're dealing with a genuine component failure, a sensor hiccup, or a condition that tripped a warning an hour ago and has since resolved.
This guide covers everything a working technician or fleet manager needs to know about Bobcat fault codes:
How the system works
What the most common codes mean
How to retrieve them from the machine
How to clear them safely.
What you're not seeing when you rely on the onboard display alone
What professional diagnostic tooling actually adds to the process
How Bobcat's Fault Code System Works
Active vs. Stored Fault Codes — Why Both Matter
Bobcat machines generate two categories of fault codes.
An active fault code is a condition that exists right now — the system is currently detecting something outside normal parameters.
A stored (or historical) fault code is a condition that was detected at some point in the past but is no longer active. The machine logged it, and it remains in memory until it's cleared.
Active codes demand immediate attention. Stored codes aren’t an immediate concern but should be investigated
A machine might show no active faults and run fine in your yard, but pull up the stored codes and you may find a pattern of intermittent hydraulic pressure warnings that hasn't progressed to a shutdown yet. That stored history tells you where to look before the next failure happens. Ignoring stored codes because the machine is currently running is one of the fastest ways to get caught off guard by a preventable breakdown.
Fault Code Severity Levels
Bobcat's fault system uses severity levels to indicate how urgently a fault requires attention.
Operator alerts are informational — they flag a condition the operator should be aware of, such as a filter service interval or a sensor reading that's drifting toward its limit, but they don't restrict machine operation.
Warning-level faults indicate a condition that requires attention. The machine will typically remain operational, but continuing to run without addressing the faults can lead to deeper issues later.
Shutdown-level faults are conditions severe enough that the control system will derate machine performance or halt operation entirely to prevent damage — high coolant temperature, critically low hydraulic pressure, or an ECM communication failure are prime examples of this.
Basically, the severity levels dictate how quickly you should respond. An operator alert on a Tier 4 machine warning of an upcoming DPF regeneration can be addressed during scheduled maintenance. A shutdown-level fault that trips mid-cycle needs to be diagnosed before the machine goes back to work.
Where Fault Codes Appear
On most Bobcat machines, fault codes appear on the operator display panel in the cab. Depending on the model and generation, this may be a simple numeric display, a multi-function LCD, or a full-colour touchscreen on newer machines. The display typically shows a code number and a basic descriptor. Some models will flash a code sequence on startup or when the fault is triggered.
Beyond the display, every Bobcat with an electronic control system has a diagnostic port — typically a 9-pin Deutsch connector located in the cab or engine compartment — through which a scan tool can communicate with the machine's ECMs. This is where the real diagnostics happen, and it's the access point used by both dealer technicians and in-house technicians with professional-grade diagnostic tools.
Download the Jaltest Pricing Guide to see exactly what a professional-grade Bobcat diagnostic setup costs.
How to Read Bobcat Fault Codes Step by Step
Using the Onboard Display (Without a Scan Tool)
To retrieve stored and active fault codes using only the machine's onboard system:
Start with the ignition key in the off position.
Turn the key to the on position without starting the engine.
On most Bobcat models, holding the select or menu button during startup will enter the diagnostic display mode.
Navigate through the menu using the display controls to access the fault code log.
The display will scroll through active codes first, followed by stored codes. Write down every code number before you clear anything.
The exact button sequence varies by model and display generation. On older machines with simpler displays, the process may involve a specific key cycle sequence to force fault code output. Consult the operator's manual for your specific machine if the above sequence doesn't produce a diagnostic menu.
Using a Professional Diagnostic Tool
With a professional scan tool connected to the 9-pin diagnostic port, the process is faster and significantly more insightful. The tool establishes communication with each ECM on the machine — engine, ACS, hydraulics, emissions — and presents a complete fault log for each system simultaneously.
From there, a technician can view active and stored codes with full descriptions, access freeze frame data showing sensor values at the moment a fault was triggered, run live data streams to watch system parameters in real time, and in some cases trigger actuations to test specific components.
Professional tools also allow controlled code clearing with confirmation prompts, keeping a record of what was cleared and when — important for warranty situations and fleet maintenance documentation.
What You Can See vs. What You're Missing Without a Proper Tool
The onboard display gives you a code number. That's the starting point, not the diagnosis. Without a proper scan tool, you cannot see the sensor values that were present when the fault triggered. You can't watch live hydraulic pressure while cycling the loader arms. You can't actuate the EGR valve to confirm it's moving. You can't view freeze frame data to determine whether a coolant temperature fault happened at startup or after two hours of load.
For simple, obvious faults — a clogged air filter, a low fluid level — the code number may be all you need. But for anything intermittent, anything emissions-related, or anything that keeps coming back after clearing, working without live data is guesswork with a code number attached. The information gap between reading a code on the display and actually diagnosing the root cause is where shops lose hours and fleets accumulate unnecessary repair costs.
How to Clear Bobcat Fault Codes
When It's Safe to Clear a Code
It's safe to clear a fault code when you have positively identified the root cause, performed the necessary repair or correction, and confirmed through live data or a functional test that the underlying condition is resolved. That's the complete list of conditions. Clearing a code before those boxes are checked doesn't fix anything — it just removes the documentation of a problem that still exists.
Why You Should Always Fix First, Clear Second
Clearing codes without diagnosing is one of the most counterproductive habits in equipment maintenance, and it's more common than it should be. When a code is cleared without being addressed, the condition that triggered it is still present. The code will return — often quickly — but you've now lost the freeze frame data from the original event, and in some cases you've reset the ECM's readiness monitors, which can create complications during emissions-related service procedures on Tier 4 machines.
There's also a documentation and liability dimension here. If a machine is cleared and returned to a job site and a subsequent failure causes damage or injury, the absence of fault history in the ECM is a problem. A professional diagnostic process leaves a paper trail — codes in, diagnosis made, repair performed, codes cleared, confirmation test passed.
Step-by-Step Code Clearing Process
Before clearing any codes, document the complete fault log. If you're using a scan tool, export or photograph the full code list including timestamps and freeze frame data. If you're using only the onboard display, write down every code number.
Once the underlying issue is corrected and confirmed, connect your scan tool and navigate to the fault code clearing function within the relevant ECM menu. Most professional tools will prompt you to confirm the clear action and log it with a timestamp. Clear active faults first, then stored faults if appropriate.
After clearing, perform a functional test that exercises the system that triggered the fault. Watch live data through the relevant parameters during the test. If the fault does not return and sensor values are within normal operating range, the repair is confirmed. If the fault returns immediately, the root cause has not been fully addressed.
On Tier 4 machines with DPF and SCR systems, some emissions-related codes require a specific completion procedure after the fault is cleared — such as a stationary regeneration or a drive cycle — before the ECM will mark the system ready. Consult the service documentation for your specific emissions configuration before returning the machine to service.
Frequently Asked Questions
Can I clear Bobcat fault codes myself without a scan tool?
Yes, in most cases you can clear codes through the onboard display using the machine's built-in diagnostic menu. The process involves navigating to the fault log via the display controls and selecting the clear option. However, clearing codes through the display alone doesn't give you access to freeze frame data, stored sensor values, or a confirmation that the underlying condition has been resolved. For any fault beyond a straightforward service item, clearing without a scan tool means you're removing the only documentation of what happened without the diagnostic information needed to confirm the repair. Use the display clear function for low-severity, confirmed faults; use a scan tool for anything serious or recurring.
Does Jaltest work on Bobcat skid steers and compact track loaders?
Yes. Jaltest covers a broad range of Bobcat equipment including skid steers, compact track loaders, excavators, and compact utility loaders. Coverage includes engine ECM communication, ACS (Advanced Control System) diagnostics, hydraulic system data, and Tier 4 emissions systems on applicable machines. Coverage is updated regularly as new model years are added to the database. Before purchasing, WholeFleet can confirm coverage for the specific Bobcat models in your fleet — that confirmation step is part of the pre-sale process.
What's the difference between a basic code reader and a full diagnostic tool for Bobcat equipment?
A basic code reader retrieves fault code numbers and provides generic descriptions. A full diagnostic platform like Jaltest communicates with every ECM on the machine and provides live sensor data, freeze frame capture, guided troubleshooting procedures, component actuation tests, and complete system scans. The practical difference is the depth of information available for making a repair decision. With a code number alone, you know that something was flagged — you don't know the conditions under which it occurred, whether it's active or stored, or what the rest of the system was doing at the time. Full diagnostic access turns a starting point into a diagnosis.
How do I know if a Bobcat fault code is serious enough to stop the machine?
Bobcat's fault severity system gives you the primary signal: shutdown-level faults are serious enough that the machine's control system has already made the decision for you by derating or halting operation. Warning-level faults indicate a condition that will escalate if ignored — continuing to operate is possible but increases the risk of component damage. Operator alerts are informational and typically don't require stopping work immediately. That said, severity level alone isn't the complete picture. A warning-level code on an engine oil pressure sensor that's potentially failing could be as serious as a shutdown fault depending on actual oil pressure — which is why live data matters. When in doubt, stop the machine, pull the full fault log, and check actual sensor values before making an operational decision.
Bobcat Fault Code List — Common Codes by System
The table below lists 23 common Bobcat fault codes organized by system. You can find the fault code you’re looking for with the search bar.
Note that exact code numbers can vary by model year, engine configuration, and control system generation. Always cross-reference codes against the specific machine's service manual or a diagnostic tool with current Bobcat coverage. Tier 4 emissions codes apply only to machines with DPF and SCR systems (typically 2013 and newer, depending on horsepower class).
3,350 codes
Attachments 56
| Fault Code | Description |
|---|---|
| A0618 | Wheel Speed Out of Range |
| A3623 | ACD Not Programmed |
| A4621 | 5 Volt Sensor Supply Out of Range High |
| A4622 | 5 Volt Sensor Supply Out of Range Low |
| A4721 | 8 Volt Sensor Supply Out of Range High |
| A4722 | 8 Volt Sensor Supply Out of Range Low |
| A7701 | Cab Key Switch Active |
| A7901 | E-Stop Active |
| A8002 | Output A Error On |
| A8003 | Output A Error Off |
| A8005 | Output A Short to Battery |
| A8006 | Output A Short to Ground |
| A8007 | Output A Open Circuit |
| A8032 | Output A Overcurrent |
| A8102 | Output B Error On |
| A8103 | Output B Error Off |
| A8105 | Output B Short to Battery |
| A8106 | Output B Short to Ground |
| A8107 | Output B Open Circuit |
| A8132 | Output B Overcurrent |
| A8202 | Output C Error On |
| A8203 | Output C Error Off |
| A8205 | Output C Short to Battery |
| A8206 | Output C Short to Ground |
| A8207 | Output C Open Circuit |
| A8232 | Output C Overcurrent |
| A8302 | Output D Error On |
| A8303 | Output D Error Off |
| A8305 | Output D Short to Battery |
| A8306 | Output D Short to Ground |
| A8307 | Output D Open Circuit |
| A8332 | Output D Overcurrent |
| A8402 | Output E Error On |
| A8403 | Output E Error Off |
| A8405 | Output E Short to Battery |
| A8406 | Output E Short to Ground |
| A8407 | Output E Open Circuit |
| A8432 | Output E Overcurrent |
| A8502 | Output F Error On |
| A8503 | Output F Error Off |
| A8505 | Output F Short to Battery |
| A8506 | Output F Short to Ground |
| A8507 | Output F Open Circuit |
| A8532 | Output F Overcurrent |
| A8602 | Output G Error On |
| A8603 | Output G Error Off |
| A8605 | Output G Short to Battery |
| A8606 | Output G Short to Ground |
| A8607 | Output G Open Circuit |
| A8702 | Output H Error On |
| A8703 | Output H Error Off |
| A8705 | Output H Short to Battery |
| A8706 | Output H Short to Ground |
| A8707 | Output H Open Circuit |
| A8802 | Reverse Solenoid Error On |
| A8803 | Reverse Solenoid Error Off |
Compact Wheel Loader 220
| Fault Code | Description |
|---|---|
| B1001-96 | Key Switch Failure |
| B1005-00 | Key Switch Multiple |
| B1034-11 | Rear Work Light Short to Battery |
| B1034-12 | Rear Work Light Short to Ground |
| B1034-13 | Rear Work Light Not Connected |
| B1037-11 | Stop Light Short to Ground |
| B1037-15 | Stop Light Error On |
| B103D-11 | Beacon Short to Ground |
| B103D-12 | Beacon Short to Battery |
| B103D-13 | Beacon Not Connected |
| B1040-11 | Buzzer Error Off |
| B1040-12 | Buzzer Error On |
| B1041-12 | Backup Alarm Error Off |
| B1041-14 | Backup Alarm Error On |
| B104A-11 | Seat Heater Short to Ground |
| B104A-12 | Seat Heater Short to Battery |
| B104A-13 | Seat Heater Open Circuit |
| B1064-F0 | Lift Input Not in Neutral |
| B1074-F0 | Tilt Input Not in Neutral |
| B1080-09 | Operator Presence Component Failure |
| B1080-16 | Operator Presence Circuit Voltage Below Threshold |
| B1080-17 | Operator Presence Circuit Voltage Above Threshold |
| B10A2-11 | Front Wiper Short to Ground |
| B10A2-12 | Front Wiper Short to Battery |
| B10A2-13 | Front Wiper Not connected |
| B10A3-11 | Front Wiper High Speed Short to Ground |
| B10A3-12 | Front Wiper High Speed Short to Battery |
| B10A3-13 | Front Wiper High Speed Not connected |
| B10A5-11 | Rear Wiper Short to Ground |
| B10A5-12 | Rear Wiper Short to Battery |
| B10A5-13 | Rear Wiper Not Connected |
| B10A7-11 | Front Washer Short to Ground |
| B10A7-12 | Front Washer Short to Battery |
| B10A7-13 | Front Washer Not Connected |
| B10A8-11 | Rear Washer Short to Ground |
| B10A8-12 | Rear Washer Short to Battery |
| B10A8-13 | Rear Washer Not Connected |
| B10C0-00 | Camera Not Connected |
| B10F0-11 | Rear Defog Short to Ground |
| B10F0-12 | Rear Defog Short to Battery |
| B10F0-13 | Rear Defog Circuit Open |
| B1100-9E | Power Exchange Lock Switch Stuck On |
| B1101-9E | Power Exchange Unlock Switch Stuck on |
| B1120-F0 | Joystick Right Roller Not in Neutral |
| B1150-F0 | FNR Lever not in Neutral |
| B1151-00 | FNR Switch Multiple |
| B1190-11 | Front Work Light Short to Battery |
| B1190-12 | Front Work Light Short to Ground |
| B1190-13 | Front Work Light Not Connected |
| B11B5-54 | Inching pedal sensor mising calibration |
| C1001-16 | Sensor Supply Out of Range Low |
| C1001-17 | Sensor Supply Out of Range High |
| C1003-16 | Sensor Supply Out of Range Low |
| C1003-17 | Sensor Supply Out of Range High |
| C1004-16 | Drive Controller Sensor Supply Out of Range Low |
| C1004-17 | Drive Controller Sensor Supply Out of Range High |
| C101A-16 | Lift Base Pressure Out of Range Low |
| C101A-17 | Lift Base Pressure Out of Range High |
| C1020-11 | Front Base Solenoid Short to Ground |
| C1020-12 | Front Base Solenoid Short to Battery |
| C1020-13 | Front Base Solenoid Open Circuit |
| C1020-19 | Front Base Solenoid Overcurrent |
| C1021-11 | Front Rod Solenoid Short to Ground |
| C1021-12 | Front Rod Solenoid Short to Battery |
| C1021-13 | Front Rod Solenoid Open Circuit |
| C1021-19 | Front Rod Solenoid Overcurrent |
| C102A-11 | Hydraulic Fan Short to Ground |
| C102A-12 | Hydraulic Fan Short to Battery |
| C102A-13 | Hydraulic Cooling Fan Electrical Problem |
| C102A-19 | Hydraulic Fan Overcurrent |
| C1039-11 | High Flow Solenoid Short to Ground |
| C1039-12 | High Flow Solenoid Short to Battery |
| C1039-13 | High Flow Solenoid Open Circuit |
| C1043-11 | Lift Cylinder Base Short to Ground |
| C1043-12 | Lift Cylinder Base Short to Battery |
| C1043-13 | Lift Cylinder Base Open Circuit |
| C1043-19 | Lift Cylinder Base Overcurrent |
| C1044-11 | Lift Cylinder Rod Short to Ground |
| C1044-12 | Lift Cylinder Rod Short to Battery |
| C1044-13 | Lift Cylinder Rod Open Circuit |
| C1044-19 | Lift Cylinder Rod Overcurrent |
| C1048-11 | Tilt Cylinder Rod Short to Ground |
| C1048-12 | Tilt Cylinder Rod Short to Battery |
| C1048-13 | Tilt Cylinder Rod Open Circuit |
| C1048-19 | Tilt Cylinder Rod Overcurrent |
| C1049-11 | Tilt Cylinder Base Short to Ground |
| C1049-12 | Tilt Cylinder Base Short to Battery |
| C1049-13 | Tilt Cylinder Base Open Circuit |
| C1049-19 | Tilt Cylinder Base Overcurrent |
| C1050-11 | Switched Power Relay Short to Ground |
| C1050-12 | Switched Power Relay Short to Battery |
| C1050-13 | Switched Power Relay Open Circuit |
| C1060-11 | Brake Short to Ground |
| C1060-12 | Brake Short to Battery |
| C1060-13 | Brake Open Circuit |
| C1060-19 | Brake Solenoid Overcurrent |
| C1090-00 | Hydraulic Filter Plugged |
| C1091-95 | Hydraulic Main Filter Switch Not Connected |
| C1099-FA | Hydraulic Oil Temperature Too High |
| C1099-FB | Hydraulic Oil Temperature Extremely High |
| C1099-FC | Hydraulic Oil Temperature Performance Reduction |
| C109A-16 | Hydraulic Oil Temperature Out of Range Low |
| C109A-17 | Hydraulic Oil Temperature Out of Range High |
| C10D1-11 | Drive Pump Forward Short to Ground |
| C10D1-12 | Drive Pump Forward Short to Battery |
| C10D1-13 | Drive Pump Forward Open Circuit |
| C10D1-19 | Drive Pump Forward Overcurrent |
| C10D2-11 | Drive Pump reverse Short to Ground |
| C10D2-12 | Drive Pump reverse Short to Battery |
| C10D2-13 | Drive Pump reverse Open Circuit |
| C10D2-19 | Drive Pump reverse Overcurrent |
| C1110-11 | Ride Control Circuit Short to Ground |
| C1110-15 | Ride Control Circuit Error On |
| C1111-16 | Ride Control Feedback Circuit Out of Range Low |
| C1111-17 | Ride Control Feedback Circuit Out of Range High |
| C1130-11 | Hydraulic Motor reverse Short to Ground |
| C1130-12 | Hydraulic Motor reverse Short to Battery |
| C1130-13 | Hydraulic Motor reverse Open Circuit |
| C1130-19 | Hydraulic Motor Overcurrent |
| C1182-A2 | Alternator Voltage Low |
| C1183-A3 | Alternator Voltage High |
| C1192-00 | System Voltage Extremely Low |
| C1193-00 | System Voltage Too Low |
| C1195-00 | System Voltage High |
| C1196-00 | System Voltage Extremely High |
| C1200-11 | Power Exchange Unlock Short to Ground |
| C1200-12 | Power Exchange Unlock Short to Battery |
| C1200-13 | Power Exchange Unlock Open Circuit |
| C1205-11 | Power Exchange Lock Short to Ground |
| C1205-12 | Power Exchange Lock Short to Battery |
| C1205-13 | Power Exchange Lock Open Circuit |
| C1220-11 | Diff-Lock Short to Ground |
| C1220-12 | Diff-Lock Short to Battery |
| C1220-13 | Diff-Lock Open Circuit |
| C1220-19 | Diff-Lock Overcurrent |
| C1221-17 | Diff-Lock Sensor Out of Range High |
| C1250-F9 | Park Brake Pressure Low |
| C1250-FA | Park Brake Pressure High |
| C1251-16 | Park Brake Pressure Sensor Circuit Out of Range Low |
| C1251-17 | Park Brake Pressure Sensor Circuit Out of Range High |
| C1260-F9 | Service Brake Pressure Low |
| C1260-FA | Service Brake Pressure High |
| C1260-FB | Service Brake Pressure Extremely High |
| C1261-16 | Service Brake Pressure Sensor Circuit Out of Range Low |
| C1261-17 | Service Brake Pressure Sensor Circuit Out of Range High |
| C1270-F9 | Steering Pressure Low |
| C1271-16 | Steering Pressure Sensor Circuit Out of Range Low |
| C1271-17 | Steering Pressure Sensor Circuit Out of Range High |
| C1280-F9 | Reserve Brake Pressure Low |
| C1280-FA | Reserve Brake Pressure High |
| C1280-FB | Reserve Brake Pressure Extremely Low |
| C1281-16 | Reserve Brake Pressure Sensor Circuit Out of Range Low |
| C1281-17 | Reserve Brake Pressure Sensor Circuit Out of Range High |
| C12F0-FB | Hydromotor Speed Extremely High |
| C12F1-31 | Hydromotor Speed Sensor Not Connected |
| C1300-16 | Inching Sensor Circuit Out of Range Low |
| C1300-17 | Inching Sensor Circuit Out of Range High |
| P0225-16 | Throttle Pedal Sensor Out of Range Low |
| P0225-17 | Throttle Pedal Sensor Out of Range High |
| P0226-16 | Throttle Pedal Sensor Secondary Out of Range Low |
| P0226-17 | Throttle Pedal Sensor Secondary Out of Range High |
| P0227-93 | Throttle Pedal Failure |
| P0460-16 | Fuel Level Sensor Out of Range Low |
| P0460-17 | Fuel Level Sensor Problem |
| P1061-97 | Air Filter Plugged |
| P1065-31 | Air Filter Switch Not Connected |
| P1100-FA | Engine Coolant Temperature High |
| P1100-FB | Engine Coolant Temperature Extremely High |
| P1100-FC | Engine Coolant Temperature Shutdown |
| P1110-FA | Fuel Temperature High |
| P1110-FB | Fuel Temperature Extremely High |
| P1110-FC | Fuel Temperature Limiting Performance |
| P1115-FA | Air Intake Temperature Too High |
| P1115-FB | Air Intake Temperature Extremely High |
| P1115-FC | Air Intake Temperature Limiting Performance |
| P1120-00 | Fuel Filter Plugged |
| P1121-00 | Fuel Filter Derate Level 1 |
| P1122-00 | Fuel Filter Derate Level 2 |
| P1125-00 | Fuel Filter Extremely Plugged |
| P1130-F8 | Fuel Filter Inlet Pressure Extremely Low |
| P1130-F9 | Fuel Filter Inlet Pressure Low |
| P1131-16 | Fuel Pressure Out of Range Low |
| P1131-17 | Fuel Pressure Out of Range High |
| P1134-11 | Fuel Lift Pump Short to Ground |
| P1134-15 | Fuel Lift Pump Short Error On |
| P1134-63 | Fuel Lift Pump Protection Time-Out |
| P113B-7B | Fuel Level Low |
| U1010-08 | PTOL Keypad No Communication |
| U1012-08 | Cab Keypad No Communication |
| U1013-08 | Accessory (ACD) Keypad No Communication |
| U1040-00 | Hour Meter Changed |
| U1050-00 | Power Failure |
| U1053-00 | Drive Controller Interrupted Power |
| U1054-00 | Interrupted Power Failure |
| U1070-00 | Hub Controller Software Updated |
| U1073-00 | Drive Controller Programmed |
| U1074-00 | Workgroup Controller Software Updated |
| U1090-51 | Hub Controller Not Programmed |
| U1090-57 | Hub Controller Software Version Error |
| U1091-08 | Display No Communication |
| U1091-51 | Display Not Programmed |
| U1091-FD | Display Shutdown |
| U1094-08 | Drive Controller No Communication |
| U1094-51 | Drive Controller Not Progammed |
| U1094-57 | Drive Controller Software Update Required |
| U1094-A2 | Drive Controller Voltage Out of Range Low |
| U1094-A3 | Drive Controller Voltage Out of Range High |
| U1095-08 | Workgroup Controller No Communication |
| U1095-51 | Workgroup Controller Not Programmed |
| U1095-57 | Workgroup Controller Software Version Error |
| U1095-A2 | Workgroup Controller System Voltage Low |
| U1095-A3 | Workgroup Controller System Voltage High |
| U1096-08 | ECU No Communication |
| U1096-56 | ECU Failure |
| U10C0-08 | Right Joystick Base Message Failure |
| U1180-00 | Display Controller Communcation Error |
| U1181-00 | Display Controller Communcation Error |
| U1182-00 | Display Controller Communcation Error |
| U1183-00 | Main Controller No Communication |
| U1184-00 | Jog Shuttle No Communication |
E145 & E165 Excavator 137
| Fault Code | Description |
|---|---|
| VAL001-03 | ALTERNATOR POTENTIAL, Voltage above normal |
| VAL001-04 | ALTERNATOR POTENTIAL, Voltage below normal |
| VAL002-05 | ACCEL. PEDAL SWITCH, Current below normal |
| VAL002-06 | ACCEL. PEDAL SWITCH, Current above normal |
| VCO001-11 | GAUGE PANEL ERROR |
| VCO002-11 | E-ECU ERROR |
| VPV001-05 | PUMP P/V (A), Current below normal |
| VPV001-06 | PUMP P/V (A), Current above normal |
| VPV002-05 | PUMP P/V (B), Current below normal |
| VPV002-06 | PUMP P/V (B), Current above normal |
| VPV003-05 | FLOW CONTROL P/V (G), Current below normal |
| VPV003-06 | FLOW CONTROL P/V (G), Current above normal |
| VPV004-05 | FAN CONTROL P/V (J), Current below normal |
| VPV004-06 | FAN CONTROL P/V (J), Current above normal |
| VPV005-05 | PRESS. CONTROL 1 P/V (H), Current below normal |
| VPV005-06 | PRESS. CONTROL 1 P/V (H), Current above normal |
| VPV006-05 | PRESS. CONTROL 2 P/V (I), Current below normal |
| VPV006-06 | PRESS. CONTROL 2 P/V (I), Current above normal |
| VPV007-05 | FLOW CONTROL P/V (C) 2-WAY RH-OPEN, Current below normal |
| VPV007-06 | FLOW CONTROL P/V (C) 2-WAY RH-OPEN, Current above normal |
| VPV008-05 | FLOW CONTROL P/V (D) 2-WAY RH-CLOSE, Current below normal |
| VPV008-06 | FLOW CONTROL P/V (D) 2-WAY RH-CLOSE, Current above normal |
| VPV009-05 | FLOW CONTROL P/V (E) ROTATING CW, Current below normal |
| VPV009-06 | FLOW CONTROL P/V (E) ROTATING CW, Current above normal |
| VPV010-05 | FLOW CONTROL P/V (F) ROTATING CCW, Current below normal |
| VPV010-06 | FLOW CONTROL P/V (F) ROTATING CCW, Current above normal |
| VPV011-05 | TRAVEL, Current below normal |
| VPV011-06 | TRAVEL, Current above normal |
| VPV012-05 | TRAVEL STRAIGHT P/V (L), Current below normal |
| VPV012-06 | TRAVEL STRAIGHT P/V (L), Current above normal |
| VRY001-05 | GLOW PLUG RELAY, Current below normal |
| VRY001-06 | GLOW PLUG RELAY, Current above normal |
| VRY002-05 | BACK BUZZER RELAY, Current below normal |
| VRY002-06 | BACK BUZZER RELAY, Current above normal |
| VRY003-05 | BACKUP LAMP RELAY, Current below normal |
| VRY003-06 | BACKUP LAMP RELAY, Current above normal |
| VRY004-05 | INCHING RELAY, Current below normal |
| VRY004-06 | INCHING RELAY, Current above normal |
| VRY005-05 | LOW SPEED RELAY, Current below normal |
| VRY005-06 | LOW SPEED RELAY, Current above normal |
| VRY006-05 | HIGH SPEED RELAY, Current below normal |
| VRY006-06 | HIGH SPEED RELAY, Current above normal |
| VRY007-05 | STARTER RELAY, Current below normal |
| VRY007-06 | STARTER RELAY, Current above normal |
| VRY008-05 | GLOW PLUG II RELAY, Current below normal |
| VRY008-06 | GLOW PLUG II RELAY, Current above normal |
| VS5001-03 | THUMB WHEEL (RH), Voltage above normal |
| VS5001-04 | THUMB WHEEL (RH), Voltage below normal |
| VS5002-03 | THUMB WHEEL (LH), Voltage above normal |
| VS5002-04 | THUMB WHEEL (LH), Voltage below normal |
| VS5003-03 | ACCEL PEDAL SENSOR, Voltage above normal |
| VS5003-04 | ACCEL PEDAL SENSOR, Voltage below normal |
| VS5004-03 | PARKING BRAKE PRESS. SENSOR, Voltage above normal |
| VS5004-04 | PARKING BRAKE PRESS. SENSOR, Voltage below normal |
| VS5005-03 | DIAL, Voltage above normal |
| VS5005-04 | DIAL, Voltage below normal |
| VSE001-00 | OIL TEMP. SENSOR, Signal above normal range |
| VSE001-03 | OIL TEMP. SENSOR, Voltage above normal |
| VSE001-04 | OIL TEMP. SENSOR, Voltage below normal |
| VSE002-03 | FUEL SENSOR, Voltage above normal |
| VSE002-04 | FUEL SENSOR, Voltage below normal |
| VSE003-03 | VEHICLE SPEED SENSOR, Voltage above normal |
| VSE003-04 | VEHICLE SPEED SENSOR, Voltage below normal |
| VSE004-01 | WIF SENSOR, Signal below normal range |
| VSE004-03 | WIF SENSOR, Voltage above normal |
| VSE004-04 | WIF SENSOR, Voltage below normal |
| VSE005-03 | SPARE SPEED, Voltage above normal |
| VSE005-04 | SPARE SPEED, Voltage below normal |
| VSE006-03 | SPARE, Voltage above normal |
| VSE006-04 | SPARE, Voltage below normal |
| VSE007-03 | ANGLE SENSOR (A), Voltage above normal |
| VSE007-04 | ANGLE SENSOR (A), Voltage below normal |
| VSE008-03 | ANGLE SENSOR (B), Voltage above normal |
| VSE008-04 | ANGLE SENSOR (B), Voltage below normal |
| VSP001-02 | FRONT PUMP PRESS. SENSOR, Incorrect signal |
| VSP001-03 | FRONT PUMP PRESS. SENSOR, Voltage above normal |
| VSP001-04 | FRONT PUMP PRESS. SENSOR, Voltage below normal |
| VSP002-02 | REAR PUMP PRESS. SENSOR, Incorrect signal |
| VSP002-03 | REAR PUMP PRESS. SENSOR, Voltage above normal |
| VSP002-04 | REAR PUMP PRESS. SENSOR, Voltage below normal |
| VSP003-02 | OWD PRESS. SENSOR, Incorrect signal |
| VSP003-03 | OWD PRESS. SENSOR, Voltage above normal |
| VSP003-04 | OWD PRESS. SENSOR, Voltage below normal |
| VSP004-03 | Px(FRONT) PRESS. SENSOR, Voltage above normal |
| VSP004-04 | Px(FRONT) PRESS. SENSOR, Voltage below normal |
| VSP005-03 | Pressure Sensor Issue |
| VSP005-04 | Py(TRAVEL) PRESS. SENSOR, Voltage below normal |
| VSP006-03 | BOOM UP PRESS. SENSOR, Voltage above normal |
| VSP006-04 | BOOM UP PRESS. SENSOR, Voltage below normal |
| VSP007-03 | BUCKET CROWD PRESS. SENSOR, Voltage above normal |
| VSP007-04 | BUCKET CROWD PRESS. SENSOR, Voltage below normal |
| VSP008-03 | BOOM DOWN PRESS. SENSOR, Voltage above normal |
| VSP008-04 | BOOM DOWN PRESS. SENSOR, Voltage below normal |
| VSP009-03 | BUCKTET DUMP PRESS. SENSOR, Voltage above normal |
| VSP009-04 | BUCKTET DUMP PRESS. SENSOR, Voltage below normal |
| VSP010-03 | ARM IN PRESS. SENSOR, Voltage above normal |
| VSP010-04 | ARM IN PRESS. SENSOR, Voltage below normal |
| VSP011-03 | ARM OUT PRESS. SENSOR, Voltage above normal |
| VSP011-04 | ARM OUT PRESS. SENSOR, Voltage below normal |
| VSP012-03 | TRAVEL PRESS. SENSOR(LH), Voltage above normal |
| VSP012-04 | TRAVEL PRESS. SENSOR(LH), Voltage below normal |
| VSP013-03 | TRAVEL PRESS. SENSOR(RH), Voltage above normal |
| VSP013-04 | TRAVEL PRESS. SENSOR(RH), Voltage below normal |
| VSP014-03 | SWING PRESS. SENSOR, Voltage above normal |
| VSP014-04 | SWING PRESS. SENSOR, Voltage below normal |
| VSP015-03 | ATT(OPTION) PRESS. SENSOR, Voltage above normal |
| VSP015-04 | ATT(OPTION) PRESS. SENSOR, Voltage below normal |
| VSP016-03 | ATTACHMENT 2 PRESS. SENSOR, Voltage above normal |
| VSP016-04 | ATTACHMENT 2 PRESS. SENSOR, Voltage below normal |
| VSP017-03 | OPTION PEDAL 1 PRESS. SENSOR, Voltage above normal |
| VSP017-04 | OPTION PEDAL 1 PRESS. SENSOR, Voltage below normal |
| VSP018-03 | OPTION PEDAL 2 PRESS. SENSOR, Voltage above normal |
| VSP018-04 | OPTION PEDAL 2 PRESS. SENSOR, Voltage below normal |
| VSV001-05 | BREAKER OPERATING S/V, Current below normal |
| VSV001-06 | BREAKER OPERATING S/V, Current above normal |
| VSV002-05 | RELIEF PRESS. UP S/V (B), Current below normal |
| VSV002-06 | RELIEF PRESS. UP S/V (B), Current above normal |
| VSV003-05 | HIGH SPEED S/V (C), Current below normal |
| VSV003-06 | HIGH SPEED S/V (C), Current above normal |
| VSV004-05 | REVERSE FAN S/V (D), Current below normal |
| VSV004-06 | REVERSE FAN S/V (D), Current above normal |
| VSV005-05 | TRAVEL II PUMP CONFLUENCE S/V, Current below normal |
| VSV005-06 | TRAVEL II PUMP CONFLUENCE S/V, Current above normal |
| VSV006-05 | SWING BRAKE RELEASE S/V (K), Current below normal |
| VSV006-06 | SWING BRAKE RELEASE S/V (K), Current above normal |
| VSV007-05 | OPTION SAFETY S/V, Current below normal |
| VSV007-06 | OPTION SAFETY S/V, Current above normal |
| VSV008-05 | CRUISE S/V (F), Current below normal |
| VSV008-06 | CRUISE S/V (F), Current above normal |
| VSV009-05 | FORWARD S/V (G), Current below normal |
| VSV009-06 | FORWARD S/V (G), Current above normal |
| VSV010-05 | REVERSE S/V (H), Current below normal |
| VSV010-06 | REVERSE S/V (H), Current above normal |
| VSV011-05 | 2 Pump SELECT S/V (I), Current below normal |
| VSV011-06 | 2 Pump SELECT S/V (I), Current above normal |
| VSV012-05 | BYPASS CUT OFF S/V (J), Current below normal |
| VSV012-06 | BYPASS CUT OFF S/V (J), Current above normal |
ECU Bobcat Engine D34 210
| Fault Code | Description |
|---|---|
| P0426 | SCR Pre-Treatment Temperature Sensor Tampering |
| P0427 | SCR Pre-Treatment Temperature Sensor Out of Range Low |
| P0428 | SCR Pre-Treatment Temperature Sensor Out of Range High |
| P0658 | DCU Fault |
| P0659 | DCU Fault |
| P068A | DCU Fault |
| P115A | DEF Temperature Sensor Failure |
| P115C | DEF Temperature Sensor Short to Ground |
| P115D | DEF Temperature Sensor Open Circuit |
| P1220 | DEF Temperature Fault |
| P1221 | DEF Temperature Fault |
| P1223 | DEF Temperature Too High |
| P1224 | DEF Temperature Too Low |
| P1227 | DEF Temperature Sensor Fault |
| P1229 | DEF Temperature Signal Fault |
| P1230 | DEF Level Signal Fault |
| P1231 | DEF Level Sensor Fault |
| P123A | DEF Fill Level Fault |
| P123B | DEF Fill Level Fault |
| P123C | DEF Level Extremely Low |
| P123D | DEF Level Empty |
| P1332 | Dosing Valve Tip Temperature Fault |
| P1337 | Dosing Valve Tip Temperature Fault |
| P1350 | DOC Pre-Treatment Temperature Too High |
| P1351 | DOC Pre-Treatment Temperature Too Low |
| P1353 | DOC Pre-Treatment Temperature Sensor Out of Range High |
| P1354 | DOC Pre-Treatment Temperature Sensor Out of Range Low |
| P1360 | SCR Pre-Treatment Temperature Too High |
| P1361 | SCR Pre-Treatment Temperature Too Low |
| P1443 | DEF Pump Pressure Max |
| P1444 | DEF Pump Pressure Min |
| P1450 | Metering Control Overpressure |
| P1451 | Metering Control Underpressure |
| P1452 | Monitoring of Overpressure |
| P1453 | Pressure Stabilization Fault |
| P1455 | Monitoring of Pressure Build-up |
| P1511 | DEF Quality Sensor Fault |
| P1531 | DEF Quality Sensor Fault |
| P1560 | DEF Quality Too High |
| P1561 | DEF Quality Too Low |
| P1561 | Battery Voltage Fault |
| P1562 | Battery Voltage Low |
| P1563 | Battery Voltage High |
| P1602 | DCU Sensor Supply Error |
| P160F | DCU Fault |
| P1630 | DCU Fault |
| P1631 | DCU Fault |
| P16C0 | DCU Fault |
| P16C1 | DCU Fault |
| P16C2 | DCU Fault |
| P16C3 | DCU Fault |
| P16C4 | DCU Fault |
| P16C5 | DCU Fault |
| P1710 | Enviroment Temperature Too High |
| P1711 | Enviroment Temperature Too Low |
| P1712 | Enviroment Temperature Sensor Fault |
| P1713 | Enviroment Temperature Sensor Fault |
| P1880 | Outlet Line Heater Fault |
| P1882 | Outlet Line Heater Fault |
| P1884 | Outlet Line Heater Over-temperature |
| P1885 | Outlet Line Heater Open Circuit |
| P1892 | Backflow Line Heater Fault |
| P1893 | Backflow fault |
| P1894 | Backflow Line Heater Over-Temperature |
| P1895 | Backflow Line Heater Open Circuit |
| P18A2 | Inlet Line Heater Fault |
| P18A3 | Inlet Line Heater Short to Battery |
| P18A4 | Inlet Line Heater Over-Temperature |
| P18A5 | Inlet Line Heater Open Circuit |
| P18B0 | DEF Line Heater Short to Battery |
| P18B2 | DEF Heater Relay Over-Temperature |
| P18B5 | DEF Heater Relay Open Circuit |
| P1A32 | Nox Sensor Self Diagnostics |
| P1A37 | Nox Sensor Self Diagnostics |
| P1A39 | Nox Sensor Self Diagnostics |
| P1A42 | Nox Sensor Self Diagnostics |
| P1A47 | Nox Sensor Self Diagnostics |
| P1A49 | Nox Sensor Self Diagnostics |
| P201F | DEF Pump Motor Speed Fault |
| P202A | DEF Tank Coolant Valve Open Circuit |
| P202B | DEF Tank Coolant Valve Short to Ground |
| P202C | DEF Tank Coolant Valve Short to Battery |
| P202E | Dosing Valve Temperature Too High |
| P203C | DEF Level Sensor Fault |
| P203D | DEF Level Sensor Fault |
| P2047 | Dosing Valve Short to Battery |
| P2048 | Dosing Valve Short to Ground |
| P2049 | Dosing Valve Short to Battery |
| P204A | General Pressure Check Fault |
| P204E | Backflow Pump Fault |
| P205E | DEF Overheating |
| P206C | DEF Quality Sensor Fault |
| P206D | DEF Quality Sensor Fault |
| P208A | DEF Pump Motor Open Circuit |
| P208B | DEF Pump Motor Overtemperature |
| P208C | DEF Pump Motor Short to Ground |
| P208D | DEF Pump Motor Short to Battery |
| P208E | Dosing Valve Blocked |
| P209F | DEF Tank Coolant Valve Temperature Too High |
| P20B9 | Supply Module Heater Open Circuit |
| P20BA | Supply Module Heater Overtemperature |
| P20BC | Supply Module Heater Short to Battery |
| P20BD | DEF Outlet Line Heater Short to Ground or Open Circuit |
| P20BF | Outlet Line Heater Short to Ground |
| P20C0 | Outlet Line Heater Short to Battery |
| P20C1 | DEF Backflow Line Heater Short to Ground or Open Circuit |
| P20C3 | Backflow Line Heater Short to Ground |
| P20C4 | Backflow Line Heater Short to Battery |
| P20C5 | DEF Inlet Line Heater Short to Ground or Open Circuit |
| P20C7 | Inlet Line Heater Short to Ground |
| P20E8 | DEF Pump Pressure Too Low |
| P20EE | SCR Efficiency Fault |
| P20FA | DEF Backflow Pump Open Circuit |
| P20FB | DEF Backflow Pump Overtemperature |
| P20FC | DEF Backflow Pump Short to Ground |
| P20FD | DEF Backflow Pump Short to Battery |
| P21C3 | DEF Heater Relay Short to Ground |
| P21C4 | DEF Heater Relay Short to Battery |
| P2202 | NOx Pre-treatment Sensor Short Circuit |
| P2203 | NOx Pre-treatment Sensor Open Circuit |
| P2215 | NOx Post-treatement Sensor Short Circuit |
| P2216 | NOx Post-treatement Sensor Open Circuit |
| P2381 | Nox Pre-Treatment Fault |
| P2382 | Nox Post-Treatment Fault |
| P2383 | Nox Pre-Treatment Fault |
| P2384 | Nox Post-Treatment Fault |
| P2385 | Nox Pre-Treatment Fault |
| P2386 | Nox Post-Treatment Fault |
| P2387 | Nox Pre-Treatment Fault |
| P2388 | Nox Pre-Treatment Fault |
| P2391 | NOx Pre-treatment Sensor Fault |
| P2392 | NOx Post-treatement Sensor Fault |
| P2393 | NOx Pre-treatment Sensor Fault |
| P2394 | NOx Post-treatement Sensor Fault |
| P2395 | NOx Pre-treatment Sensor Fault |
| P2396 | NOx Post-treatement Sensor Fault |
| P2397 | NOx Pre-treatment Sensor Fault |
| P2398 | NOx Post-treatement Sensor Fault |
| P23A1 | NOx Pre-treatment Sensor Fault |
| P23A2 | NOx Post-treatement Sensor Fault |
| P23A3 | NOx Pre-treatment Sensor Fault |
| P23A4 | NOx Post-treatement Sensor Fault |
| P23A5 | NOx Pre-treatment Sensor Fault |
| P23A6 | NOx Post-treatement Sensor Fault |
| P23A7 | NOx Pre-treatment Sensor Fault |
| P23A8 | NOx Post-treatement Sensor Fault |
| P23A9 | NOx Pre-treatment Sensor Fault |
| P23AA | NOx Post-treatement Sensor Fault |
| P23B0 | DEF Hose Leak |
| P23B1 | Evaluate Filter Clog |
| P23B2 | Supply Module Heater Fault |
| P23B3 | Supply Module Heater Temperature Fault |
| P23B4 | Supply Module Heater Temperature Fault |
| P23B5 | Supply Modlue Temperature Fault |
| P23B6 | Supply Module Temperature Fault |
| P23BA | DEF Pump Pressure Too Low |
| P23BB | DEF Pump Pressure Too High |
| P24F4 | SCR Pre-Treatment Temperature Fault |
| P24F5 | SCR Pre-Treatment Temperature Fault |
| P24F6 | SCR Pre-Treatment Temperature Fault |
| P2510 | DCU Fault |
| P2530 | DCU Activation Signal Fault |
| P25E0 | Supply Module Heater Fault |
| P25E1 | Supply Module Heater Fault |
| P25E2 | Supply Module Temperature Duty Low |
| P25E3 | Supply Module Temperature Duty High |
| P2670 | DCU Fault |
| P2671 | DCU Fault |
| P2685 | DCU Fault |
| P2686 | DCU Fault |
| P26E8 | DCU Fault |
| P26E9 | DCU Fault |
| P2A8C | DEF Pump Motor Speed Fault |
| P2A8D | DEF Pump Motor Speed Fault |
| P2B8C | DEF Pump Motor Fault |
| P2B8D | DEF Pump Motor Fault |
| U010E | DCU Communication Fault |
| U0401 | DCU Communication Fault |
| U040F | DEF Pump Motor Fault |
| U1024 | Nox Pre-Treatment CAN communication Fault |
| U1025 | Nox Pre-Treatment CAN communication Fault |
| U1026 | Nox Pre-Treatment CAN communication Fault |
| U1027 | Nox Pre-Treatment CAN communication Fault |
| U1028 | Nox Pre-Treatment CAN communication Fault |
| U1029 | Nox Pre-Treatment CAN communication Fault |
| U102A | Nox Pre-Treatment CAN communication Fault |
| U102B | Nox Post-Treatement CAN communication Fault |
| U102C | Nox Post-Treatement CAN communication Fault |
| U102D | Nox Post-Treatement CAN communication Fault |
| U102E | Nox Post-Treatement CAN communication Fault |
| U102F | Nox Post-Treatement CAN communication Fault |
| U1030 | Nox Post-Treatement CAN communication Fault |
| U1031 | Nox Post-Treatement CAN communication Fault |
| U111A | CAN Communications Fault |
| U1164 | CAN Communications Fault |
| U116D | CAN Communications Fault |
| U1216 | NOx Pre-treatment Sensor Fault |
| U1219 | NOx Pre-treatment Sensor Fault |
| U121A | CAN Communications Fault |
| U1223 | NOx Pre-treatment Sensor Fault |
| U1224 | NOx Pre-treatment Sensor Fault |
| U1225 | NOx Post-treatement Sensor Fault |
| U1226 | NOx Post-treatement Sensor Fault |
| U1227 | NOx Post-treatement Sensor Fault |
| U1229 | NOx Post-treatement Sensor Fault |
| U1233 | NOx Post-treatement Sensor Fault |
| U1235 | NOx Post-treatement Sensor Fault |
| U1444 | CAN Communications Fault |
| U1661 | CAN Communications Fault |
| U1923 | CAN Communications Fault |
ECU Bobcat Engine V1 275
| Fault Code | Description |
|---|---|
| 3251-03 | EGR Temperature Sensor - Fault |
| 3251-04 | EGR Temperature Sensor - Fault |
| 3252-00 | Exhaust Temperature - High |
| 3509-03 | Sensor Supply Voltage Fault |
| 3509-04 | Sensor Supply Voltage Fault |
| P0002 | Rail Pressure Control Fault |
| P0003 | Rail Pressure Control Fault |
| P0004 | Rail Pressure Control Fault |
| P0006 | Rail Pressure Control Fault |
| P0007 | Rail Pressure Control Fault |
| P0016 | Cam or Crank Sensor - Fault |
| P0070 | Intake Air Temperature Sensor Fault |
| P0072 | MAF Sensor - Fault |
| P0072 | Intake Air Temperature - Fault |
| P0073 | MAF Sensor - Fault |
| P0073 | Intake Air Temperature - Fault |
| P0074 | Intake Air Temperature Sensor Fault |
| P0087 | Rail Pressure Fault |
| P0087 | Rail Pressure - Fault |
| P0088 | Rail Pressure Control Fault |
| P0088 | Rail Pressure - Fault |
| P0089 | Rail Pressure Control Fault |
| P00BC | Intake Air Volume - Fault |
| P00BD | Intake Air Volume - Fault |
| P0100 | MAF Sensor - Fault |
| P0101 | Intake Air Volume - Fault |
| P0102 | MAF Sensor - Fault |
| P0103 | MAF Sensor - Fault |
| P0105 | Manifold Pressure Sensor Fault |
| P0107 | Manifold Pressure Sensor Fault |
| P0108 | Manifold Pressure Sensor Fault |
| P0110 | Intake Manifold Temperature Sensor Fault |
| P0111 | Intake Manifold Temperature Fault |
| P0111 | Intake Air Temperature - High |
| P0112 | Intake Air Temperature - Fault |
| P0112 | Intake Manifold Temperature Sensor Fault |
| P0113 | Intake Manifold Temperature Sensor Fault |
| P0113 | Intake Air Temperature - Fault |
| P0114 | Intake Manifold Temperature Sensor Fault |
| P0116 | Engine Coolant Temperature Fault |
| P0117 | Water Temp Sensor Fault |
| P0118 | Water Temp Sensor Fault |
| P0180 | Fuel Temp Sensor Fault |
| P0181 | Fuel Temperature Fault |
| P0181 | Fuel Temperature - High |
| P0182 | Fuel Temp Sensor Fault |
| P0183 | Fuel Temp Sensor Fault |
| P0190 | Rail Pressure Sensor Fault |
| P0191 | Rail Pressure Fault |
| P0192 | Rail Pressure Sensor Fault |
| P0193 | Rail Pressure Sensor Fault |
| P0195 | Engine Oil Temperature Sensor Fault |
| P0196 | Engine Oil Temperature Fault |
| P0200 | Injector Fault |
| P0201 | Injector #1 Fault |
| P0202 | Injector #3 Fault |
| P0202 | Injector #2 Fault |
| P0203 | Injector #4 Fault |
| P0203 | Injector #3 Fault |
| P0204 | Injector #4 Fault |
| P0204 | Injector #2 Fault |
| P0217 | Engine Temp Extremely High |
| P0219 | Engine Speed Extremely High |
| P0237 | Engine Oil Pressure Sensor Fault |
| P0237 | Intake Air Pressure Sensor Fault |
| P0238 | Intake Air Pressure Sensor Fault |
| P0238 | Engine Oil Pressure Sensor Fault |
| P0241 | Boost Control Fault |
| P0242 | Boost Control Fault |
| P0251 | Rail Pressure Control Fault |
| P0252 | Rail Pressure Control Fault |
| P0253 | Rail Pressure Control Fault |
| P0254 | Rail Pressure Control Fault |
| P0258 | Rail Pressure Control Fault |
| P0259 | Rail Pressure Control Fault |
| P025A | Inlet Metering Valve Fault |
| P025B | Inlet Metering Valve Fault |
| P025C | Inlet Metering Valve Fault |
| P025D | Inlet Metering Valve Fault |
| P0261 | Injector #1 Fault |
| P0262 | Injector #1 Fault |
| P0264 | Injector #2 Fault |
| P0265 | Injector #2 Fault |
| P0267 | Injector #3 Fault |
| P0268 | Injector #3 Fault |
| P0270 | Injector #4 Fault |
| P0271 | Injector #4 Fault |
| P029A | Injector #1 Fault |
| P029B | Injector #1 Fault |
| P029E | Injector #2 Fault |
| P029F | Injector #2 Fault |
| P02A2 | Injector #3 Fault |
| P02A3 | Injector #3 Fault |
| P02A6 | Injector #4 Fault |
| P02A7 | Injector #4 Fault |
| P02EE | Injector #1 Fault |
| P02EF | Injector #2 Fault |
| P02F0 | Injector #3 Fault |
| P02F1 | Injector #4 Fault |
| P0325 | Accelerometer Fault |
| P0330 | Accelerometer Fault |
| P0335 | Crank position sensor fault |
| P0336 | Crank position sensor fault |
| P0339 | Crank position sensor fault |
| P0340 | Camshaft position sensor fault |
| P0340 | CAM Signal Fault |
| P0341 | CAM Signal Fault |
| P0341 | Camshaft position sensor fault |
| P0342 | CAM Signal Fault |
| P0344 | CAM Signal Fault |
| P0371 | Crank position sensor fault |
| P0372 | Crank position sensor fault |
| P0374 | Crank position sensor fault |
| P037E | Glow Plug Signal - Fault |
| P037F | Glow Plug Signal - Fault |
| P0380 | Glow Plug Relay Fault |
| P0380 | Intake heater fault |
| P0383 | Glow Plug Relay Fault |
| P0384 | Glow Plug Relay Fault |
| P0400 | EGR Fault |
| P0400 | EGR Blocked Fault |
| P0401 | EGR Control Fault |
| P0402 | EGR Control Fault |
| P0403 | EGR Actuator - Fault |
| P0404 | EGR Fault |
| P0404 | EGR Position Fault |
| P0404 | EGR Actuator - Fault |
| P0405 | EGR Fault |
| P0406 | EGR Fault |
| P0406 | EGR Actuator Position Fault |
| P0407 | EGR Actuator Position Fault |
| P0409 | EGR Position Sensor - Fault |
| P0409 | EGR Actuator Position Fault |
| P0421 | DOC Exothermal Efficiency Fault |
| P046D | EGR Actuator Position Fault |
| P0524 | Engine Oil Pressure Low |
| P0543 | Exhaust Gas Temperature Sensor - Fault |
| P0544 | Exhaust Gas Temperature Sensor - Fault |
| P0545 | Turbo Temperature Sensor Fault |
| P0546 | Turbo Temperature Sensor Fault |
| P0546 | Exhaust Gas Temperature Sensor - Fault |
| P0547 | Exhaust Gas Temperature Sensor - Fault |
| P0562 | Battery Voltage Low |
| P0563 | Battery Voltage High |
| P0602 | ECU Fault |
| P0602 | Injector Data Fault |
| P0603 | ECU Fault |
| P0604 | ECU Fault |
| P0605 | ECU Fault |
| P0606 | ECU Fault |
| P060B | ECU Fault |
| P0611 | Injector Fault |
| P061B | ECU Safety Monitoring - Fault |
| P0628 | High Pressure Pump Fault |
| P0629 | High Pressure Pump Fault |
| P062D | Injector #1 and #4 Fault |
| P062E | Injector #2 and #3 Fault |
| P062F | ECU Fault |
| P0641 | 5V Sensor Supply #1 Fault |
| P0651 | 5V Sensor Supply #2 Fault |
| P0652 | Sensor Supply Voltage Fault |
| P0653 | Sensor Supply Voltage Fault |
| P0687 | ECU Main Relay Fault |
| P0697 | 5V Aux Sensor Supply #2 Fault |
| P0C17 | EGR Position Learning - Fault |
| P0C18 | EGR Position Learning - Fault |
| P1219 | ECU Safety Monitoring - Fault |
| P1228 | ECU Safety Monitoring - Fault |
| P1274 | Fuel Pump Fault |
| P1275 | Fuel Pump Fault |
| P1601 | ECU Safety Monitoring - Fault |
| P1602 | ECU Safety Monitoring - Fault |
| P1604 | ECU Safety Monitoring - Fault |
| P1606 | ECU Safety Monitoring - Fault |
| P1607 | ECU Safety Monitoring - Fault |
| P160B | ECU Safety Monitoring - Fault |
| P160C | ECU Safety Monitoring - Fault |
| P1611 | ECU Safety Monitoring - Fault |
| P1612 | ECU Safety Monitoring - Fault |
| P1620 | ECU Safety Monitoring - Fault |
| P1621 | ECU Safety Monitoring - Fault |
| P1622 | ECU Safety Monitoring - Fault |
| P1623 | ECU Safety Monitoring - Fault |
| P1624 | ECU Safety Monitoring - Fault |
| P1625 | ECU Safety Monitoring - Fault |
| P1626 | ECU Safety Monitoring - Fault |
| P1627 | ECU Safety Monitoring - Fault |
| P162B | ECU Safety Monitoring - Fault |
| P1630 | ECU Safety Monitoring - Fault |
| P1631 | ECU Safety Monitoring - Fault |
| P1632 | ECU Safety Monitoring - Fault |
| P1633 | ECU Safety Monitoring - Fault |
| P1634 | ECU Safety Monitoring - Fault |
| P1635 | ECU Safety Monitoring - Fault |
| P1636 | ECU Safety Monitoring - Fault |
| P1637 | ECU Safety Monitoring - Fault |
| P1638 | ECU Safety Monitoring - Fault |
| P1660 | ECU Safety Monitoring - Fault |
| P1661 | ECU Safety Monitoring - Fault |
| P1662 | ECU Safety Monitoring - Fault |
| P1663 | ECU Safety Monitoring - Fault |
| P1690 | ECU Safety Monitoring - Fault |
| P1691 | ECU Safety Monitoring - Fault |
| P1692 | ECU Safety Monitoring - Fault |
| P16D2 | ECU Safety Monitoring - Fault |
| P16D6 | ECU Safety Monitoring - Fault |
| P16D8 | ECU Safety Monitoring - Fault |
| P1990 | ECU - Fault |
| P2080 | Turbo Temperature Fault |
| P2081 | Turbo Temperature Sensor Fault |
| P2108 | Intake Throttle - Fault |
| P2131 | Throttle Position Sensor Fault |
| P2143 | EGR Motor - Fault |
| P2144 | EGR Motor - Fault |
| P2145 | EGR Motor - Fault |
| P2146 | Injector #1 and #4 Fault |
| P2147 | Injector #1 and #4 Fault |
| P2148 | Injector #1 and #4 Fault |
| P2149 | Injector #2 and #3 Fault |
| P2150 | Injector #2 and #3 Fault |
| P2151 | Injector #2 and #3 Fault |
| P2226 | Barometric Pressure Fault |
| P2228 | Barometric Pressure Fault |
| P2229 | Barometric Pressure Fault |
| P2264 | Water in Fuel Sensor Fault |
| P2266 | Water in Fuel Sensor Fault |
| P2267 | Water in Fuel Sensor Fault |
| P2413 | EGR Actuator - Fault |
| P2414 | EGR Motor - Fault |
| P2415 | EGR Temperature Sensor - Fault |
| P2428 | Exhaust Over Temperature Fault |
| P242B | SCR Inlet Temperature Sensor Fault |
| P242C | EGR Temperature Sensor - Fault |
| P242D | EGR Temperature Sensor - Fault |
| P2463 | SCR Fault |
| P2621 | Intake Throttle Lift Sensor - Fault |
| P2622 | Intake Throttle Lift Sensor - Fault |
| P2BB1 | SCR Inducement - Blocked EGR |
| P2BB2 | SCR Inducement - Dosing Interrupted |
| P2BB4 | SCR Inducement - DEF Quality |
| P2BB5 | SCR Inducement - Tampering |
| P2BB6 | SCR Inducement - Repeat Offense |
| P2BC1 | DEF Level - Low |
| P2BC2 | DEF Level - Very Low |
| P2BC3 | DEF Level - Extremely Low |
| P2BC4 | Unknown SCR fault |
| P2BC4 | DEF Level - Empty |
| P2BD0 | DCU CAN Communication Fault |
| P3002 | Exhaust Temperature - Extremely High |
| P3003 | Exhaust Temperature - Extremely High |
| P3004 | Exhaust Temperature - Extremely High |
| P3006 | Particulate Matter - Warning |
| P3007 | Particulate Matter - High |
| P3008 | Particulate Matter - Extremely High |
| P3011 | Boost Pressure - Fault |
| P3012 | Low Water Temperature in Parked Regeneration |
| P3013 | Parked Regeneration - Time Out |
| P3018 | Exhaust Temperature Sensor - Fault |
| P3019 | Pump Calibration - Error |
| P3023 | Exhaust Gas Temperature Sensor - Fault |
| P3024 | DPF Fault |
| P3025 | Water Temp Sensor Fault |
| U0075 | ECU Communication Error |
| U0076 | EGR Fault |
| U0077 | ECU COMMUNICATION FAULT |
| U0081 | ECU Communication Error |
| U0082 | ECU Communication - Fault |
| U0083 | ECU Communication - Fault |
| U0084 | ECU COMMUNICATION FAULT |
| U0085 | ECU Communication - Fault |
| U0086 | ECU Communication - Fault |
| U0087 | ECU COMMUNICATION FAULT |
| U0089 | ECU COMMUNICATION FAULT |
| U0100 | ECU Communication Fault |
| U0140 | Throttle Position Sensor Fault |
ECU Bobcat Engine V2 396
| Fault Code | Description |
|---|---|
| P0002 | Fuel Rail Pressure Fault |
| P0003 | Fuel Rail Pressure Fault |
| P0004 | Fuel Rail Pressure Fault |
| P000F | Fuel Rail Pressure High - Over Relief |
| P0072 | Engine Compartment Temperature Sensor Out of Range Low |
| P0073 | Engine Compartment Temperature Sensor Out of Range High |
| P007C | Inlet Air Temperature Sensor Out of Range Low |
| P007D | Inlet Air Temperature Sensor Out of Range High |
| P0087 | Fuel Rail Pressure Fault |
| P009B | Common Rail Pressure Relief Valve Open Count Exceeds Limit |
| P009C | Common Rail Pressure Relief Valve Opened |
| P009D | Common Rail Pressure Relief Valve Opened |
| P009F | High Rail Pressure |
| P00AC | Intake Manifold Temperature Sensor Out of Range Low |
| P00AD | Intake Manifold Temperature Sensor Out of Range High |
| P00BC | Low Manifold Absolute Pressure (Low boost) |
| P00BE | Air Flow Fault (MAF / MAP agreement) |
| P0100 | Mass Air Flow Sensor Short to Battery or Open Circuit |
| P0101 | Mass Air Flow Sensor Electrical Fault |
| P0102 | Mass Air Flow Sensor Out of Range Low |
| P0103 | Mass Air Flow Sensor Out of Range High |
| P0107 | Manifold Absolute Pressure Sensor Out of Range Low |
| P0108 | Manifold Absolute Pressure Sensor Out of Range High |
| P0117 | Coolant Temperature Sensor Out of Range Low |
| P0118 | Coolant Temperature Sensor Out of Range High |
| P011E | Coolant Temperature Low Fault |
| P0121 | Engine Speed Control Signal Fault |
| P0122 | Engine Speed Control Signal Fault |
| P0123 | Engine Speed Control Signal Fault |
| P0124 | Engine Speed Control Signal Fault |
| P0182 | Fuel Temperature Sensor Out of Range Low |
| P0183 | Fuel Temperature Sensor Out of Range High |
| P018C | Low Fuel Filter Pressure |
| P018D | High Fuel Filter Pressure |
| P018F | Common Rail Pressure Relief Valve Open Time Exceeds Limit |
| P0192 | Rail Pressure Sensor Out of Range Low |
| P0193 | Rail Pressure Sensor Out of Range High |
| P0196 | Oil Level/Temp Sensor Fault |
| P01C2 | Fuel Filter Pressure Sensor Out of Range Low |
| P01C4 | Low Fuel Filter Pressure Warning |
| P01C5 | Low Fuel Filter Pressure - Derate |
| P01C6 | Fuel Filter Pressure Sensor Out of Range High |
| P0201 | Injector #1 Open Circuit |
| P0202 | Injector #2 Open Circuit |
| P0203 | Injector #3 Open Circuit |
| P0204 | Injector #4 Open Circuit |
| P0215 | Engine Shutoff Request Signal Detected |
| P0218 | CAN Communication Fault - Transmission Oil Temperature |
| P0219 | Engine Overspeed Detected |
| P0221 | Engine Speed Control Signal Fault |
| P0222 | Engine Speed Control Signal Fault |
| P0223 | Engine Speed Control Signal Fault |
| P0224 | Engine Speed Control Signal Fault |
| P0252 | Low Fuel Rail Pressure |
| P0254 | Fuel Rail Pressure Control Fault |
| P025A | Fuel Metering Unit Open Circuit |
| P025B | Fuel Metering Unit Fault |
| P025C | Fuel Metering Unit Short to Ground |
| P025D | Fuel Metering Unit Short to Battery |
| P028A | Fan PWM Open Circuit |
| P028D | Fan PWM Short to Ground |
| P028E | Fan PWM Short to Battery |
| P02E0 | Air Control Valve H-Bridge Drive Open Circuit |
| P02E2 | Air Control Valve H-Bridge Drive Short to Ground |
| P02E3 | Air Control Valve H-Bridge Drive Short to Battery |
| P02E4 | Air Control Valve Position Fault |
| P02E5 | Air Control Valve Position Fault |
| P02E7 | Air Control Valve Close Position Fault |
| P02E8 | Air Control Valve Sensor Out of Range Low |
| P02E9 | Air Control Valve Sensor Out of Range High |
| P02EA | Air Control Valve Close Position Fault |
| P02EB | Air Control Valve Close Position Fault |
| P02EE | Injector #1 Short Circuit |
| P02EF | Injector #2 Short Circuit |
| P02F0 | Injector #3 Short Circuit |
| P02F1 | Injector #4 Short Circuit |
| P0340 | Cam Sensor Signal Fault |
| P0342 | Cam Sensor Signal Fault |
| P0344 | Cam Sensor Signal Fault |
| P0372 | Crank Sensor Signal Fault |
| P0374 | Crank Sensor Signal Fault |
| P0380 | Glow Plug Relay Open Circuit |
| P0381 | Glow Plug Lamp Open Circuit |
| P0383 | Glow Plug Relay Short to Ground |
| P0384 | Glow Plug Relay Short to Battery |
| P0406 | EGR Position Sensor Out of Range High |
| P0407 | EGR Position Sensor Out of Range Low |
| P0408 | EGR Flow Rate Error |
| P0421 | DOC Efficiency Fault (During Regen) |
| P042E | EGR Control Position Fault |
| P042F | EGR Control Position Fault |
| P049B | EGR Flow Rate Error |
| P0512 | Engine Start Switch Stuck On |
| P0522 | Engine Oil Pressure Sensor Out of Range Low |
| P0523 | Engine Oil Pressure Sensor Out of Range High |
| P0527 | Fan Speed Timeout Fault |
| P0528 | Cooling Fan Overspeed |
| P0529 | Cooling Fan Underspeed |
| P0544 | Turbine Inlet Temperature Fault |
| P0545 | Turbine Inlet Temperature Sensor Out of Range Low |
| P0546 | Turbine Inlet Temperature Sensor Out of Range High |
| P055B | Oil Pressure Warning Lamp Open Circuit |
| P055C | Oil Pressure Warning Lamp Short to Ground |
| P055D | Oil Pressure Warning Lamp Short to Battery |
| P0562 | ECU Battery Voltage Extremely Low |
| P0563 | ECU Battery Voltage Extremely High |
| P056D | DEF Supply Module Communication Fault |
| P0591 | PTO Lamp Open Circuit |
| P0592 | PTO Lamp Short to Ground |
| P0593 | PTO Lamp Short to Battery |
| P05ED | DEF Heater Line Short to Battery |
| P060B | ECU Calculation Error |
| P060C | ECU Communication Fault |
| P0615 | Starter Relay Open Circuit |
| P0616 | Starter Relay Short to Ground |
| P0617 | Starter Relay Short to Battery |
| P062D | Injector Bank Short Circuit 1 |
| P062E | Injector Bank Short Circuit 2 |
| P062F | ECU Data Read Fault |
| P0630 | ECU Data Write Fault |
| P0641 | ECU 5V Sensor Supply Voltage Out of Range High |
| P0642 | ECU 5V Sensor Supply Voltage Out of Range Low |
| P0657 | ECU Sensor Supply 1 Short to Ground |
| P0658 | ECU Sensor Supply 1 Voltage Low |
| P0659 | ECU Sensor 1 Voltage High |
| P0669 | High ECU Temperature |
| P0685 | ECU Main Relay Fault |
| P068A | ECU Main Relay Fault |
| P06AD | ECU Temperature Sensor Short to Ground |
| P06AE | ECU Temperature Sensor Short to Battery |
| P06F0 | DEF Supply Module Fault |
| P06F1 | DEF Supply Module Fault |
| P0C17 | EGR Closed Position Fault |
| P0C18 | EGR Closed Position Fault |
| P0C19 | EGR Closed Position Fault |
| P1013 | Engine Speed Fault |
| P101A | ECU Internal Fault |
| P1033 | High DPF Inlet Temperature |
| P1044 | DEF Tank Temperature Sensor Error Low |
| P1045 | DEF Tank Temperature Sensor Error High |
| P106C | Low DEF Quality |
| P106D | High DEF Quality |
| P1073 | High Engine Compartment Temperature |
| P107D | High Inlet Air Temperature |
| P108A | DEF Supply Pump Motor Speed Fault |
| P108B | DEF Supply Pump Motor Speed Fault |
| P108C | DEF Supply Pump Motor Fault |
| P10AD | High Intake Manifold Temperature |
| P1118 | High Engine Coolant Temp |
| P1183 | High Fuel Temperature |
| P1227 | Low DEF Tank Temperature Fault |
| P1230 | DEF Tank Level Signal Error |
| P12E5 | EGR Fault - Level 1 Inducement |
| P12E6 | EGR Fault - Level 2 Inducement |
| P12E7 | EGR Fault - Level 3 Inducement |
| P12E8 | EGR Fault - Warning |
| P12E9 | SCR Dosing Interrupted - Level 1 Inducement |
| P12EA | SCR Dosing Interrupted - Level 2 Inducement |
| P12EB | SCR Dosing Interrupted - Level 3 Inducement |
| P12EC | SCR Dosing Interrupted - Warning |
| P12F2 | DEF Quality - Level 1 Inducement |
| P12F3 | DEF Quality - Level 2 Inducement |
| P12F4 | DEF Quality - Level 3 Inducement |
| P12F5 | DEF Quality - Warning |
| P12F6 | SCR Tampering - Level 1 Inducement |
| P12F7 | SCR Tampering - Level 2 Inducement |
| P12F8 | SCR Tampering - Level 3 Inducement |
| P12F9 | SCR Tampering - Warning |
| P1303 | SCR Fault Repeat Offense - Level 1 Inducement |
| P1304 | SCR Fault Repeat Offense - Level 2 Inducement |
| P1305 | SCR Fault Repeat Offense - Level 3 Inducement |
| P1450 | High DEF Pump Pressure |
| P1451 | Low DEF Pump Pressure |
| P1452 | High DEF Pump Pressure |
| P1453 | DEF Pump Pressure Stabilization Fault |
| P1454 | Low DPF Differential Pressure |
| P1457 | Low DEF Pump Pressure |
| P1459 | DEF Pressure Reduction Fault |
| P1460 | DEF Afterrun Error |
| P1461 | DEF Reverting Valve Pressure Fault |
| P1522 | Low Engine Oil Pressure |
| P1546 | High Turbine Inlet Temperature |
| P1562 | ECU Battery Voltage Low |
| P1563 | ECU Battery Voltage High |
| P1564 | ECU Battery Voltage Extremely High |
| P1565 | ECU Battery Voltage Extremely Low |
| P160B | ECU Internal Fault |
| P160C | ECU Internal Fault |
| P160D | ECU Internal Fault |
| P160E | ECU Internal Fault |
| P160F | ECU Memory Fault |
| P1610 | ECU Internal Fault |
| P1611 | ECU Internal Fault |
| P1612 | ECU Internal Fault |
| P1613 | ECU Internal Fault |
| P1614 | ECU Internal Fault |
| P1615 | ECU Internal Fault |
| P1616 | ECU Internal Fault |
| P1617 | ECU Internal Fault |
| P1618 | ECU Internal Fault |
| P1619 | ECU Internal Fault |
| P1657 | ECU Sensor Suplly 1 Voltage Fault |
| P1669 | ECU Sensor Supply 2 Voltage Fault |
| P1684 | ECU Sensor Suplly 3 Voltage Fault |
| P1893 | DEF Backflow Line Pressure Fault |
| P1904 | Glow Plug Lamp Short to Ground |
| P1906 | DPF Regeneration Switch Inhibit Lamp Open Circuit |
| P1907 | DPF Regeneration Switch Inhibit Lamp Short to Ground |
| P1908 | DPF Regeneration Switch Inhibit Lamp Short to Battery |
| P190B | High Fuel Rail Pressure |
| P190C | Low Fuel Rail Pressure |
| P192E | Check Engine Lamp Open Circuit |
| P192F | Check Engine Lamp Short to Ground |
| P1931 | Check Engine Lamp Short to Battery |
| P1934 | Pressure Relief Valve Fault |
| P202D | DEF Leakage Fault |
| P202E | DEF Dosing Valve Error |
| P2032 | DPF Inlet Temperature Sensor Out of Range Low |
| P2033 | DPF Inlet Temperature Sensor Out of Range High |
| P2034 | DPF Inlet Temperature Fault |
| P203A | DEF Level Sensor Open Circuit |
| P203F | DEF Tank Empty |
| P2041 | DEF Level Sensor Short Circuit |
| P2043 | DEF Temperature Sensor Open Circuit |
| P2046 | DEF Temperature Sensor Short Circuit |
| P2047 | DEF Dosing Valve Short to Battery |
| P2048 | DEF Dosing Valve Short to Ground |
| P2049 | DEF Dosing Valve Open Circuit |
| P204A | DEF Pressure Fault |
| P204C | DEF Supply Pump Pressure Sensor Out of Range Low |
| P204D | DEF Supply Pump Pressure Sensor Out of Range High |
| P2050 | DEF Dosing Valve Short to Battery |
| P2051 | DEF Dosing Valve Short to Ground |
| P205E | High DEF Tank Temperature |
| P208A | DEF Supply Pump Motor Open Circuit |
| P208B | DEF Supply Pump Motor Signal Error |
| P208C | DEF Supply Pump Motor Short to Ground |
| P208D | DEF Supply Pump Motor Short to Battery |
| P208E | DEF Dosing Valve Blocked |
| P20A0 | DEF Reverting Valve Open Circuit |
| P20A1 | High DEF Reverting Valve Temperature |
| P20A2 | DEF Reverting Valve Short to Ground |
| P20A3 | DEF Reverting Valve Short to Battery |
| P20A5 | DEF Reverting Valve Pressure Fault |
| P20AC | DEF Supply Module Heater Fault |
| P20AD | DEF Supply Module Heater Fault |
| P20B0 | DEF Supply Module Temperature Fault |
| P20B1 | DEF Tank Heater Valve Open Circuit |
| P20B3 | DEF Tank Heater Valve Short to Ground |
| P20B4 | DEF Tank Heating/Coolant Valve Short to Battery |
| P20B9 | DEF Supply Module Heater Relay Open Circuit |
| P20BA | DEF Supply Module Heater Fault |
| P20BB | DEF Supply Module Heater Relay Short to Ground |
| P20BC | DEF Supply Module Heater Relay Short to Battery |
| P20BD | DEF Pressure Line Heater Relay Open Circuit |
| P20BE | DEF Pressure Line Heater Fault |
| P20BF | DEF Pressure Line Heater Relay Short to Ground |
| P20C0 | DEF Pressure Line Heater Relay Short to Battery |
| P20C1 | DEF Backflow Line Heater Relay Open Circuit |
| P20C2 | DEF Backflow Line Heater Fault |
| P20C3 | DEF Backflow Line Heater Relay Short to Ground |
| P20C4 | DEF Backflow Line Heater Relay Short to Battery |
| P20C5 | DEF Suction Line Heater Relay Open Circuit |
| P20C6 | DEF Suction Line Heater Fault |
| P20C7 | DEF Suction Line Heater Relay Short to Ground |
| P20C8 | DEF Suction Line Heater Relay Short to Battery |
| P20EE | SCR Efficiency Low |
| P20FF | DEF Supply Module Communication Timeout |
| P2135 | Engine Speed Control Signal Fault |
| P2136 | Engine Speed Control Signal Fault |
| P213E | ECU Internal Shutdown |
| P2143 | EGR H-Bridge Driver Open Circuit |
| P2144 | EGR H-Bridge Driver Short to Ground |
| P2145 | EGR H-Bridge Driver Short to Battery |
| P214F | DEF Supply Module Heater Open Circuit |
| P215E | DEF Suction Line Heater SC/STG Fault |
| P215F | DEF Suction Line Heater Open Circuit |
| P21C2 | DEF Main Heater Relay Open Circuit |
| P21C3 | DEF Main Heater Relay Short to Ground |
| P21C4 | DEF Main Heater Relay Short to Battery |
| P21C7 | SCR System Main Relay Fault |
| P21C8 | SCR System Main Relay Short to Ground |
| P21C9 | SCR System Main Relay Short to Battery |
| P21DD | DEF Supply Module Heater Short to Ground |
| P2202 | Upstream NOx Sensor Short Circuit |
| P2203 | Upstream NOx Sensor Open Circuit |
| P2215 | Downstream NOx Sensor Short Circuit |
| P2216 | Downstream NOx Sensor Open Circuit |
| P221C | DEF Pressure Line Heater Electrical Fault |
| P221D | DEF Pressure Line Heater Open Circuit |
| P221E | DEF Backflow Line Heater Electrical Fault |
| P221F | DEF Backflow Line Heater Open Circuit |
| P2228 | Atmospheric Pressure Low Fault |
| P2229 | Atmospheric Pressure High Fault |
| P225D | Low Upstream NOx Concentration |
| P2265 | Water in Fuel Detected - Derate |
| P2266 | Water in Fuel Sensor Out of Range Low |
| P2267 | Water in Fuel Sensor Out of Range High |
| P2269 | Water in Fuel Detected |
| P2381 | Glow Plug Lamp Short to Battery |
| P2383 | Upstream NOx Sensor Installation Fault |
| P2384 | Downstream NOx Sensor Installation Fault |
| P2397 | Upstream NOx Concentration Low |
| P2398 | Downstream NOx Concentration Low |
| P23B2 | DEF Supply Module Heater Fault |
| P23B3 | DEF Supply Module Heater Temperature Fault |
| P23B4 | DEF Supply Module Heater Temperature Fault |
| P23B5 | DEF Supply Module Temperature Fault |
| P23B6 | DEF Supply Module Temperature Fault |
| P242F | High DPF Ash Content - Ash Cleaning Needed |
| P2454 | DPF Differential Pressure Sensor Out of Range Low |
| P2455 | DPF Differential Pressure Sensor Out of Range High |
| P2463 | High DPF Soot Mass - Regen Required |
| P246B | DPF Regeneration Failure |
| P246C | High DPF Differential Pressure - DPF Plugged |
| P24A3 | Very High DPF Soot Mass - Service Regen Required |
| P2505 | High ECU Temperature |
| P2506 | ECU Software Reset |
| P2507 | ECU Internal Fault |
| P2508 | ECU Internal Fault |
| P2509 | ECU Internal Fault |
| P250A | Oil Level/Temp Sensor Open Circuit |
| P250C | Oil Level/Temp Sensor Short to Ground |
| P250D | Oil Level/Temp Sensor Short to Battery |
| P250F | Check Engine Oil Level |
| P2511 | ECU Internal Fault |
| P2546 | Multi-Torque Switch Out of Range Low |
| P2547 | Multi-Torque Switch Out of Range High |
| P25BA | DPF Regeneration Inhibit and Enable Switch Fault |
| P25BB | DPF Regeneration Enable Switch Short to Battery |
| P25BC | DPF Regeneration Inhibit Switch Short to Battery |
| P260E | DPF Regeneration Enable Switch Lamp Open Circuit |
| P260F | DPF Regeneration Enable Switch Lamp Short to Ground |
| P2611 | DPF Regeneration Enable Switch Lamp Short to Battery |
| P2632 | Fuel Feed Pump Open Circuit |
| P2633 | Fuel Feed Pump Short to Ground |
| P2634 | Fuel Feed Pump Short to Battery |
| P2635 | Fuel Feed Pump Fault |
| P263D | DEF Pressure Line Heating Fault |
| P2669 | ECU Sensor Supply 2 Short to Ground |
| P2670 | ECU Sensor Supply 2 Out of Range Low |
| P2671 | ECU Sensor Supply 2 Out of Range High |
| P2684 | ECU Sensor Supply 3 Short to Ground |
| P2685 | ECU Sensor Supply 3 Out of Range Low |
| P2686 | ECU Sensor 3 Out of Range High |
| P268C | Injector #1 IQA Code Missing |
| P268D | Injector #2 IQA Code Missing |
| P268E | Injector #3 IQA Code Missing |
| P268F | Injector #4 IQA Code Missing |
| P273F | High Transmission Oil Temperature (CAN) |
| P274F | High Transmission Oil Temperature (H/W Switch) |
| P2C11 | DEF Dosing Valve Fault |
| P304C | Low DEF Supply Pump Pressure |
| P304D | High DEF Supply Pump Pressure |
| P3052 | DPF Differential Pressure Sensor Fault |
| P30B1 | High DEF Tank Heating/Coolant Valve Fault |
| P30B9 | High DEF Supply Module Heater Relay Fault |
| P30BD | High DEF Pressure Line Heater Relay Fault |
| P30C1 | High DEF Backflow Line Heater Relay Fault |
| P30C5 | High DEF Suction Line Heater Relay Fault |
| P31C5 | High DEF Main Heater Relay Fault |
| P32EE | Injector #1 Short Circuit |
| P32EF | Injector #2 Short Circuit |
| P32F0 | Injector #3 Short Circuit |
| P32F1 | Injector #4 Short Circuit |
| P350D | Oil Level/Temp Sensor Communication Fault |
| P350E | Oil Level/Temp Sensor Fault |
| P350F | Low Engine Oil Level |
| P360E | DPF Regeneration Active Lamp Open Circuit |
| P360F | DPF Regeneration Active Lamp Short to Ground |
| P3611 | DPF Regeneration Active Lamp Short to Battery |
| U0028 | ECU CAN Communication Fault |
| U0029 | ECU CAN Communication Fault |
| U010F | ECU CAN Communication Fault |
| U013C | ECU CAN Communication Fault - Engine Speed |
| U01B7 | ECU CAN Communication Fault - Regeneration Switch |
| U01B8 | ECU CAN Communication Fault - Multiple Torque Switch |
| U01B9 | ECU CAN Communication Fault - Engine Shut Down |
| U029D | ECU CAN Communication Fault - Upstream NOx Sensor |
| U029E | ECU CAN Communication Fault - Downstream NOx Sensor |
| U02A2 | ECU CAN Communication Fault - DEF Tank |
| U030D | Upstream NOx Sensor Heating Fault |
| U030E | Downstream NOx Sensor Heating Fault |
| U043D | ECU CAN Communication Fault - Engine Speed Control |
| U0606 | ECU CAN Communication Fault - Engine Speed Control |
| U0607 | ECU CAN Communication Fault |
| U0608 | ECU CAN Communication Fault - Engine Speed Control |
| U0619 | ECU CAN Communication Fault - DEF Sensor |
| U0632 | ECU CAN Communication Fault - Cooling Fan Control |
| U1001 | CAN Communication Fault - Hydraulic Oil Temperature |
| U1003 | ECU Received Engine Shutdown Request from Machine Controller |
| U1028 | DEF Quality Sensor Open Circuit |
| U1030 | DEF Quality Sensor Short Circuit |
| U1031 | ECU CAN Communication Fault |
| U1032 | ECU CAN Communication Fault - PTO |
| U1033 | ECU CAN Communication Fault - Starter Relay |
M-Series Excavator 211
| Fault Code | Description |
|---|---|
| H0104 | Boom Angle Sensor No Communication |
| H0204 | Arm Angle Sensor No Communication |
| H0304 | Bucket Angle Sensor No Communication |
| H0405 | Angle Sensor Supply Short To Battery |
| H0406 | Angle Sensor Supply Short To Ground |
| H0407 | Angle Sensor Supply Open Circuit |
| H0705 | Aux 4 Base Short to Battery |
| H0706 | Aux 4 Base Short to Ground |
| H0707 | Aux 4 Base Open Circuit |
| H0732 | Aux 4 Base Overcurrent |
| H0805 | Aux 4 Rod Short to Battery |
| H0806 | Aux 4 Rod Short to Ground |
| H0807 | Aux 4 Rod Open Circuit |
| H0832 | Aux 4 Rod Overcurrent |
| H0905 | Direct To Tank Short to Battery |
| H0906 | Direct to Tank Short to Ground |
| H0907 | Direct to Tank Open Circuit |
| H0932 | Direct to Tank Overcurrent |
| H2521 | Angle Blade Control Switch Out Of Range High |
| H2522 | Angle Blade Control Switch Out Of Range Low |
| H2524 | Angle Blade Control Switch Out Of Neutral |
| H2605 | Angle Blade Base Solenoid Short To Battery |
| H2606 | Angle Blade Base Solenoid Short To Ground |
| H2607 | Angle Blade Base Solenoid Open Circuit |
| H2632 | Angle Blade Base Solenoid Overcurrent |
| H2705 | Angle Blade Rod Solenoid Short To Battery |
| H2706 | Angle Blade Rod Solenoid Short To Ground |
| H2707 | Angle Blade Rod Solenoid Open Circuit |
| H2732 | Angle Blade Rod Solenoid Overcurrent |
| H2805 | Diverter Output Short To Battery |
| H2806 | Diverter Output Short To Ground |
| H2807 | Diverter Output Open Circuit |
| H2832 | Diverter Output Overcurrent |
| H2848 | Diverter Multiple Input |
| H3904 | Left Joystick In Error |
| H3912 | Left Joystick Thumb Switch Not In Neutral |
| H3916 | Left Joystick No Communication |
| H3928 | Left Joystick Internal Failure |
| H4423 | Secondary Not Programmed |
| H4497 | Secondary Controller Programmed |
| H4621 | 5 Volt Sensor Supply Out Of Range High |
| H4622 | 5 Volt Sensor Supply Out Of Range Low |
| H4721 | 8 Volt Sensor Supply Out Of Range High |
| H4722 | 8 Volt Sensor Supply Out Of Range Low |
| H5705 | Angle Blade Aux 4 Base Short to Battery |
| H5706 | Angle Blade Aux 4 Base Short to Ground |
| H5707 | Angle Blade Aux 4 Base Open Circuit |
| H5732 | Angle Blade Aux 4 Base Overcurrent |
| H5805 | Angle Blade Aux 4 Rod Short to Battery |
| H5806 | Angle Blade Aux 4 Rod Short to Ground |
| H5807 | Angle Blade Aux 4 Rod Open Circuit |
| H5832 | Angle Blade Aux 4 Rod Overcurrent |
| H7604 | Display No Communication |
| H7902 | Door Unlock Error On |
| H7903 | Door Unlock Error Off |
| H8002 | Door Lock Error On |
| H8003 | Door Lock Error Off |
| L0102 | Lights Button Error On |
| L0202 | High Flow Enable Button Error On |
| L0302 | Auxiliary Enable Button Error On |
| L0402 | Information Button Error On |
| L7404 | Information Button Error On |
| L7672 | Information Button Error On |
| M0216 | Hydraulic/hydrostatic Filter Not Connected |
| M0217 | Hydraulic/hydrostatic Filter Plugged |
| M0322 | System Voltage Out Of Range Low |
| M0415 | Engine Oil Pressure In Shutdown |
| M0615 | Engine Speed In Shutdown |
| M0618 | Engine Speed Out Of Range |
| M0710 | Hydraulic Oil Temp Too High |
| M0711 | Hydraulic Oil Temp Extremely High |
| M0715 | Hydraulic Oil Temp In Shutdown |
| M0721 | Hydraulic Oil Temp Out Of Range High |
| M0722 | Hydraulic Oil Temp Out Of Range Low |
| M0810 | Engine Coolant Temp Too High |
| M0811 | Engine Coolant Temp Extremely High |
| M0815 | Engine Coolant Temp In Shutdown |
| M0821 | Engine Coolant Temp Out Of Range High |
| M0822 | Engine Coolant Temp Out Of Range Low |
| M0826 | Engine Coolant Temp Out Of Range Low |
| M0921 | Fuel Level Out Of Range High |
| M0922 | Fuel Level Out Of Range Low |
| M1121 | Console Sensor Out Of Range High |
| M1122 | Console Sensor Out Of Range Low |
| M1128 | Console Sensor Failure |
| M1305 | Fuel Hold Solenoid Short To Battery |
| M1306 | Fuel Hold Solenoid Short To Ground |
| M1402 | Fuel Pull Solenoid Error On |
| M1403 | Fuel Pull Solenoid Error Off |
| M1407 | Fuel Pull Solenoid Open Circuit |
| M1428 | Fuel Pull Solenoid Failure |
| M1605 | Hydraulic Bypass Short to Battery |
| M1606 | Hydraulic Bypass Short to Ground |
| M1607 | Hydraulic Bypass Open Circuit |
| M1632 | Hydraulic Bypass Overcurrent |
| M1705 | Hydraulic Lock Valve Short To Battery |
| M1706 | Hydraulic Lock Valve Short To Ground |
| M1707 | Hydraulic Lock Valve Open Circuit |
| M1732 | Hydraulic Lock Valve Overcurrent |
| M1802 | Power Beyond Valve Output Error On |
| M1803 | Power Beyond Valve Output Error Off |
| M1902 | Power Beyond Valve Relay Error On |
| M1903 | Power Beyond Valve Relay Error Off |
| M2005 | Two Speed Primary Solenoid Short To Battery |
| M2006 | Two Speed Primary Solenoid Short To Ground |
| M2007 | Two Speed Primary Solenoid Open Circuit |
| M2521 | Load Sense Sensor Out Of Range High |
| M2522 | Load Sense Sensor Out Of Range Low |
| M2721 | Throttle Primary Sensor Out Of Range High |
| M2722 | Throttle Primary Sensor Out Of Range Low |
| M2805 | Diverter Output Short To Battery |
| M2806 | Diverter Output Short To Ground |
| M2807 | Diverter Output Open Circuit |
| M3204 | Throttle Controller No Communication To Bobcat Controller |
| M3223 | Throttle Controller Not Calibrated |
| M3228 | Throttle Controller Failure |
| M3299 | Throttle Controller Calibration In Process |
| M3304 | Deluxe Panel No Communication |
| M3372 | Display Software Incompatible |
| M3373 | Display Software Outdated |
| M3702 | HYD Exchange Output Error On |
| M3703 | HYD Exchange Output Error Off |
| M3904 | Jog Shuttle No Communication |
| M4109 | Alternator Voltage Too Low |
| M4110 | Alternator Voltage High |
| M4204 | Keyless Entry No Communication |
| M4404 | Secondary No Communication |
| M4472 | Secondary Controller Software Incompatible |
| M4473 | Secondary Controller Software Outdated |
| M4621 | 5 Volt Sensor Supply Out Of Range High |
| M4622 | 5 Volt Sensor Supply Out Of Range Low |
| M4721 | 8 Volt Sensor Supply Out Of Range High |
| M4722 | 8 Volt Sensor Supply Out Of Range Low |
| M5205 | Offset Base Solenoid Short To Battery |
| M5206 | Offset Base Solenoid Short To Ground |
| M5207 | Offset Base Solenoid Open Circuit |
| M5232 | Offset Base Solenoid Overcurrent |
| M5305 | Offset Rod Solenoid Error On |
| M5306 | Offset Rod Solenoid Short To Ground |
| M5307 | Offset Rod Solenoid Open Circuit |
| M5332 | Offset Rod Solenoid Overcurrent |
| M5421 | Offset Control Switch Out Of Range High |
| M5422 | Offset Control Switch Out Of Range Low |
| M5424 | Offset Control Switch Out Of Neutral |
| M5505 | Auxiliary Base Solenoid Short To Battery |
| M5506 | Auxiliary Base Solenoid Short To Ground |
| M5507 | Auxiliary Base Solenoid Open Circuit |
| M5532 | Auxiliary Base Solenoid Overcurrent |
| M5605 | Auxiliary Rod Solenoid Short To Battery |
| M5606 | Auxiliary Rod Solenoid Short To Ground |
| M5607 | Auxiliary Rod Solenoid Open Circuit |
| M5632 | Auxiliary Rod Solenoid Overcurrent |
| M5721 | Auxiliary Control Switch Out Of Range High |
| M5722 | Auxiliary Control Switch Out Of Range Low |
| M5724 | Auxiliary Control Switch Out Of Neutral |
| M5811 | Fuel Temperature Extremely High |
| M5815 | Fuel Temperature In Shutdown |
| M5826 | Fuel Temperature In Shutdown |
| M6021 | Left Control Switch Out of Range High |
| M6022 | Left Control Switch Out of Range Low |
| M6024 | Left Control Switch Out of Neutral |
| M6121 | Right Control Switch Out of Range High |
| M6122 | Right Control Switch Out of Range Low |
| M6124 | Right Control Switch Out of Neutral |
| M6204 | Load Moment Sensor In Error |
| M6221 | Overload Warning Sensor Out of Range High |
| M6222 | Overload Warning Sensor Out of Range Low |
| M6505 | ECU Power Short To Battery |
| M6506 | ECU Power Short To Ground |
| M6905 | Dump Valve Short to Battery |
| M6906 | Dump Valve Short to Ground |
| M6907 | Dump Valve Open Circuit |
| M6932 | Dump Valve Overcurrent |
| M7472 | Main Controller Software Incompatible |
| M7473 | Main Controller Software Outdated |
| M7497 | Main Controller Controller Programmed |
| M7604 | Standard Display Panel No Communication |
| M8004 | Cooling Fan Controller No Communication |
| M8005 | Cooling Fan Short To Battery |
| M8006 | Cooling Fan Short To Ground |
| M8021 | Cooling Fan Out Of Range High |
| M8022 | Cooling Fan Out Of Range Low |
| M8025 | Cooling Fan Unresponsive |
| M8027 | Cooling Fan CAN Error |
| M8028 | Cooling Fan Failure |
| M8029 | Cooling Fan Wiring Fault |
| M8030 | Cooling Fan Controller Fault |
| M8302 | Wait to Start Lamp Error On |
| M8303 | Wait to Start Lamp Error Off |
| M8615 | Engine Speed Derate In Shutdown |
| M9111 | Fuel Filter Extremely Plugged |
| M9117 | Fuel Filter Plugged |
| M9144 | Fuel Filter Derate Level 1 |
| M9145 | Fuel Filter Derate Level 2 |
| M9202 | Fuel Lift Pump Error On |
| M9203 | Fuel Lift Pump Error Off |
| M9287 | Fuel Pump Failure Time Exceeded |
| M9309 | Fuel Pressure Low |
| M9314 | Fuel Pressure Extremely Low |
| M9321 | Fuel Pressure Out Of Range High |
| M9322 | Fuel Pressure Out Of Range Low |
| M9344 | Fuel Pressure Derate Level 1 |
| R3327 | Display CAN Error |
| R3334 | Display CAN Error |
| R3335 | Display CAN Error |
| R3904 | Jog Shuttle No Communication |
| R4304 | Keyless Start Panel No Communication |
| R7404 | Main Controller No Communication |
| R7423 | Display Not Programmed |
| R7492 | Main Controller Authentication Failed |
| R9604 | Radio No Communication |
M-Series Loader 820
| Fault Code | Description |
|---|---|
| A4621 | 5V Sensor Supply Out of Range High |
| A4622 | 5V Sensor Supply Out of Range Low |
| A4721 | 8V Sensor Supply Out of Range High |
| A4722 | 8V Sensor Supply Out of Range Low |
| A7701 | Key Switch Active |
| B1005-00 | Key Switch Multiple |
| B102A-16 | Cab Controller Sensor Supply Voltage Out of Range Low |
| B102A-17 | Cab Controller Sensor Supply Voltage Out of Range High |
| B1030-11 | Front Work Light (Left Side) Short to Ground |
| B1030-12 | Front Work Light (Left Side) Short to Battery |
| B1030-13 | Front Work Light (Left Side) Not Connected |
| B1031-11 | Front Work Light (Right Side) Short to Ground |
| B1031-12 | Front Work Light (Right Side) Short to Battery |
| B1031-13 | Front Work Light (Right Side) Not Connected |
| B1034-12 | Rear Work Lights Error On |
| B1034-14 | Rear Work Lights Error Off |
| B1035-12 | Rear Marker Light Short to Battery |
| B1035-14 | Rear Marker Light Short to Ground or Open Circuit |
| B1036-12 | Rear Tail Lights Error On |
| B1036-14 | Rear Tail Lights Error Off |
| B1037-12 | Stop Lamp Short to Battery |
| B1037-14 | Stop Lamp Short to Ground or Open Circuit |
| B1038-12 | Registration Plate Lamp Short to Battery |
| B1038-14 | Registration Plate Lamp Short to Ground or Open Circuit |
| B1039-11 | Side Lights Short to Ground |
| B1039-12 | Side Lights Short to Battery |
| B1039-13 | Side Lights Not Connected |
| B1040-14 | Buzzer Error Off |
| B1041-12 | Backup Alarm Error On |
| B1041-14 | Backup Alarm Error Off |
| B1042-12 | Horn Relay Short to Battery |
| B1042-14 | Horn Relay Short to Ground or Open Circuit |
| B1050-12 | HVAC Output Short to Battery |
| B1050-14 | HVAC Output Short to Ground or Open Circuit |
| B1051-93 | HVAC Inside Sensor In Error |
| B1052-93 | HVAC Device Sensor In Error |
| B1053-93 | HVAC Coil Sensor In Error |
| B1054-11 | HVAC Clutch Output Error Off |
| B1054-12 | HVAC Clutch Output Error On |
| B1054-13 | HVAC Clutch Output Open Circuit |
| B1054-19 | HVAC Clutch Output Overcurrent |
| B1055-93 | HVAC Water Valve In Error |
| B1060-93 | Lift Pedal In Error |
| B1060-F0 | Lift Pedal Not in Neutral |
| B1061-16 | Lift Pedal Sensor A Out of Range Low |
| B1061-17 | Lift Pedal Sensor A Out of Range High |
| B1062-16 | Lift Pedal Position Sensor "B" Out of Range Low |
| B1062-17 | Lift Pedal Position Sensor "B" Out of Range High |
| B1063-00 | Lift Pedal Sensor In Error |
| B1064-F0 | Lift Joystick Not in Neutral |
| B1065-F0 | Lift Input Not in Neutral |
| B1070-09 | Tilt Pedal Failure |
| B1070-93 | Tilt Pedal In Error |
| B1070-F0 | Tilt Pedal Not in Neutral |
| B1071-16 | Tilt Pedal Sensor A Out of Range Low |
| B1071-17 | Tilt Pedal Sensor A Out of Range High |
| B1072-16 | Tilt Pedal Position Sensor "B" Out of Range High |
| B1072-17 | Tilt Pedal Position Sensor "B" Out of Range Low |
| B1073-00 | Tilt Pedal Sensor In Error |
| B1074-F0 | Tilt Joystick Not in Neutral |
| B1075-F0 | Tilt Input Not in Neutral |
| B1080-09 | Seat Bar Failure |
| B1080-16 | Seat Bar Out of Range Low |
| B1080-17 | Seat Bar Out of Range High |
| B1090-00 | Door Open |
| B1091-16 | Door Sensor Out of Range Low |
| B1095-13 | Window Sensor Open Circuit |
| B1095-16 | Window Sensor Out of Range Low |
| B1095-17 | Window Sensor Out of Range High |
| B1095-95 | Window Sensor Failure |
| B10A0-12 | Wiper Output Short to Battery |
| B10A0-14 | Wiper Output Short to Ground or Open Circuit |
| B10A1-12 | Washer Fluid Output Short to Battery |
| B10A1-14 | Washer Fluid Output Short to Ground or Open Circuit |
| B10B0-00 | Drive ISO/H Pattern Switch Flipped While Operating |
| B10B1-F0 | Drive Input Not in Neutral |
| B10B3-F0 | Drive X Input Not In Neutral |
| B10B6-F0 | Drive Y Input Not In Neutral |
| B10B9-F0 | Drive Left Input Not In Neutral |
| B10BC-F0 | Drive Right Input Not In Neutral |
| B10D0-12 | Display Switched Power Relay Error On |
| B10D0-14 | Display Switched Power Relay Error Off |
| B1100-9E | Bobtach Engage Button Stuck On |
| B1101-9E | Bobtach Disengage Button Stuck On |
| B1110-F0 | Left Primary Not in Neutral |
| B1111-F0 | Left Secondary Not in Neutral |
| B1120-F0 | Right Primary Not in Neutral |
| B1121-F0 | Right Secondary Not in Neutral |
| B1122-F0 | Detent Not in Neutral |
| B116F-11 | Front Left Road Light Short to Ground |
| B116F-12 | Front Left Road Light Short to Battery |
| B116F-13 | Front Left Road Light Open Circuit |
| B1177-12 | Left Turn Signal Short to Battery |
| B1177-14 | Left Turn Signal Short to Ground or Open Circuit |
| B117F-11 | Front Right Road Light Short to Ground |
| B117F-12 | Front Right Road Light Short to Battery |
| B117F-13 | Front Right Road Light Open Circuit |
| B1187-12 | Right Turn Signal Short to Battery |
| B1187-14 | Right Turn Signal Short to Ground or Open Circuit |
| C1002-16 | Sensor Supply Out of Range Low |
| C1002-17 | Sensor Supply Out of Range High |
| C100A-11 | ECU Power Short to Ground |
| C100A-12 | ECU Power Short to Battery |
| C100A-13 | ECU Power Open Circuit |
| C1015-16 | Lift Spool Position Sensor Out of Range Low |
| C1015-17 | Lift Spool Position Sensor Out of Range High |
| C1015-56 | Lift Spool Position Sensor Inverted Movement |
| C1015-93 | Lift Spool Position Sensor Unresponsive |
| C1015-F0 | Lift Spool Position Sensor Not in Neutral |
| C1016-16 | Tilt Spool Position Sensor Out of Range Low |
| C1016-17 | Tilt Spool Position Sensor Out of Range High |
| C1016-93 | Tilt Spool Position Sensor Unresponsive |
| C1016-F0 | Tilt Spool Position Sensor Not in Neutral |
| C101D-16 | Tilt Rod Pressure Sensor Out of Range Low |
| C101D-17 | Tilt Rod Pressure Sensor Out of Range High |
| C1029-11 | Hydraulic Lock Solenoid Short to Ground |
| C1029-12 | Hydraulic Lock Solenoid Short to Battery |
| C1029-13 | Hydraulic Lock Solenoid Open Circuit |
| C102B-11 | Reverse Fan Short to Ground |
| C102B-12 | Reverse Fan Short to Battery |
| C102B-13 | Reverse Fan Open Circuit |
| C1030-00 | Two Speed Shift Not Allowed |
| C1032-11 | Brake Pull Output Short to Ground |
| C1032-12 | Brake Pull Output Short to Battery |
| C1032-13 | Brake Pull Output Open Circuit |
| C1033-11 | Left Brake Hold Output Short to Ground |
| C1033-12 | Left Brake Hold Output Short to Battery |
| C1033-13 | Left Brake Hold Output Open Circuit |
| C1034-11 | Right Brake Hold Output Short to Ground |
| C1034-12 | Right Brake Hold Output Short to Battery |
| C1034-13 | Right Brake Hold Output Open Circuit |
| C1035-16 | Left Brake Pull Relay Error Off |
| C1035-17 | Left Brake Pull Relay Error On |
| C1036-16 | Right Brake Pull Relay Error Off |
| C1036-17 | Right Brake Pull Relay Error On |
| C1039-19 | High Flow Solenoid Overcurrent |
| C103A-11 | Ride Control 1 Short to Ground |
| C103A-12 | Ride Control 1 Short to Battery |
| C103A-13 | Ride Control 1 Open Circuit |
| C103B-11 | Ride Control 2 Short to Ground |
| C103B-12 | Ride Control 2 Short to Battery |
| C103B-13 | Ride Control 2 Open Circuit |
| C103C-11 | Bobtach Engage Short to Ground |
| C103C-12 | Bobtach Engage Short to Battery |
| C103C-13 | Bobtach Engage Open Circuit |
| C103D-11 | Bobtach Disengage Short to Ground |
| C103D-12 | Bobtach Disengage Short to Battery |
| C103D-13 | Bobtach Disengage Open Circuit |
| C1040-11 | Lift Actuator Short to Ground |
| C1040-12 | Lift Actuator Short to Battery |
| C1040-13 | Lift Actuator Open Circuit |
| C1040-19 | Lift Actuator Overcurrent |
| C1040-77 | Lift Actuator Reduced Performance |
| C1041-00 | Lift Spool Position Sensor Inverted Movement |
| C1042-00 | Lift Actuator Uncommanded Motion |
| C1045-11 | Tilt Actuator Short to Ground |
| C1045-12 | Tilt Actuator Short to Battery |
| C1045-13 | Tilt Actuator Open Circuit |
| C1045-19 | Tilt Actuator Overcurrent |
| C1045-77 | Tilt Actuator Reduced Performance |
| C1046-00 | Tilt Spool Position Sensor Inverted Movement |
| C1047-00 | Tilt Actuator Uncommanded Motion |
| C104A-00 | Lift Float Failed to achieve float |
| C104B-00 | Lift Float Conditions not favorable |
| C104C-00 | Lift Float Failed to maintain float |
| C1051-11 | Two Speed Solenoid Short to Ground |
| C1051-12 | Two Speed Solenoid Short to Battery |
| C1051-13 | Two Speed Solenoid Open Circuit |
| C1051-19 | Two Speed Solenoid Overcurrent |
| C1070-11 | Rear Auxiliary Base Solenoid Short to Ground |
| C1070-12 | Rear Auxiliary Base Solenoid Short to Battery |
| C1070-13 | Rear Auxiliary Base Solenoid Open Circuit |
| C1071-11 | Rear Auxiliary Base Lock Solenoid Short to Ground |
| C1071-12 | Rear Auxiliary Base Lock Solenoid Short to Battery |
| C1071-13 | Rear Auxiliary Base Lock Open Circuit |
| C1075-11 | Rear Auxiliary Rod Solenoid Short to Ground |
| C1075-12 | Rear Auxiliary Rod Solenoid Short to Battery |
| C1075-13 | Rear Auxiliary Rod Solenoid Open Circuit |
| C1076-11 | Rear Auxiliary Rod Lock Solenoid Short to Ground |
| C1076-12 | Rear Auxiliary Rod Lock Solenoid Short to Battery |
| C1076-13 | Rear Auxiliary Rod Solenoid Open Circuit |
| C1080-F8 | Hydraulic Charge Pressure Extremely Low |
| C1080-F9 | Low Hydraulic Pump Pressure |
| C1080-FA | Hydraulic Charge Pressure High |
| C1080-FB | Hydraulic Charge Pressure Extremely High |
| C1093-00 | Hydraulic Case Drain Filter Switch Plugged |
| C1097-16 | Hydraulic Charge Pressure Sensor Out of Range Low |
| C1097-17 | Hydraulic Charge Pressure Sensor Out of Range High |
| C10A0-16 | Drive Motor Case Drain Hydraulic Oil Temperature Out of Range Low |
| C10A0-17 | Drive Motor Case Drain Hydraulic Oil Temperature Out of Range High |
| C10A1-FA | Drive Motor Case Drain Hydraulic Oil Temperature High |
| C10A1-FB | Drive Motor Case Drain Hydraulic Oil Temperature Extremely High |
| C10A1-FC | Drive Motor Case Drain Hydraulic Oil Temperature Reduced Performance |
| C10A5-16 | Pump Case Drain Hydraulic Oil Temperature Out of Range Low |
| C10A5-17 | Pump Case Drain Hydraulic Oil Temperature Out of Range High |
| C10A6-FA | Pump Case Drain Hydraulic Oil Temperature High |
| C10A6-FB | Pump Case Drain Hydraulic Oil Temperature Extremely High |
| C10A6-FC | Pump Case Drain Hydraulic Oil Temperature High |
| C10B0-00 | Workgroup Disabled Due To Window Fault |
| C10C0-77 | Right Swash Plate Commanded Position Not Reachable |
| C10C0-F0 | Right Swash Plate Not in Neutral |
| C10C1-16 | Right Swash Plate Sensor Out of Range Low |
| C10C1-17 | Right Swash Plate Sensor Out of Range High |
| C10C5-77 | Left Swash Plate Commanded Position Not Reachable |
| C10C5-F0 | Left Swash Plate Not in Neutral |
| C10C6-16 | Left Swash Plate Sensor Out of Range Low |
| C10C6-17 | Left Swash Plate Sensor Out of Range High |
| C10D0-54 | Drive Pump Not Calibrated |
| C1150-13 | Right Drive Motor Direction Open Circuit |
| C1150-16 | Right Drive Motor Direction Out of Range Low |
| C1150-17 | Right Drive Motor Direction Out of Range High |
| C1155-13 | Left Drive Motor Direction Open Circuit |
| C1155-16 | Left Drive Motor Direction Out of Range Low |
| C1155-17 | Left Drive Motor Direction Out of Range High |
| C1182-A3 | Alternator Voltage High |
| C1190-00 | System Voltage Out of Range Low |
| C1195-00 | System Voltage Extremely Low |
| C11C0-11 | Left Forward Drive Solenoid Error Off |
| C11C0-12 | Left Forward Drive Solenoid Error On |
| C11C2-11 | Left Reverse Drive Solenoid Error Off |
| C11C2-12 | Left Reverse Drive Solenoid Error On |
| C11C4-11 | Right Forward Drive Solenoid Error Off |
| C11C4-12 | Right Forward Drive Solenoid Error On |
| C11C6-11 | Right Reverse Drive Solenoid Error Off |
| C11C6-12 | Right Reverse Drive Solenoid Error On |
| CP706 | TestCP706 |
| D3905 | Left Joystick X-Axis Not in Neutral |
| D3907 | Left Joystick Y-Axis Not in Neutral |
| D4007 | Right Joystick Y-Axis Not in Neutral |
| D7501 | Drive/Drive+ CAN Joystick Information Error |
| D7502 | Drive Controller Needs Programming |
| D7504 | Drive No Communication from Drive Controller |
| D7505 | Drive Left Joystick X-Axis Not in Neutral |
| D7506 | Drive+ Steering valve cartridge stuck |
| D7507 | Drive Left Joystick Y-Axis Not in Neutral |
| D7508 | Drive Right Joystick Y-Axis Not in Neutral |
| D7509 | Drive ISO/H Pattern Switch Short to Ground or Battery |
| D7510 | Drive Improper Joysticks installed |
| D7511 | Drive Left speed sensor not connected. |
| D7512 | Drive Right speed sensor not connected |
| D7513 | Drive+ Right Front Wheel Angle Sensor Stuck |
| D7514 | Drive+ Left Front Wheel Angle Sensor Stuck |
| D7515 | Drive+ Right Reat Wheel Angle Sensor Stuck |
| D7516 | Drive+ Left Rear Wheel Angle Sensor Stuck |
| D7517 | Drive Left Swash Plate Not in Neutral |
| D7518 | Drive Right Swash Plate Not in Neutral |
| D7519 | Drive Left Joystick X-Axis Out of Range High |
| D7521 | Drive Left Joystick Y-Axis Out of Range High |
| D7522 | Drive Right Joystick Y-Axis Out of Range High |
| D7523 | Drive+ Right Front Wheel Angle Sensor Out of Range High |
| D7524 | Drive+ Left Front Wheel Angle Sensor Out of Rane High |
| D7525 | Drive+ Right Rear Wheel Angle Sensor Out of Range High |
| D7526 | Drive+ Left Rear Wheel Angle Sensor Out of Range High |
| D7527 | Drive Left Swash Plate Out of Position |
| D7528 | Drive Right Swash Plate Out of Position |
| D7529 | Drive Left Joystick X-Axis Out of Range Low |
| D7531 | Drive Left Joystick Y-Axis Out of Range Low |
| D7532 | Drive Right Joystick Y-Axis Out of Range Low |
| D7533 | Drive+ Right Front Wheel Angle Sensor Out of Range Low |
| D7534 | Drive+ Left Front Wheel Angle Sensor Out of Range Low |
| D7535 | Drive+ Right Rear Wheel Angle Sensor Out of Range Low |
| D7536 | Drive+ Left Rear Wheel Angle Sensor Out of Range Low |
| D7537 | Drive 5 Volt Sensor Supply 1 Out of Range Low |
| D7538 | Drive+ Sensor Supply 2 Out of Range Low |
| D7539 | Drive Left Swash Plate Sensor Out of Range High |
| D7540 | Drive Left Swash Plate Sensor Out of Range Low |
| D7541 | Drive Right Swash Plate Sensor Out of Range High |
| D7542 | Drive Right Swash Plate Sensor Out of Range Low |
| D7543 | Drive Left Forward Drive Solenoid Error On |
| D7544 | Drive Left Reverse Drive Solenoid Error On |
| D7545 | Drive Right Forward Drive Solenoid Error On |
| D7546 | Drive Right Reverse Drive Solenoid Error On |
| D7547 | Drive+ Right Front Steer Extend Short to Battery |
| D7548 | Drive+ Left Front Steer Extend Short to Battery |
| D7549 | Drive+ Right Rear Steer Extend Short To Battery |
| D7550 | Drive+ Left Rear Steer Extend Short to Battery |
| D7551 | Drive+ Steer Pressure Short To Battery |
| D7552 | Drive Backup Alarm Error On |
| D7553 | Drive Left Forward Drive Solenoid Error Off |
| D7554 | Drive Left Reverse Drive Solenoid Error Off |
| D7555 | Drive Right Forward Drive Solenoid Error Off |
| D7556 | Drive Right Reverse Drive Solenoid Error Off |
| D7557 | Drive+ Right Front Steer Extend Short to Ground |
| D7558 | Drive+ Right Front Steer Retract Short to Ground |
| D7559 | Drive+ Left Front Steer Extend Short to Ground |
| D7560 | Drive+ Left Front Steer Retract Short to Ground |
| D7561 | Drive+ Right Rear Steer Extend Short to Ground |
| D7562 | Drive+ Right Rear Steer Retract Short to Ground |
| D7563 | Drive+ Left Rear Steer Extend Short to Ground |
| D7564 | Drive+ Left Rear Steer Retract Short to Ground |
| D7565 | Drive+ Stree Pressure Short to Ground |
| D7566 | Drive Backup Alarm Error Off |
| D7567 | Drive No Communication from Bobcat Controller |
| D7568 | Drive+ Angle Sensors Not Calibrated |
| D7569 | Drive Battery Voltage Out of Range High |
| D7570 | Drive Interrupted Power (also occurs after software updates) |
| D7571 | Drive Battery Voltage Out of Range Low |
| D7572 | Drive Drive Pump Not Calibrated |
| D7573 | Drive ISO/H Pattern Switch Flipped While Operating |
| D7574 | Drive Right Wheel Speed Uncommanded Motion |
| D7575 | Drive Left Wheel Speed Uncommanded Motion |
| D7576 | Drive No Communication from ACS Controller |
| D7577 | Drive Left Speed Sensor Out of Range High |
| D7578 | Drive Right Speed Sensor Out of Range High |
| D7579 | Drive Left Speed Sensor Out of Range Low |
| D7580 | Drive Right Speed Sensor Out of Range Low |
| D7581 | Drive+ Right Front Steer Retract Short to Battery |
| D7582 | Drive+ Left Front Steer Retract Short to Battery |
| D7583 | Drive+ right Rear Steer Retract Short to Battery |
| D7584 | Drive+ Left Rear Steer Retract Short to Battery |
| D7585 | Drive 5 Volt Sensor Supply 1 Out of Range High |
| D7586 | Drive+ Sensor Supply 2 Out of Range High |
| D7587 | Drive Software Update Required |
| D7588 | Drive/Drive+ Switched Power Stuck On |
| D7589 | Drive Switched Power Error Off |
| D7590 | Drive Drive calibration performed |
| D7591 | Drive Left Swashplate Sensor Reversed |
| D7592 | Drive Right Swashplate Sensor Reversed |
| D7593 | Drive Unresponsive Right Speed Sensor |
| D7594 | Drive Unresponsive Left Speed Sensor |
| D7595 | Drive Left Speed Sensor Reverse Direction |
| D7596 | Drive Right Speed Sensor Reverse Direction |
| D7597 | Drive Controller Programmed |
| D7598 | Drive Controller in Calibration Mode |
| D7599 | Drive Controller in Angle Calibration Mode |
| H1221 | Right Primary Out of Range High |
| H1222 | Right Primary Out of Range Low |
| H1224 | Right Primary Not in Neutral |
| H1324 | Left Primary Not in Neutral |
| H1421 | Lift Base Pressure Out of Range High |
| H1422 | Lift Base Pressure Out of Range Low |
| H1502 | Ride Control Relay Error On |
| H1503 | Ride Control Relay Error Off |
| H1602 | Ride Control Output Error On |
| H1603 | Ride Control Output Error Off |
| H1607 | Ride Control Output Open Circuit |
| H1628 | Ride Control Output Failure |
| H2105 | Reverse Fan Solenoid Short To Battery |
| H2106 | Reverse Fan Solenoid Short to Ground |
| H2107 | Reverse Fan Solenoid Open Circuit |
| H2132 | Reverse Fan Solenoid Overcurrent |
| H2305 | Rear Base Solenoid Short to Battery |
| H2306 | Rear Base Solenoid Short to Ground |
| H2307 | Rear Base Solenoid Open Circuit |
| H2332 | Rear Base Solenoid Overcurrent |
| H2405 | Rear Rod Solenoid Short to Battery |
| H2406 | Rear Rod Solenoid Short to Ground |
| H2407 | Rear Rod Solenoid Open Circuit |
| H2432 | Rear Rod Solenoid Overcurrent |
| H2505 | Diverter Solenoid #2 Short to Battery |
| H2506 | Diverter Solenoid #2 Short to Ground |
| H2605 | Front Base Solenoid Short to Battery |
| H2606 | Front Base Solenoid Short to Ground |
| H2607 | Front Base Solenoid Open Circuit |
| H2632 | Front Base Solenoid Overcurrent |
| H2705 | Front Rod Solenoid Short to Battery |
| H2706 | Front Rod Solenoid Short to Ground |
| H2707 | Front Rod Solenoid Open Circuit |
| H2732 | Front Rod Solenoid Overcurrent |
| H2805 | Diverter Solenoid Short to Battery |
| H2806 | Diverter Solenoid Short to Ground |
| H2905 | High Flow Solenoid Short to Battery |
| H2906 | High Flow Solenoid Short to Ground |
| H2907 | High Flow Solenoid Open Circuit |
| H2932 | High Flow Solenoid Overcurrent |
| H3028 | Controller Memory Failure |
| H3128 | Interrupted Power Failure |
| H3648 | ACD Multiple |
| H3702 | Power Bobtach Up Solenoid Error On |
| H3913 | Left Joystick Grip No Communication |
| H3916 | Left Joystick Not Connected |
| H3928 | Left Joystick Failure |
| H3948 | Left Joystick Multiple |
| H4013 | Right Joystick Grip No Communication |
| H4016 | Right Joystick Not Connected |
| H4028 | Right Joystick Failure |
| H4048 | Right Joystick Multiple |
| H4423 | Auxiliary Not Programmed |
| H4721 | Sensor Supply 1 Out of Range High |
| H4722 | Sensor Supply 1 Out of Range Low |
| H4821 | 5V Sensor Supply Out of Range High |
| H4822 | 5V Sensor Supply Out of Range Low |
| H7404 | Main Controller No Communication |
| H7604 | Left Hand Panel No Communication |
| H8002 | ACD Output A Error On |
| H8003 | ACD Output A Error Off |
| H8102 | ACD Output B Error On |
| H8103 | ACD Output B Error Off |
| H8202 | ACD Output C Error On |
| H8203 | ACD Output C Error Off |
| H8302 | ACD Output D Error On |
| H8303 | ACD Output D Error Off |
| H8402 | ACD Output E Error On |
| H8403 | ACD Output E Error Off |
| H8502 | ACD Output F Error On |
| H8503 | ACD Output F Error Off |
| H8602 | ACD Output G Error On |
| H8603 | ACD Output G Error Off |
| H8702 | ACD Output H Error On |
| H8703 | ACD Output H Error Off |
| H9110 | Fuel Pressure at Filter Inlet Too High |
| H9111 | Fuel Pressure at Filter Inlet Extremely High |
| H9121 | Fuel Pressure Out of Range High |
| H9122 | Fuel Pressure Out of Range Low |
| H9144 | Fuel Filter Derate Level 1 |
| H9145 | Fuel FIlter Derate Level 2 |
| H9202 | Fuel Lift Pump Output Error On |
| H9203 | Fuel Lift Pump Output Error Off |
| H9287 | Fuel Lift Pump Protection Time-Out |
| H9309 | Fuel Pressure Low |
| H9314 | Fuel Pressure Extremely Low |
| H9321 | Fuel Pressure Out of Range High |
| H9322 | Fuel Pressure Out of Range Low |
| H9344 | Fuel Pressure Derate Level 1 |
| L0102 | Standard Panel Button 1 Error On |
| L0202 | Standard Panel Button 2 Error On |
| L0302 | Standard Panel Button 3 Error On |
| L0402 | Standard Panel Button 4 Error On |
| L7404 | Main Controller No Communication |
| L7672 | Standard Panel Programming Error |
| LOWVLTG | Low Battery Voltage |
| M0116 | Air Filter Not Connected |
| M0117 | Air Filter Plugged |
| M0144 | Air Filter Derate Level 1 |
| M0145 | Air Filter Derate Level 2 |
| M0216 | Hydraulic/Hydrostatic Filter Not Connected |
| M0217 | Hydraulic/Hydrostatic Filter Plugged |
| M0309 | System Voltage Too Low |
| M0310 | System Voltage Too High |
| M0311 | System Voltage Extremely High |
| M0314 | System Voltage Extremely Low |
| M0322 | System Voltage Out of Range Low |
| M0409 | Engine Oil Pressure Too Low |
| M0414 | Engine Oil Pressure Extremely Low |
| M0415 | Engine Oil Pressure Shutdown |
| M0421 | Engine Oil Pressure Out of Range High |
| M0422 | Engine Oil Pressure Out of Range Low |
| M0509 | Hydraulic Charge Pressure Low |
| M0510 | Hydraulic Charge Pressure High |
| M0511 | Hydraulic Charge Pressure Extremely High |
| M0514 | Hydraulic Charge Pressure Extremely Low |
| M0515 | Hydraulic Charge Pressure Shutdown |
| M0521 | Hydraulic Charge Pressure Out of Range High |
| M0522 | Hydraulic Charge Pressure Out of Range Low |
| M0610 | Engine Speed Too High |
| M0611 | Engine Speed Extremely High |
| M0613 | Engine Speed No Signal |
| M0615 | Engine Speed Shutdown |
| M0618 | Engine Speed Out of Range |
| M0634 | Engine Speed Invalid Data |
| M0710 | Hydraulic Oil Temperature Too High |
| M0711 | Hydraulic Oil Temperature Extremely High |
| M0715 | Hydraulic Oil Temperature Shutdown |
| M0721 | Hydraulic Oil Temperature Out of Range High |
| M0722 | Hydraulic Oil Temperature Out of Range Low |
| M0810 | Engine Coolant Temperature Too High |
| M0811 | Engine Coolant Temperature Extremely High |
| M0815 | Engine Coolant Temperature Shutdown |
| M0821 | Engine Coolant Temperature Out of Range High |
| M0822 | Engine Coolant Temperature Out of Range Low |
| M0826 | Engine Coolant Temperature Pre Shutdown |
| M0909 | Fuel Level Too Low |
| M0921 | Fuel Level Out of Range High |
| M0922 | Fuel Level Out of Range Low |
| M1016 | Hydraulic Charge Filter Not Connected |
| M1017 | Hydraulic Charge Filter Plugged |
| M1121 | Seat Bar Sensor Out of Range High |
| M1122 | Seat Bar Sensor Out of range Low |
| M1128 | Seat Bar Sensor Failure |
| M1210 | Air Inlet Temperature High |
| M1211 | Air Inlet Temprature Extremely High |
| M1305 | Fuel Hold Solenoid Short to Battery |
| M1306 | Fuel Hold Solenoid Short to Ground |
| M1307 | Fuel Hold Solenoid Open Circuit |
| M1402 | Fuel Pull Output Error On |
| M1403 | Fuel Pull Output Error Off |
| M1407 | Fuel Pull Output Open Circuit |
| M1428 | Fuel Pull Output Controller Failure |
| M1502 | Traction Lock Pull Output Error On |
| M1503 | Traction Lock Pull Output Error Off |
| M1507 | Traction Lock Pull Output Open Circuit |
| M1528 | Traction Lock Pull Output Controller Failure |
| M1605 | Traction Lock Hold Solenoid Short to Battery |
| M1606 | Traction Lock Hold Solenoid Short to Ground |
| M1607 | Traction Lock Hold Solenoid Open Circuit |
| M1705 | Hydraulic Lock Valve Solenoid Short to Battery |
| M1706 | Hydraulic Lock Valve Solenoid Short to Ground |
| M1707 | Hydraulic Lock Valve Solenoid Open Circuit |
| M1732 | Hydraulic Lock Valve Solenoid Overcurrent |
| M1805 | Spool Lock 1 Short to Battery |
| M1806 | Spool Lock 1 Short to Ground |
| M1807 | Spool Lock 1 Open Circuit |
| M1832 | Spool Lock 1 Overcurrent |
| M1910 | Engine Ambient Temperature High |
| M1911 | Engine Ambient Temperature Extremely High |
| M1921 | Engine Ambient Temperature Out of Range High |
| M1922 | Engine Ambient Temperature Out of Range Low |
| M2005 | Two Speed Primary Short to Battery |
| M2006 | Two Speed Primary Short to Ground |
| M2007 | Two Speed Primary Open Circuit |
| M2032 | Two Speed Primary Overcurrent |
| M2102 | Glow Plug Output Error On |
| M2103 | Glow Plug Output Error Off |
| M2107 | Glow Plug Output Open Circuit |
| M2128 | Glow Plug Output Failure |
| M2202 | Starter Output Error On |
| M2203 | Starter Output Error Off |
| M2207 | Starter Output Open Circuit |
| M2228 | Starter Output Failure |
| M2302 | Starter Relay Error On |
| M2303 | Starter Relay Error Off |
| M2402 | Fuel Pull Relay Error On |
| M2403 | Fuel Pull Relay Error Off |
| M2502 | Traction Pull Relay Error On |
| M2503 | Traction Pull Relay Error Off |
| M2602 | Glow Plug Relay Error On |
| M2603 | Glow Plug Relay Error Off |
| M2721 | Throttle Primary Sensor Out of Range High |
| M2722 | Throttle Primary Sensor Out of Range Low |
| M2821 | Throttle Secondary Sensor Out of Range High |
| M2822 | Throttle Secondary Sensor Out of Range Low |
| M2899 | Throttle Secondary Sensor Calibration Required |
| M2910 | Exhaust Gas Temperature High |
| M3128 | Interrupted Power Failure |
| M3204 | Workgroup Controller No Communication |
| M3304 | Deluxe Panel (MSeries) No Communication |
| M3404 | Deluxe Panel No Communication |
| M3505 | Hydraulic Fan Short to Battery |
| M3506 | Hydraulic Fan Short to Ground |
| M3507 | Hydraulic Fan Open Circuit |
| M3532 | Hydraulic Fan Overcurrent |
| M3705 | Two Speed Secondary Short to Battery |
| M3706 | Two Speed Secondary Short to Ground |
| M3707 | Two Speed Secondary Open Circuit |
| M3732 | Two Speed Secondary Overcurrent |
| M3805 | Auxiliary Hydraulic Lock Short to Battery |
| M3806 | Auxiliary Hydraulic Lock Short to Ground |
| M3807 | Auxiliary Hydraulic Lock Open Circuit |
| M3832 | Auxiliary Hydraulic Lock Overcurrent |
| M4028 | Wrong ECU Detected |
| M4109 | Alternator Low |
| M4110 | Alternator High |
| M4228 | Wrong DCU Detected |
| M4304 | Keyless Start Panel No Communication |
| M4404 | Auxiliary No Communication |
| M4510 | Water In Fuel Too High |
| M4511 | Water In Fuel Extremely High |
| M4521 | Water In Fuel Sensor Out of Range High |
| M4522 | Water In Fuel Sensor Out of Range Low |
| M4530 | Water In Fuel Sensor Fault |
| M4621 | 5V Sensor Supply Out of Range High |
| M4622 | 5V Sensor Supply Out of Range Low |
| M4721 | 8V Sensor Supply Out of Range High |
| M4722 | 8V Sensor Supply Out of Range Low |
| M4802 | Front Light Relay Error On |
| M4803 | Front Light Relay Error Off |
| M4902 | Rear Light Relay Error On |
| M4903 | Rear Light Relay Error Off |
| M5002 | Front Light Output Error On |
| M5003 | Front Light Output Error Off |
| M5007 | Front Light Output Open Circuit |
| M5028 | Front Light Output Failure |
| M5102 | Rear Light Output Error On |
| M5103 | Rear Light Output Error Off |
| M5107 | Rear Light Output Open Circuit |
| M5128 | Rear Light Output Failure |
| M5202 | Press to Operate Switch Error On |
| M5221 | Press to Operate Switch Out of Range High |
| M5222 | Press to Operate Switch Out of Range Low |
| M5305 | Press to Operate Light Short to Battery |
| M5306 | Press to Operate Light Short to Ground |
| M5405 | Spool Lock 2 Short to Battery |
| M5406 | Spool Lock 2 Short to Ground |
| M5407 | Spool Lock 2 Open Circuit |
| M5432 | Spool Lock 2 Overcurrent |
| M5810 | Fuel Temperature High |
| M5811 | Fuel Temperature Extremely High |
| M5815 | Fuel Temperature Shutdown |
| M5826 | Fuel Temperature Pre Shutdown |
| M5902 | DPF Regeneration Switch Error On |
| M6002 | DPF Inhibit Regen Switch Error On |
| M6102 | Remote Parked Regeneration Switch Error On |
| M6202 | Tailgate Fan 1 Error On |
| M6203 | Tailgate Fan 1 Error Off |
| M6228 | Tailgate Fan 1 Failure |
| M6302 | Tailgate Fan 2 Error On |
| M6303 | Tailgate Fan 2 Error Off |
| M6328 | Tailgate Fan 2 Failure |
| M6402 | Switched Power Relay Error On |
| M6403 | Switched Power Relay Error Off |
| M6505 | ECU Power Short to Battery |
| M6506 | ECU Power Short to Ground |
| M6507 | ECU Power Open Circuit |
| M6604 | ECU No Communication |
| M6702 | HVAC Output Error On |
| M6703 | HVAC Output Error Off |
| M6707 | HVAC Output Open Circuit |
| M6728 | HVAC Output Failure |
| M6802 | HVAC Relay Error On |
| M6803 | HVAC Relay Error Off |
| M6904 | DCU No Communication |
| M7002 | Switched Power Output Error On |
| M7003 | Switched Power Output Error Off |
| M7007 | Switched Power Output Open Circuit |
| M7028 | Switched Power Output Failure |
| M7102 | Electric Fan Output Error On |
| M7103 | Electric Fan Output Error Off |
| M7107 | Electric Fan Output Open Circuit |
| M7202 | Electric Fan Relay Error On |
| M7203 | Electric Fan Relay Error Off |
| M7304 | Remote Control No Communication |
| M7316 | Remote Control Not Connected |
| M7423 | Main Controller Not Programmed |
| M7497 | Main Controller Software Updated |
| M7504 | Drive No Communication |
| M7604 | Left Display Panel No Communication |
| M7748 | Key Switch Multiple |
| M7839 | Hourmeter Changed |
| M7902 | Forestry Door Closed |
| M7974 | Door Open |
| M8228 | AdBlue/DEF Sensor Mismatch |
| M8402 | DESOX Service Requested |
| M8450 | DeSox Required but Inhibited |
| M8541 | DPF Automatic Regeneration Active |
| M8542 | DPF Automatic Regeneration Active |
| M8543 | DPF Regeneration Required |
| M8551 | DPF Regeneration Needed Inhibit Active |
| M8552 | DPF Regeneration Needed - Inhibit Active |
| M8553 | DPF Remote Parked Regeneration Required - Remote Regeneration Kit Required |
| M8554 | DPF Service Regeneration Required - Contact Bobcat Dealer |
| M8555 | DPF Service Required |
| M8560 | DPF Service Regeneration Active |
| M8561 | DPF Service Regeneration Active |
| M8562 | DPF Service Regeneration Active |
| M8563 | DPF Service Regeneration Active |
| M8564 | DPF Service Regeneration Active |
| M8615 | Engine Speed Derate Shutdown |
| M8625 | Engine Speed Derate Unresponsive |
| M8715 | Torque Derate Shutdown |
| M8725 | Torque Derate Unresponsive |
| M8804 | Telematics Not Connected |
| M9701 | Turbo Prime Sequence Active |
| P0225-54 | Throttle Pedal Position Sensor Calibration Required |
| P100A-11 | Starter Output Short to Ground |
| P100A-12 | Starter Output Short to Battery |
| P100A-13 | Starter Output Open Circuit |
| P100B-16 | Starter Output Error Off |
| P100B-17 | Starter Output Error On |
| P1060-16 | Air Filter Out of Range Low |
| P1060-17 | Air Filter Out of Range High |
| P1062-00 | Air Filter Plugged |
| P1063-00 | Air Filter Plugged |
| P1131-13 | Fuel Filter Inlet Pressure Sensor Open Circuit |
| P1134-12 | Fuel Lift Pump Short to Battery |
| P1134-13 | Fuel Lift Pump Open Circuit |
| R3327 | IQ Touch CAN Error |
| R3334 | IQ Touch CAN RX Error |
| R3335 | IQ Touch CAN TX Error |
| U100A-08 | Machine Control Message Failure |
| U1011-08 | Options Keypad No Communication |
| U1015-62 | Throttle Encoder Signal Failure |
| U1051-00 | Cab Controller Interrupted Power Failure |
| U1052-00 | Power Failure |
| U1055-00 | Aux Controller Interrupted Power Failure |
| U1056-00 | Rear Auxiliary Controller Interrupted Power Failure |
| U1060-46 | Workgroup Calibration Failed |
| U1060-87 | Workgroup Calibration Required |
| U1061-00 | Workgroup Calibration Passed |
| U1065-00 | Drive Calibration Passed |
| U1071-00 | Cab Controller Software Updated |
| U1075-00 | Lights Controller Interrupted Power Failure |
| U1080-00 | Drive Controller In Calibration Mode |
| U1084-00 | Workgroup In Calibration Mode |
| U1092-08 | Cab Controller No Communication |
| U1092-51 | Cab Controller Not Programmed |
| U1092-57 | Cab Controller Software Version Error |
| U1092-A2 | Cab Controller System Voltage Low |
| U1092-A3 | Cab Controller System Voltage High |
| U1093-08 | Mid Controller No Communication |
| U1093-51 | Mid Controller Not Calibrated |
| U1093-57 | Mid Controller Software Version Error |
| U1093-A2 | Battery Voltage Low |
| U1093-A3 | Battery Voltage High |
| U1097-08 | Aux Controller Bus Signal / Message Failure |
| U1097-51 | Aux Controller Not Programmed |
| U1097-A2 | Aux Controller System Voltage Low |
| U1097-A3 | Aux Controller System Voltage High |
| U1098-08 | Rear Auxiliary Controller Communication Error |
| U1098-51 | Reary Auxiliary Controller Not Programmed |
| U1098-57 | Rear Auxiliary Controller Software Version Error |
| U1098-A2 | Rear Auxiliary Controller System Voltage Low |
| U1098-A3 | Rear Auxiliary Controller System Voltage High |
| U109C-08 | Lights Controller Communication Error |
| U109C-51 | Lights Controller Not Programmed |
| U109C-57 | Lights Controller Software Incompatible |
| U109C-A2 | Lights Controller Voltage Low |
| U109C-A3 | Lights Controller Voltage High |
| U10A0-08 | Drive Motor Case Drain Hydraulic Oil Temperature Sensor No Communication |
| U10A5-08 | Pump Case Drain Hydraulic Oil Temperature Sensor No Communication |
| U10B0-08 | Left Joystick Base Message Failure |
| U10B0-49 | Left Joystick Base Failure |
| U10B1-08 | Left Joystick Grip Message Failure |
| U10B1-49 | Left Joystick Grip Failure |
| U10B2-49 | Left Joystick Failure |
| U10B3-00 | Left Joystick Multiple |
| U10C0-49 | Right Joystick Base Failure |
| U10C1-08 | Right Joystick Grip Message Failure |
| U10C1-49 | Right Joystick Grip Failure |
| U10C2-49 | Right Joystick Failure |
| U10C3-00 | Right Joystick Multiple |
| U10D0-08 | Remote Control No Communication |
| U10D0-93 | Remote Control Loss Communication |
| U1110-08 | Bob-Tach Angle Sensor No Communication |
| U1111-08 | Bucket Angle Sensor No Communication |
| U1112-08 | Lift Arm Angle No Communication |
| U1113-08 | Frame Angle Sensor No Communication |
| U1185-00 | Radio No Communcation |
| VRLOWVLTG | Very Low Battery Voltage |
| W0176 | Input Selection Flipped While Operating |
| W0321 | Battery Voltage Out of Range High |
| W0322 | Battery Voltage Out of Range Low |
| W0521 | Lift Spool Position Sensor Out of Range High |
| W0522 | Lift Spool Position Sensor Out of Range Low |
| W0524 | Lift Spool Position Sensor Not in Neutral |
| W0525 | Lift Spool Position Sensor Unresponsive |
| W0595 | Lift Spool Position Sensor Inverted Movement |
| W0621 | Tilt Spool Position Sensor Out of Range High |
| W0622 | Tilt Spool Position Sensor Out of Range Low |
| W0624 | Tilt Spool Position Sensor Not in Neutral |
| W0625 | Tilt Spool Position Sensor Unresponsive |
| W0695 | Tilt Spool Position Sensor Inverted Movement |
| W1005 | Lift Base Solenoid Short to Battery |
| W1006 | Lift Base Solenoid Short to Ground |
| W1007 | Lift Base Solenoid Open Circuit |
| W1032 | Lift Base Solenoid Overcurrent |
| W1105 | Lift Rod Solenoid Short to Battery |
| W1106 | Lift Rod Solenoid Short to Ground |
| W1107 | Lift Rod Solenoid Open Circuit |
| W1132 | Lift Rod Solenoid Overcurrent |
| W1205 | Tilt Base Solenoid Short to Battery |
| W1206 | Tilt Base Solenoid Short to Ground |
| W1207 | Tilt Base Solenoid Open Circuit |
| W1232 | Tilt Base Solenoid Overcurrent |
| W1305 | Tilt Rod Solenoid Short to Battery |
| W1306 | Tilt Rod Solenoid Short to Ground |
| W1307 | Tilt Rod Solenoid Open Circuit |
| W1332 | Tilt Rod Solenoid Overcurrent |
| W1505 | Pedal Lock Short to Battery |
| W1506 | Pedal Lock Short to Ground |
| W1507 | Pedal Lock Open Circuit |
| W1605 | Handle Lock Short to Battery |
| W1606 | Handle Lock Short to Ground |
| W1607 | Handle Lock Open Circuit |
| W2021 | Lift Handle Sensor Out of Range High |
| W2022 | Lift Handle Sensor Out of Range Low |
| W2121 | Lift Pedal Sensor Out of Range High |
| W2122 | Lift Pedal Sensor Out of Range Low |
| W2221 | Tilt Handle Sensor Out of Range High |
| W2222 | Tilt Handle Sensor Out of Range Low |
| W2321 | Tilt Pedal Sensor Out of Range High |
| W2322 | Tilt Pedal Sensor Out of Range Low |
| W2824 | Lift Input Not in Neutral |
| W2924 | Tilt Input Not in Neutral |
| W3128 | Interrupted Power Failure |
| W3223 | ACS Calibration required |
| W3224 | ACS Calibration Performed |
| W3225 | ACS (AHC) Calibration Failed |
| W3231 | ACS/AHC Tilt actuator fault |
| W3232 | AHC Tilt actuator wiring fault |
| W3233 | AHC Tilt handle wiring fault |
| W3234 | ACS/AHC Tilt actuator not in neutral |
| W3235 | ACS/AHC Tilt handle not in neutral |
| W3236 | ACS/AHC Lift actuator fault |
| W3237 | AHC Lift actuator wiring fault |
| W3238 | AHC Lift handle wiring fault |
| W3239 | ACS/AHC Lift actuator not in neutral |
| W3240 | ACS/AHC Lift handle not in neutral |
| W3241 | AHC No communication |
| W3249 | ACS Lift actuator short to ground |
| W3250 | ACS Tilt actuator short to ground |
| W3251 | ACS Lift actuator short to battery |
| W3252 | ACS Tilt actuator short to battery |
| W3253 | ACS Lift handle/pedal short to ground |
| W3254 | ACS Tilt handle/pedal short to ground |
| W3255 | ACS Lift handle/pedal short to battery |
| W3256 | ACS Tilt handle/pedal short to battery |
| W3257 | ACS Lift actuator reduced performance |
| W3258 | ACS Tilt actuator reduced performance |
| W3259 | ACS Lift actuator wrong direction |
| W3260 | ACS Tilt actuator wrong direction |
| W3261 | ACS Handle lock short to ground |
| W3262 | ACS Handle lock short to battery |
| W3263 | ACS Pedal lock short to ground |
| W3264 | ACS Pedal lock short to battery |
| W3265 | ACS Sensor supply voltage out of range |
| W3266 | ACS Battery voltage out of range |
| W3267 | ACS Switch flipped while operating |
| W3268 | ACS Lift handle information error |
| W3270 | ACS Right hand drive short to ground |
| W3271 | ACS Right hand drive short to battery |
| W3274 | ACS Left Joystick X-Axis Out of Range |
| W3275 | ACS Interrupted unswitched power |
| W3276 | ACS CAN Joystick Information Error |
| W3277 | ACS Remote Control Information Error |
| W3295 | Workgroup Calibration Passed |
| W3296 | Workgroup Calibration Failed |
| W3297 | ACS (AHC) Controller Programmed |
| W3298 | Workgroup In Calibration Mode |
| W3299 | Workgroup Calibration Required |
| W3304 | Main Controller No Communication |
| W3904 | Left Joystick No Communication |
| W3905 | Left Joystick X-Axis Not in Neutral |
| W4004 | Right Joystick No Communication |
| W4005 | Right Joystick X-Axis Not in Neutral |
| W4007 | Right Joystick Y-Axis Not in Neutral |
| W4721 | Sensor Supply Out of Range High |
| W4722 | Sensor Supply Out of Range Low |
| W5004 | Lift Float Failed to maintain float |
| W7304 | Remote Control No Communication |
| W7504 | Drive Controller No Communication |
Small Articulated Loader 75
| Fault Code | Description |
|---|---|
| B103B-12 | Light Circuit Short to Battery |
| B103B-14 | Light Circuit Short to Ground |
| B1080-16 | Armrest Out of Range Low |
| B1080-17 | Armrest Out of Range High |
| B1080-54 | Armrest No Signal |
| B1080-66 | Armrest Intermittent Signal |
| B1120-16 | Right Primary Out of Range Low |
| B1120-17 | Right Primary Out of Range High |
| B1121-16 | Right Secondary Out of Range Low |
| B1121-17 | Right Secondary Out of Range High |
| C102E-12 | Fan Circuit Short to Battery |
| C102E-14 | Fan Open Circuit |
| C1050-15 | Switched Power Relay Short to Battery or Open Circuit |
| C1060-11 | Brake Solenoid Short to Ground |
| C1060-12 | Brake Solenoid Short to Battery |
| C1060-13 | Brake Solenoid Open Circuit |
| C1080-FD | Hydraulic Charge Pressure Shutdown |
| C1099-FD | Hydraulic Oil Temperature Shutdown |
| C10E0-16 | Controller 8V Sensor Supply Voltage Low |
| C10E0-17 | Controller 8V Sensor Supply Voltage High |
| C10E5-16 | Controller 5V Sensor Supply Voltage Low |
| C10E5-17 | Controller 5V Sensor Supply Voltage High |
| C10F0-11 | Lift/Tilt Short to Ground |
| C10F0-12 | Lift/Tilt Short to Battery |
| C10F0-13 | Lift/Tilt Open Circuit |
| C10F1-16 | Lift/Tilt Out of Range Low |
| C10F1-17 | Lift/Tilt Out of Range High |
| C10FA-11 | Lift Arm Extension Short to Ground |
| C10FA-12 | Lift Arm Extension Short to Battery |
| C10FA-13 | Lift Arm Extension Open Circuit |
| C10FA-19 | Lift Arm Extension Overcurrent |
| C10FB-11 | Lift Arm Rod Solenoid Short to Ground |
| C10FB-12 | Lift Arm Rod Solenoid Short to Battery |
| C10FB-13 | Lift Arm Rod Solenoid Open Circuit |
| C10FB-19 | Lift Arm Rod Solenoid Overcurrent |
| C10FC-11 | Lift Arm Base Solenoid Short to Ground |
| C10FC-12 | Lift Arm Base Solenoid Short to Battery |
| C10FC-13 | Lift Arm Solenoid Open Circuit |
| C10FC-19 | Lift Arm Solenoid Overcurrent |
| C1100-11 | Travel Circuit Short to Ground |
| C1100-12 | Travel Circuit Short to Battery |
| C1100-13 | Travel Circuit Open |
| C1101-16 | Travel Circuit Our of Range Low |
| C1101-17 | Travel Circuit Out of Range High |
| C1182-A2 | Alternator Voltage High |
| C1182-A3 | Alternator Voltage Low |
| C119A-F8 | System Voltage Extremely Low |
| C119A-F9 | System Voltage Too Low |
| C119A-FA | System Voltage Extremely Low |
| C119A-FB | System Voltage Extremely High |
| P1020-11 | Glow Plug Output Short to Ground |
| P1020-12 | Glow Plug Output Short to Battery |
| P1020-13 | Glow Plug Output Open Circuit |
| P1021-16 | Glow Plug Output Error Off |
| P1021-17 | Glow Plug Output Error On |
| P10E0-F8 | Engine Oil Pressure Extremely Low |
| P10E0-FD | Engine Oil Pressure Shutdown |
| P10F0-29 | Engine Speed Invalid Data |
| P10F0-31 | Engine Speed No Signal |
| P10F0-FA | Engine Speed Too High |
| P10F0-FB | Engine Speed Extremely High |
| P10F0-FD | Engine Speed Shutdown |
| P1100-FD | Engine Coolant Temperature Shutdown |
| P1101-16 | Engine Coolant Temperature Out of Range Low |
| P1101-17 | Engine Coolant Temperature Out of Range High |
| P1140-11 | Fuel Pull Output Error Off |
| P1140-12 | Fuel Pull Output Error On |
| P1140-13 | Fuel Pull Output Open Circuit |
| P1141-16 | Fuel Pull Output Error Off |
| P1141-17 | Fuel Pull Output Error On |
| P1145-11 | Fuel Hold Solenoid Short to Ground |
| P1145-12 | Fuel Hold Solenoid Short to Battery |
| P1145-13 | Fuel Hold Solenoid Open Circuit |
| U1099-51 | Main Controller Not Programmed |
| U10D0-95 | Remote Control Fault |
Telehandler 697
| Fault Code | Description |
|---|---|
| A0321 | Battery Voltage OOR High |
| A0322 | Battery Voltage OOR Low |
| A0702 | Left interlocking sensor Short to Battery |
| A0703 | Left interlocking sensor Short to Ground or Open circuit |
| A0802 | Right interlocking sensor Short to Battery |
| A0803 | Right interlocking sensor Short to Ground or Open circuit |
| A0921 | Overload Signal 1 Out Of Range High |
| A0922 | Overload Signal 1 Out Of Range Low |
| A1021 | Overload Signal 2 Out Of Range High |
| A1022 | Overload Signal 2 Out Of Range Low |
| A1144 | Overload signals disagrees |
| A1198 | Overload calibration performed |
| A1199 | Overload calibration required |
| A1221 | Tilt inclinometer innput Out of range High |
| A1222 | Tilt inclinometer innput Out of range Low |
| A1298 | Tilt inclinometer calibration performed |
| A1299 | Tilt inclinometer calibration required |
| A3623 | Programming or constant data invalid |
| C0314 | LLMC Undervoltage |
| C0315 | LLMC Overvoltage |
| C3014 | LLMC Sensor Offset |
| C3015 | LLMC Sensor Out of Range |
| C3016 | LLMC Sensor Default |
| C3017 | LLMC Sensor ID Error |
| C3018 | LLMC Sensor Rx Out of Delay |
| C3113 | LLMC Calibration Values Out of Range |
| C3121 | LLMC Calibration Values Inverted |
| C3122 | LLMC Calibration Values Too Close |
| C3123 | LLMC Calibration Timeout |
| C3801 | LLMC EEPROM Failure |
| C3803 | LLMC External Watchdog Default |
| C3804 | LLMC Wrong RAM Test |
| C3805 | LLMC Wrong Program Checksum |
| D0217 | Hydraulic filter plugged |
| D0321 | Battery Voltage OOR High |
| D0322 | Battery Voltage OOR Low |
| D0421 | Inching Pedal OOR High |
| D0422 | Inching Pedal OOR Low |
| D0428 | Inching Pedal In error |
| D0605 | Vehicle speed Short To Battery |
| D0606 | Vehicle speed Short To Ground |
| D0607 | Vehicle speed Open circuit |
| D0611 | Vehicle speed extremely high |
| D0613 | Vehicle speed No Signal |
| D0721 | Hydraulic Oil Temperature OOR High |
| D0722 | Hydraulic Oil Temperature OOR Low |
| D0821 | Frame leveling Pressure Sensor Out Of Range High |
| D0822 | frame leveling Pressure Sensor Out Of Range Low |
| D0909 | Park Brake Pressure Low |
| D0910 | Park Brake Pressure High |
| D0911 | Park Brake Pressure Extremely High |
| D0921 | Park Brake Pressure Out of Range High |
| D0922 | Park Brake Pressure Out of Range Low |
| D1002 | Passive Brake Output Short To Battery or Open circuit |
| D1003 | Passive Brake Valve Short To Ground |
| D1005 | Passive Brake Output Short To Battery |
| D1006 | Passive Brake Output Short To Ground |
| D1007 | Passive Brake Output Open Circuit |
| D1032 | Passive Brake Output Overcurrent |
| D1128 | Park Brake Dashboard Switch In Error |
| D1145 | Park Brake Dashboard Switch Disagree |
| D1202 | EMEA Trailer Brake output Error On (Short To Battery) |
| D1203 | EMEA Trailer Brake output Error Off (Short To Gound) |
| D1207 | EMEA Trailer Brake output Open circuit |
| D1233 | EMEA Trailer Brake output Controller Internal failure |
| D1302 | EMEA Trailer Brake Relay Error On |
| D1303 | EMEA Trailer Brake Relay Error Off |
| D1402 | Brake Light Output Error On |
| D1402 | Trailer Brake Command Line Output Error On |
| D1403 | Trailer Brake Command Line Output Error Off |
| D1403 | Brake Light Output Error Off |
| D1407 | Trailer Brake Command Line Output Open Circuit |
| D1407 | Brake Light Output Open Circuit |
| D1433 | Trailer Brake Command Line Output Internal failure |
| D1433 | Brake Light Output Internal failure |
| D1502 | Trailer Brake Command Line Relay Error On |
| D1502 | Brake Light Relay Error On |
| D1503 | Trailer Brake Command Line Relay Error Off |
| D1503 | Brake Light Relay Error Off |
| D1605 | Drive Pump Forward Coil Short To Battery |
| D1606 | Drive Pump Forward Coil Short To Ground |
| D1607 | Drive Pump Forward Coil Open circuit |
| D1632 | Drive Pump Forward Coil Overcurrent |
| D1705 | Drive Pump Reverse Coil Short To Battery |
| D1706 | Drive Pump Reverse Coil Short To Ground |
| D1707 | Drive Pump Reverse Coil Open circuit |
| D1732 | Drive Pump Reverse Coil Overcurrent |
| D1802 | Stabilisers / Aux diverter output valve error ON |
| D1803 | Stabilisers / Aux diverter output valve error OFF |
| D1807 | Stabilisers / Aux diverter output open circuit |
| D1825 | Stabilisers / Aux diverter output Unresponsive |
| D1902 | Stabilisers / Aux diverter relay feedback error ON |
| D1903 | Stabilisers / Aux diverter relay feedback error OFF |
| D2002 | Low speed output (hydraulic motor) Error On |
| D2003 | Low speed output (hydraulic motor) Error Off |
| D2007 | Low speed output (hydraulic motor) Open circuit |
| D2033 | Low speed output (hydraulic motor) Controller Internal failure |
| D2102 | Low speed Relay Error On |
| D2103 | Low speed Relay Error Off |
| D2202 | Defeat valve output (hydraulic motor) Error On |
| D2203 | Defeat valve output (hydraulic motor) Error Off |
| D2207 | Defeat valve output (hydraulic motor) Open circuit |
| D2233 | Defeat valve output Controller Internal failure |
| D2302 | Defeat valve relay Error On |
| D2303 | Defeat valve relay Error Off |
| D2502 | Left stabilizer on the floor Error ON |
| D2503 | Left stabilizer on the floor Error OFF |
| D2609 | Hydraulic Steering Pressure Low |
| D2621 | Hydraulic Steering Pressure Out of Range High |
| D2702 | Right stabilizer on the floor Error ON |
| D2703 | Right stabilizer on the floor Error OFF |
| D2821 | Left stabilizer Pressure Sensor Out Of Range High |
| D2822 | Left stabilizer Pressure Sensor Out Of Range Low |
| D2921 | Right stabilizer Pressure Sensor Out Of Range High |
| D2922 | Right stabilizer Pressure Sensor Out Of Range Low |
| D3005 | Stabilizers Right Output Short To Battery |
| D3006 | Stabilizers Right Output Short To Ground |
| D3007 | Stabilizers Right Output Open circuit |
| D3024 | Stabilizers Right Output Not In Neutral |
| D3105 | Stabilizers Left Output Short To Battery |
| D3106 | Stabilizers Left Output Short To Ground |
| D3107 | Stabilizers Left Output Open circuit |
| D3124 | Stabilizers Left Output Not In Neutral |
| D3204 | Workgroup controller No Communication |
| D3304 | Gateway controller No Communication |
| D3404 | Display controller No Communication |
| D3604 | Engine controller No Communication |
| D3723 | Programming or constant data invalid |
| D3728 | Drive Controller failure |
| D3796 | Interrupted power |
| D3797 | Drive Controller programmed |
| D4004 | Joystick No communication |
| D4011 | Joystick Right roller Out Of Neutral (Auxiliary) |
| D4028 | Joystick Grip Fault |
| D4113 | FNR lever no Signal |
| D4128 | FNR multiple inputs active |
| D4402 | Power Quicktach output Error On |
| D4403 | Power Quicktach output Error Off |
| D4407 | Power Quicktach Output Open circuit |
| D4502 | Power Quicktach Relay feedback Error On |
| D4503 | Power Quicktach Relay feedback Error Off |
| D4528 | Power Quicktach Switch in error |
| D4621 | Voltage Sensor 5V OOR High |
| D4622 | Voltage Sensor 5V OOR Low |
| D4705 | Frame leveling Output Short To Battery |
| D4706 | Frame leveling Output Short To Ground |
| D4707 | Frame leveling Output Open circuit |
| D4724 | Frame leveling Output Not In Neutral |
| D4802 | Park Brake Reserve Pressure Valve Output Error On |
| D4803 | Park Brake Reserve Pressure Valve Output Error Off |
| D4807 | Park Brake Reserve Pressure Valve Output Open Circuit |
| D4902 | Park Brake Reserve Pressure Valve Relay Feedback Error On |
| D4903 | Park Brake Reserve Pressure Valve Relay Feedback Error Off |
| D5005 | Rear Aux./Hook UP Valve Short to Battery |
| D5006 | Rear Aux./Hook UP Valve Short to Ground |
| D5007 | Rear Aux./Hook UP Valve Open Circuit |
| D5105 | Rear Aux./Hook DOWN Valve Short to Battery |
| D5106 | Rear Aux./Hook DOWN Valve Short to Ground |
| D5107 | Rear Aux./Hook DOWN Valve Open Circuit |
| D5205 | Rear Aux./Hook ACTIVATION Valve Short to Battery |
| D5206 | Rear Aux./Hook ACTIVATION Valve Short to Ground |
| D5207 | Rear Aux./Hook ACTIVATION Valve Open Circuit |
| D5232 | Rear Aux./Hook ACTIVATION Valve Overcurrent |
| D5328 | Rear Aux./Hook Dashbord Switch In Error |
| D5421 | Auxiliary spool sensor Out Of Range high |
| D5422 | Auxiliary spool sensor Out Of Range low |
| D5424 | Auxiliary spool sensor not in neutral |
| D5425 | Auxiliary spool sensor unresponsive |
| D5521 | SwashPlate Sensor1 OORH |
| D5522 | SwashPlate Sensor1 OORL |
| D5621 | Swash Plate Sensor2 OORH |
| D5622 | Swash Plate Sensor2 OORL |
| D5715 | Swash Plate shutdown |
| D5744 | Swash Plate dual fault |
| D5745 | Swash Plate disagree |
| D5746 | Swash plate unresponsive |
| D5786 | Swash plate Safe Stop failure |
| D5815 | Safe Start Shutdown |
| D5824 | Safe Start Swash Out Of Neutral |
| D5835 | Safe Start Dump valve stuck on |
| D5911 | Overspeed fault |
| D5915 | Overspeed shutdown |
| D5928 | Overspeed failure |
| D5986 | Overspeed failure |
| D6021 | Servo Pressure Out of Range High |
| D6022 | Servo Pressure Out of Range Low |
| D6202 | Creep Light Error On |
| D6203 | Creep Light Error Off |
| D6302 | Creep Switch Error On |
| D6505 | Gear 1 (Gearbox) Short To Battery |
| D6506 | Gear 1 (Gearbox) Short To Ground |
| D6507 | Gear 1 (Gearbox) Open Circuit |
| D6605 | Gear 2 (Gearbox) Short To Battery |
| D6606 | Gear 2 (Gearbox) Short To Ground |
| D6607 | Gear 2 (Gearbox) Open Circuit |
| D6702 | Gearshift sensor Error On |
| D6760 | Gearshift sensor - Shift didn't start / no shift |
| D6761 | Gearshift sensor - Shift too long / locked |
| D6824 | Frame leveling switch Not in Neutral |
| D6902 | Gear switch 1/2 Error On (dashboard) |
| D7002 | High/Low speed switch Error on (left lever) |
| D7102 | Backup alarm Output Error On |
| D7103 | Backup alarm Output Error Off |
| D7107 | Backup alarm Output Open Cirduit |
| D7133 | Backup alarm Output Internal Failure |
| D7202 | Backup alarm Relay Feedback Error On |
| D7203 | Backup alarm Relay Feedback Error Off |
| D7209 | Service Brake Pressure Low |
| D7210 | Service Brake Pressure High |
| D7214 | Service Brake Pressure Extremley Low |
| D7221 | Service Brake Pressure Out of Range High |
| D7222 | Service Brake Pressure Out of Range Low |
| D7309 | Service Brake Reserve Pressure Low |
| D7310 | Service Brake Reserve Pressure High |
| D7321 | Service Brake Reserve Pressure Out of Range High |
| D7322 | Service Brake Reserve Pressure Out of Range Low |
| D7509 | Park Brake Reserve Pressure Low |
| D7605 | Aux Female Output Short To Battery |
| D7606 | Aux Female Output Short To Ground |
| D7607 | Aux Female Output Open Circuit |
| D7632 | Aux Female Output Overcurrent |
| D7705 | Aux Male Output Short To Battery |
| D7706 | Aux Male Output Short To Ground |
| D7707 | Aux Male Output Open Circuit |
| D7732 | Aux Male Output Overcurrent |
| D7802 | DEF Tank Elec fan relay Error ON |
| D7803 | SCR Elec fan relay error OFF |
| D7902 | ACD Switches Error On |
| D8002 | Dump valve Short To Battery |
| D8003 | Dump valve Short To Ground |
| D8007 | Dump valve Open circuit |
| D8032 | Dump valve Overcurrent |
| D8110 | LS Pump Pressure High |
| D8121 | LS Pump Pressure Out of Range High |
| D8122 | LS Pump Pressure Out of Range Low |
| D8202 | Boom Suspension Valve Error On |
| D8203 | Boom Suspension Valve Error Off |
| D8207 | Boom Suspension Open Circuit |
| D8232 | Boom Suspension Overcurrent |
| D8302 | Stabilizers ON/OFF output valve Error On |
| D8303 | Stabilizers ON/OFF output valve Error Off |
| D8307 | Stabilizers ON/OFF output Open circuit |
| D8402 | Stabilizers ON/OFF Relay feedback Error On |
| D8403 | Stabilizers ON/OFF Relay feedback Error Off |
| D8505 | Stabilizers Left Up Output Short To Battery |
| D8506 | Stabilizers Left Up Output Short To Ground |
| D8507 | Stabilizers Left Up Output Open circuit |
| D8605 | Stabilizers Left Down Output Short To Battery |
| D8606 | Stabilizers Left Down Output Short To Ground |
| D8607 | Stabilizers Left Down Output Open circuit |
| D8705 | Stabilizers Right Up Output Short To Battery |
| D8706 | Stabilizers Right Up Output Short To Ground |
| D8707 | Stabilizers Right Up Output Open circuit |
| D8805 | Stabilizers Right Down Output Short To Battery |
| D8806 | Stabilizers Right Down Output Short To Ground |
| D8807 | Stabilizers Right Down Output Open circuit |
| D8902 | Stabilizers Active Switch Error On |
| D9098 | Drive Controller Calibration Performed |
| D9099 | Drive Calibration Required |
| D9199 | Swash Plate Neutral range calibration required (drive pump) - See procedure |
| D9299 | Swash Plate maximal range calibration required (drive pump) - See procedure |
| D9302 | Trailer Brake Supplementary Line Output Error On |
| D9303 | Trailer Brake Supplementary Line Output Error Off |
| D9307 | Trailer Brake Supplementary Line Output Open Circuit |
| D9333 | Trailer Brake Supplementary Line Output Internal failure |
| D9402 | Trailer Brake Supplementary Line Relay Error On |
| D9403 | Trailer Brake Supplementary Line Relay Error Off |
| D9509 | Trailer Brake Reserve Pressure Low |
| D9605 | Redundancy Park Brake Output Short To Battery |
| D9606 | Redundancy Park Brake Output Short To Ground |
| D9607 | Redundancy Park Brake Output Open Cuircuit |
| D9999 | Bad constant Data Table |
| H0321 | Battery Voltage OOR High |
| H0322 | Battery Voltage OOR Low |
| H1005 | Rear diverter 1 output Short To Battery |
| H1006 | Rear diverter 1 output Short To Ground |
| H1007 | Rear diverter 1 output Open Circuit |
| H1102 | Rear diverter 2 output Error On |
| H1103 | Rear diverter 2 output Error Off |
| H1107 | Rear diverter 2 output Open Circuit |
| H1202 | Rear diverter 2 output Relay Feedback Error On |
| H1203 | Rear diverter 2 output Relay Feedback Error Off |
| H1302 | Front / Rear diverter sensor Error On |
| H1303 | Front / Rear diverter sensor Error Off |
| H2005 | Rear Aux./Hook UP Valve Short to Battery |
| H2006 | Rear Aux./Hook UP Valve Short to Ground |
| H2007 | Rear Aux./Hook UP Valve Open Circuit |
| H2105 | Rear Aux./Hook DOWN Valve Short to Battery |
| H2106 | Rear Aux./Hook DOWN Valve Short to Ground |
| H2107 | Rear Aux./Hook DOWN Valve Open Circuit |
| H2205 | Rear Aux./Hook ACTIVATION Valve Short to Battery |
| H2206 | Rear Aux./Hook ACTIVATION Valve Short to Ground |
| H2207 | Rear Aux./Hook ACTIVATION Valve Open Circuit |
| H2232 | Rear Aux./Hook ACTIVATION Valve Overcurrent |
| H2328 | Rear Aux./Hook Dashbord Switch In Error |
| H3204 | Workgroup controller No communication |
| H3304 | Gateway controller No communication |
| H3404 | Display controller No communication |
| H3523 | Programming or constant data invalid |
| H3528 | Controller failure |
| H3596 | Interrupted power |
| H3597 | Controller programmed |
| H3604 | Engine controller No communication |
| H3704 | Drive controller No communication |
| H4004 | Joystick No communication |
| H4621 | Vsensor 5V supply OOR High |
| H4622 | Vsensor 5V supply OOR Low |
| H7002 | Boom Drain Output Error ON |
| H7003 | Boom Drain Output Error OFF |
| H7007 | Boom Drain Output Error Open Circuit |
| H7033 | Boom Drain Output Internal Failure |
| H7102 | Boom Drain Relay Feedback Output Error ON |
| H7103 | Boom Drain Relay Feedback Output Error OFF |
| H7205 | Boom Suspension Output Short To Battery |
| H7206 | Boom Suspension Output Short To Ground |
| H7207 | Boom Suspension Open Circuit |
| H7232 | Boom Suspension Overcurrent |
| H7233 | Boom Suspension Output Internal Failure |
| H7428 | Boom Suspension Error |
| H7528 | Boom Suspension switch On |
| H7602 | Boom Suspension Icon Error ON |
| H7603 | Boom Suspension Icon Error OFF |
| H7705 | Boom Float Output Short To Battery |
| H7706 | Boom Float Output Short To Ground |
| H7707 | Boom Float Open Circuit |
| H7732 | Boom Float Overcurrent |
| H8110 | LS Pump Inlet Pressure High |
| H8121 | LS Pump Inlet Pressure Out Of Range High |
| H8122 | LS Pump Inlet Pressure Out Of Range Low |
| H8209 | LS Pump Outlet Pressure Low |
| H8221 | LS Pump Outlet Pressure Out Of Range High |
| H8222 | LS Pump Outlet Pressure Out Of Range Low |
| H8305 | LS Pump Displacement Control Valve Short To Battery |
| H8306 | LS Pump Displacement Control Valve Short To Ground |
| H8307 | LS Pump Displacement Control Open Circuit |
| H8332 | LS Pump Displacement Control Overcurrent |
| H9999 | Auxiliary controller Bad Table |
| I0314 | LLMI Undervoltage |
| I0315 | LLMI Overvoltage |
| I3014 | LLMI Sensor Offset |
| I3015 | LLMI Sensor Out of Range |
| I3016 | LLMI Sensor Default |
| I3017 | LLMI Sensor ID Error |
| I3018 | LLMI Sensor Rx Out of Delay |
| I3113 | LLMI Calibration Values Out of Range |
| I3121 | LLMI Calibration Values Inverted |
| I3122 | LLMI Calibration Values Too Close |
| I3123 | LLMI Calibration Timeout |
| I3901 | LLMI EEPROM Failure |
| I3903 | LLMI External Watchdog Default |
| I3904 | LLMI Wrong RAM Test |
| I3905 | LLMI Wrong Program Checksum |
| I3909 | LLMI Test Button Error |
| K1005 | Position Lights Output Short To Battery |
| K1006 | Position Lights Output Short To Ground |
| K1007 | Position Lights Output Open Circuit |
| K1102 | Position Lights Status Error ON |
| K1103 | Position Lights Status Error OFF |
| K1205 | Low Beam Output Short To Battery |
| K1206 | Low Beam Output Short To Ground |
| K1207 | Low Beam Output Open Circuit |
| K1305 | High Beam Output Short To Battery |
| K1306 | High Beam Output Short To Ground |
| K1307 | High Beam Output Open Circuit |
| K1402 | Fog Light Output Error ON |
| K1403 | Fog Light Output Error OFF |
| K1505 | Left Turn Signal Output Short To Battery |
| K1506 | Left Turn Signal Output Short To Ground |
| K1507 | Left Turn Signal Output Open Circuit |
| K1602 | Left Turn Signal Status Error ON |
| K1603 | Left Turn Signal Status Error OFF |
| K1705 | Right Turn Signal Output Short To Battery |
| K1706 | Right Turn Signal Output Short To Ground |
| K1707 | Right Turn Signal Output Open Circuit |
| K1802 | Right Turn Signal Status Error ON |
| K1803 | Right Turn Signal Status Error OFF |
| K2002 | Front Wiper Output Error ON |
| K2003 | Front Wiper Output Error OFF |
| K2102 | Front Wiper (High Speed) Output Error ON |
| K2103 | Front Wiper (High Speed) Output Error OFF |
| K2202 | Front/Roof Washer Output Error ON |
| K2203 | Front/Roof Washer Output Error OFF |
| K2305 | Roof Wiper Output Short To Battery |
| K2306 | Roof Wiper Output Short To Ground |
| K2307 | Roof Wiper Output Open Circuit |
| K2405 | Rear Wiper Output Short To Battery |
| K2406 | Rear Wiper Output Short To Ground |
| K2407 | Rear Wiper Output Open Circuit |
| K2502 | Rear Washer Output Error ON |
| K2503 | Rear Washer Output Error OFF |
| K2605 | Lateral Wiper Output Short To Battery |
| K2606 | Lateral Wiper Output Short To Ground |
| K2607 | Rear Wiper Output Open Circuit |
| K2702 | Lateral Washer Output Error ON |
| K2703 | Lateral Washer Output Error OFF |
| K4204 | Left Steering Lever No Communication |
| K4304 | Right Steering Lever No Communication |
| K4404 | Steering Lever No Communication |
| M0116 | Air Filter Switch Not Connected |
| M0144 | Air Filter De-rate Level 1 |
| M0145 | Air Filter De-rate Level 2 |
| M0309 | Battery voltage Low |
| M0310 | Battery voltage High |
| M0311 | Battery voltage Extremely High |
| M0314 | Battery voltage Extremely Low |
| M0322 | Battery voltage Out Of Range Low |
| M0610 | Engine speed High |
| M0710 | Hydraulic Oil Temperature High |
| M0810 | Engine Coolant Temperature High |
| M0821 | Engine Coolant Temperature OOR High |
| M0822 | Engine Coolant Temperature OOR Low |
| M0909 | Fuel Level Low |
| M0921 | Fuel Level OOR High |
| M0922 | Fuel Level OOR Low |
| M1009 | Fuel Filter Pressure Low |
| M1014 | Fuel Filter Pressure Extremely Low |
| M1021 | Fuel Filter Pressure OOR High |
| M1022 | Fuel Filter Pressure OOR Low |
| M1117 | Fuel Filter Plugged |
| M1119 | Fuel Filter Extremely Plugged |
| M1144 | Fuel Filter De-rate Level 1 |
| M1145 | Fuel Filter De-rate Level 2 |
| M1302 | Fuel Pump Output Error ON |
| M1303 | Fuel Pump Output Error OFF |
| M1402 | Fuel Solenoid Output Error ON |
| M1403 | Fuel Solenoid Output Error OFF |
| M1428 | Fuel Solenoid Output Internal failure |
| M1502 | Fuel Solenoid Relay Error ON |
| M1503 | Fuel Solenoid Relay Error OFF |
| M1602 | Front Alignement Lamp Output Error ON |
| M1603 | Front Alignement Lamp Output Error OFF |
| M1702 | Rear Alignement Lamp Output Error ON |
| M1703 | Rear Alignement Lamp Output Error OFF |
| M1821 | Frame Leveling pot Out of range high |
| M1822 | Frame Leveling pot Out of range low |
| M2102 | Glow Plug Output Error ON |
| M2103 | Glow Plug Output Error OFF |
| M2202 | Starter Output Error ON |
| M2203 | Starter Output Error OFF |
| M2207 | Starter Output Open circuit |
| M2302 | Starter Relay Error ON |
| M2303 | Starter Relay Error OFF |
| M2405 | Crab valve Output Short To Battery |
| M2406 | Crab valve Output Short To Ground |
| M2407 | Crab valve Output Open Circuit |
| M2505 | 4 Wheels valve Short To Battery |
| M2506 | 4 Wheels valve Short To Ground |
| M2507 | 4 Wheels valve Open circuit |
| M2648 | Steer Mode Switch Multiple inputs active |
| M2702 | Fan Inverter Output Error On |
| M2703 | Fan Inverter Output Error OFF |
| M2707 | Fan Inverter Output Open Circuit |
| M2805 | Fan PWM Output Short To Battery |
| M2806 | Fan PWM Output Short To Ground |
| M2807 | Fan PWM Ouptut Open Circuit |
| M2832 | Fan PWM Output Overcurrent |
| M2910 | Engine Exhaust gas Temperature High |
| M3204 | Workgroup Controller no communication |
| M3404 | Display controller no communication |
| M3504 | DCU Controller no communication |
| M3604 | Engine Controller no communication |
| M3704 | Drive Controller no communication |
| M3905 | Cab Buzzer Short To Battery |
| M4028 | Wrong mapping of ECU controller detected : Engine HP mismatch |
| M4109 | Alternator voltage low |
| M4110 | Alternator voltage high |
| M4228 | Wrong mapping of DCU controller mapping detected : Horse Power mismatch |
| M4304 | Keypad KSS no communication |
| M4405 | Brake Fail Electric Lamp Short To Battery |
| M4505 | Brake Fail Pressure Lamp Short To Battery |
| M4721 | Sensor Supply OORH |
| M4722 | Sensor Supply OORL |
| M4805 | Worklights output Error On |
| M4806 | Worklights output Error Off |
| M4902 | Blue lights Output Short To Battery or Open Circuit |
| M4903 | Blue lights Output Short To Ground |
| M5005 | Front Worklights Output Short to Battery |
| M5006 | Front Worklights Output Short to Ground |
| M5007 | Front Worklights Output Open Circuit |
| M5102 | Rear Worklights Short To Battery or Open Circuit |
| M5103 | Rear Worklights Output Short To Ground |
| M5205 | Electronic Battery Disconnect Output Open circuit or Short To Battery |
| M5206 | Electronic Battery Disconnect Output Short To Ground |
| M5207 | Electronic Battery Disconnect Output Open circuit |
| M5302 | Electronic Battery Disconnect stucked |
| M5303 | Electronic Battery Disconnect open error (unstucked) |
| M5815 | Fuel Temperature in shutdown |
| M6004 | Cab Controller No Communication |
| M6105 | Safety Valve Short To Battery |
| M6106 | Safety Valve Short To Ground |
| M6107 | Safety Valve Open Circuit |
| M6132 | Safety Valve Overcurrent |
| M7748 | Multiple key on active (service tool & keyswitch) |
| M8021 | Throttle pedal analog signal Out Of Range High |
| M8022 | Throttle pedal analog signal Out Of Range Low |
| M8028 | Throttle pedal in error. (redundancy error) |
| M8128 | Wrong DEF Sensor detected |
| M8228 | Inhibit DESOX/REGEN switch in failure |
| M8328 | Force DESOX/REGEN Switch in failure |
| M8450 | DESOX/REGEN requested but inhibited |
| M8602 | Receiver input Error On |
| M8703 | Attachment run input Error off |
| M8848 | Selection mode switch Multiple |
| M8928 | ECO Mode switch In error |
| M9604 | Single Keypad No Communication |
| M9704 | Primary Keypad No Communication |
| M9804 | Secondary Keypad No Communication |
| M9999 | Bad Constant Data table |
| W0321 | Battery Voltage OOR High |
| W0322 | Battery Voltage OOR Low |
| W0721 | Hydraulic Oil Temperature OOR High |
| W0722 | Hydraulic Oil Temperature OOR Low |
| W1005 | PVG32 Lift Up/Down valve Short to Battery |
| W1006 | PVG32 Lift Up/Down Valve Short to Ground |
| W1007 | PVG32 Lift Up/Down Valve Open circuit |
| W1028 | PVG32 Lift Up/Down Valve in error. From mainvalve diagnostic |
| W1105 | PVG32 Tilt Valve Short to Battery |
| W1106 | PVG32 Tilt Valve Short to Ground |
| W1107 | PVG32 Tilt Valve Open circuit |
| W1128 | PVG32 Tilt Valve in error, From mainvalve diagnostic |
| W1205 | PVG32 Extend/Retract Valve Short to Battery |
| W1206 | PVG32 Extend/Retract Valve Short to Ground |
| W1207 | PVG32 Extend/Retract Valve Open circuit |
| W1228 | PVG32 Extend/Retract Valve in error From mainvalve diagnostic |
| W1305 | PVG32 Auxiliary Valve Short to Battery |
| W1306 | PVG32 Auxiliary valve Short to Ground |
| W1307 | PVG32 Auxiliary valve Open circuit |
| W1328 | PVG32 Auxiliary Valve in error, From mainvalve diagnostic |
| W1405 | PVG32 Frame Leveling Valve Short to Battery |
| W1406 | PVG32 Frame Leveling Valve Short to Ground |
| W1407 | PVG32 Frame Leveling Valve Open circuit |
| W1428 | PVG32 Frame Leveling Valve in error From mainvalve diagnostic |
| W1824 | Frame Leveling potentiometer Out of neutral |
| W2205 | Lift Up Output Short To Battery |
| W2206 | Lift Up Output Short To Ground |
| W2207 | Lift Up Output Open Circuit |
| W2232 | Lift Up Output Overcurrent |
| W2299 | Lift Up Solenoid Calibration Required |
| W2299 | Lift Up Coil Calibration required |
| W2305 | Lift Down Output Short To Battery |
| W2306 | Lift Down Output Short To Ground |
| W2307 | Lift Down Output Open Circuit |
| W2332 | Lift Down Output Overcurrent |
| W2399 | Lift Down Coil Calibration required |
| W2399 | Lift Down Solenoid Calibration Required |
| W2405 | Tilt Out Output Short To Battery |
| W2406 | Tilt Out Output Short To Ground |
| W2407 | Tilt Out Output Open Circuit |
| W2432 | Tilt Out Output Overcurrent |
| W2505 | Tilt Back Output Short To Battery |
| W2506 | Tilt Back Output Short To Ground |
| W2507 | Tilt Back Output Open Circuit |
| W2532 | Tilt Back Output Overcurrent |
| W2605 | Extend Output Short To Battery |
| W2606 | Extend Output Short To Ground |
| W2607 | Extend Output Open Circuit |
| W2632 | Extend Output Overcurrent |
| W2705 | Retract Output Short To Battery |
| W2706 | Retract Output Short To Ground |
| W2707 | Retract Output Open Circuit |
| W2732 | Retract Output Overcurrent |
| W3223 | Programming or constant data invalid |
| W3228 | Controller failure |
| W3296 | Interrupted power |
| W3297 | Controller programmed |
| W3304 | Gateway controller No communication |
| W3404 | Display controller No communication |
| W3604 | Engine controller No communication |
| W3704 | Drive controller No communication |
| W3804 | LLMC No communication |
| W3818 | LLMC Out of Range |
| W3844 | LLMC Not matching |
| W3845 | LLMC Not matching level 2 |
| W3904 | LLMI No communication |
| W3918 | LLMI Out of Range |
| W4004 | Joystick No communication |
| W4005 | Joystick X Axis Out Of Neutral (Tilt) |
| W4007 | Joystick Y Axis Out Of Neutral (Lift) |
| W4010 | Joystick Left roller Out Of Neutral (Extend Retract) |
| W4028 | Joystick Grip Fault |
| W4204 | Receiver No Communication |
| W4205 | Remote Left Joystick X Axis OON |
| W4206 | Remote Right Joystick X Axis OON |
| W4207 | Remote Left Joystick Y Axis OON |
| W4208 | Remote Right Joystick Y Axis OON |
| W4215 | Remote Left Joystick X axis in error |
| W4216 | Remote Right Joystick X axis in error |
| W4217 | Remote Left Joystick Y axis in error |
| W4218 | Remote Right Joystick Y axis in error |
| W4320 | Manbasket mode : Remote control not connected to Manbasket harness (from Receiver CAN Bus signal) |
| W4321 | Manbasket mode : Remote control not connected to Manbasket harness (from GACD controller status) |
| W4325 | Manbasket mode : Manbasket detection in error |
| W4326 | Manbasket mode : Manbasket not detected on carriage |
| W4327 | Manbasket mode : Manbasket not detected on carriage with GACD on or Remote control active |
| W4330 | Manbasket mode : Manbasket Retract switch in error |
| W4331 | Manbasket mode : No boom extension when expected (boom retract switch ON) |
| W4335 | Manbasket mode : Stabilizers in error |
| W4336 | Manbasket mode : Stabilizers not on the ground |
| W4340 | Manbasket mode : Boom angle in error |
| W4341 | Manbasket mode : Boom lift movement when not expected |
| W4342 | Manbasket mode : No Boom lift movement when expected |
| W4343 | Manbasket mode : Boom angle limit exceeded |
| W4345 | Manbasket mode : LLM in error |
| W4346 | Manbasket mode : LLM in reduced zone |
| W4347 | Manbasket mode : Longitudinal stability : Max allowed value reached. |
| W4350 | Manbasket mode : Frame Leveling in error |
| W4351 | Manbasket mode : Frame Leveling angle exeeded (out of the range [-2°;+2°]) |
| W4355 | Manbasket mode : Interlocking pin in error |
| W4356 | Manbasket mode : Interlocking pin unlocked |
| W4360 | Manbasket mode : Manbasket Overload in error |
| W4361 | Manbasket mode : Manbasket Overload |
| W4362 | Manbasket mode : Manbasket Overload in error Level 2 |
| W4365 | Manbasket mode : Tilt angle in error |
| W4366 | Manbasket mode : Tilt angle limit exceeded (out of the range [-4° ; +4° ]) |
| W4370 | Manbasket mode : FNR in error |
| W4371 | Manbasket mode : Park brake in error |
| W4372 | Manbasket mode : Swash plate position in error |
| W4404 | Manbasket mode : GACD controller no communication on CAN Bus |
| W4621 | Vsensor 5V supply OOR High |
| W4622 | Vsensor 5V supply OOR Low |
| W4902 | Blue lights Output Short To Battery or Open Circuit |
| W4903 | Blue lights Output Short To Ground |
| W5005 | Rear diverter 1 output Short To Battery |
| W5006 | Rear diverter 1 output Short To Ground |
| W5007 | Rear diverter 1 output Open Circuit |
| W5102 | Rear diverter 2 output Error On |
| W5103 | Rear diverter 2 output Error Off |
| W5107 | Rear diverter 2 output Open Circuit |
| W5202 | Rear diverter 2 output Relay Feedback Error On |
| W5203 | Rear diverter 2 output Relay Feedback Error Off |
| W5302 | Front / Rear diverter sensor Error On |
| W5303 | Front / Rear diverter sensor Error Off |
| W5402 | Boom Worklights Output Short To Battery or Open Circuit |
| W5403 | Boom Worklights Output Short To Ground |
| W5502 | Mirror Worklights Output Short To Battery or Open Circuit |
| W5503 | Mirror Worklights Output Short To Ground |
| W5602 | Mirror Defrost Output Short To Battery or Open Circuit |
| W5603 | Mirror Defrost Output Short To Ground |
| W6021 | Inclinometer sensor input Out of Range High |
| W6022 | Inclinometer sensor input Out of Range Low |
| W6098 | Calibration performed |
| W6099 | Inclinometer Calibration required |
| W6102 | Inclinometer lamp error on |
| W6103 | Inclinometer lamp error off |
| W6521 | Boom Angle 1 OOR High |
| W6522 | Boom Angle 1 OOR Low |
| W6621 | Boom Angle 2 OOR High |
| W6622 | Boom Angle 2 OOR Low |
| W6744 | Boom Angle in error |
| W6798 | Boom Angle Calibration Performed |
| W6799 | Boom Angle Calibration Required |
| W6802 | Boom retract Switch Short to Battery |
| W6803 | Boom retract Switch Short to Ground or open circuit |
| W6902 | Boom retract Switch 2 Short to Battery |
| W6903 | Boom retract Switch 2 Short to Ground or open circuit |
| W6928 | Boom retract Switch 2 In Error |
| W7002 | Boom Drain Output Error ON |
| W7003 | Boom Drain Output Error OFF |
| W7007 | Boom Drain Output Error Open Circuit |
| W7033 | Boom Drain Output Internal Failure |
| W7102 | Boom Drain Relay Feedback Output Error ON |
| W7103 | Boom Drain Relay Feedback Output Error OFF |
| W7428 | Boom Suspension Error |
| W7528 | Boom Suspension/Float switch On |
| W7602 | Boom Suspension Icon Error ON |
| W7603 | Boom Suspension Icon Error OFF |
| W7705 | Boom Float Output Short To Battery |
| W7706 | Boom Float Output Short To Ground |
| W7707 | Boom Float Output Open circuit |
| W8002 | Power Quicktach output Error On |
| W8003 | Power Quicktach output Error Off |
| W8005 | Power Quicktach Output Short To Battery |
| W8006 | Power Quicktach Output Short To Ground |
| W8007 | Power Quicktach Output Open circuit |
| W8128 | Power Quicktach Switch in error |
| W8202 | Power Quicktach Relay feedback Error On |
| W8203 | Power Quicktach Relay feedback Error Off |
| W8302 | Electromagnet Output Error On |
| W8303 | Electromagnet Output Error Off |
| W8307 | Electromagnet Output Open circuit |
| W8402 | Electromagnet Relay feedback Error On |
| W8403 | Electromagnet Relay feedback Error Off |
| W8502 | Manplatform detection switch Short To Battery |
| W8503 | Manplatform detection switch Short To Ground or Open circuit |
| W8611 | Winch Overloaded |
| W8628 | Winch Inputs In Error |
| W8702 | Power Quicktach Boom Output Error On |
| W8703 | Power Quicktach Boom Output Error Off |
| W8707 | Power Quicktach Boom Output Open circuit |
| W8802 | Power Quicktach Boom Relay feedback Error On |
| W8803 | Power Quicktach Boom Relay feedback Error Off |
| W8902 | Power Lift Output Error ON |
| W8903 | Power Lift Output Error OFF |
| W8907 | Power Lift Output Error Open Circuit |
| W9002 | Power Lift Relay Error ON |
| W9003 | Power Lift Relay Error OFF |
| W9999 | Workgroup controller Bad Table |
Toolcat 253
| Fault Code | Description |
|---|---|
| B1001-96 | Key Switch - Component Internal Failure |
| B102A-16 | Cab Controller Sensor Supply - Circuit Voltage Below Threshold |
| B102A-17 | Cab Controller Sensor Supply - Circuit Voltage Above Threshold |
| B1034-11 | Rear Work Lights - Circuit Short to Ground |
| B1034-12 | Rear Work Lights - Circuit Short to Battery |
| B1034-13 | Rear Work Lights - Circuit Open |
| B1036-11 | Rear Marker Lights - Circuit Short to Ground |
| B1036-12 | Rear Marker Lights - Circuit Short to Battery |
| B1036-13 | Rear Marker Lights - Circuit Open |
| B1037-11 | Stop Lights - Circuit Short to Ground |
| B1037-12 | Stop Lights - Circuit Short to Battery |
| B1037-13 | Stop Lights - Circuit Open |
| B103D-12 | Beacon Light - Circuit Short to Battery |
| B103D-14 | Beacon Light - Circuit Short to Ground or Open |
| B1040-12 | Buzzer - Circuit Short to Battery |
| B1040-14 | Buzzer - Circuit Short to Ground or Open |
| B1041-12 | Backup Alarm - Circuit Short to Battery |
| B1041-14 | Backup Alarm - Circuit Short to Ground or Open |
| B1042-12 | Horn Output - Circuit Short to Battery |
| B1042-14 | Horn Output - Circuit Short to Ground or Open |
| B1050-12 | HVAC Output - Circuit Short to Battery |
| B1050-14 | HVAC Output - Circuit Short to Ground or Open |
| B105A-12 | Front Window Defroster Output - Circuit Short to Battery |
| B105A-14 | Front Window Defroster Output - Circuit Short to Ground or Open |
| B1080-09 | Operator Presence - Component Failure |
| B1080-16 | Operator Presence - Circuit Voltage Below Threshold |
| B1080-17 | Operator Presence - Circuit Voltage Above Threshold |
| B10A0-12 | Wiper Output - Circuit Short to Battery |
| B10A0-14 | Wiper Output - Circuit Short to Ground or Open |
| B10A1-12 | Washer Fluid Output - Circuit Short to Battery |
| B10A1-14 | Washer Fluid Output - Circuit Short to Ground or Open |
| B10C1-00 | Camera Software Error |
| B10D0-11 | Display Switched Power Output - Circuit Short to Ground |
| B10D0-12 | Display Switched Power Output - Circuit Short to Battery |
| B10D0-13 | Display Switched Power Output - Circuit Open |
| B1110-F0 | Left Primary - Not in Neutral |
| B1111-F0 | Left Secondary - Not in Neutral |
| B1120-F0 | Right Primary - Not in Neutral |
| B1121-F0 | Right Secondary - Not in Neutral |
| B1122-F0 | Detent - Not in Neutral |
| B1130-F0 | Joystick Primary - Not in Neutral |
| B1131-F0 | Joystick Secondary - Not in Neutral |
| B1155-31 | FPR Switch - No Signal |
| B1156-00 | FPR Switch Multiple |
| B1170-11 | Head Light High Left - Circuit Short to Ground |
| B1170-12 | Head Light High Left - Circuit Short to Battery |
| B1170-13 | Head Light High Left - Circuit Open |
| B1172-11 | Front Turn Signal Left - Circuit Short to Ground |
| B1172-12 | Front Turn Signal Left - Circuit Short to Battery |
| B1172-13 | Front Turn Signal Left - Circuit Open |
| B1175-11 | Rear Turn Signal Left - Circuit Short to Ground |
| B1175-12 | Rear Turn Signal Left - Circuit Short to Battery |
| B1175-13 | Rear Turn Signal Left - Circuit Open |
| B1180-11 | Head Light High Right - Circuit Short to Ground |
| B1180-12 | Head Light High Right - Circuit Short to Battery |
| B1180-13 | Head Light High Right - Circuit Open |
| B1182-11 | Front Turn Signal Right - Circuit Short to Ground |
| B1182-12 | Front Turn Signal Right - Circuit Short to Battery |
| B1182-13 | Front Turn Signal Right - Circuit Open |
| B1185-11 | Rear Turn Signal Right - Circuit Short to Ground |
| B1185-12 | Rear Turn Signal Right - Circuit Short to Battery |
| B1185-13 | Rear Turn Signal Right - Circuit Open |
| B1190-11 | Front Work Lights - Circuit Short to Ground |
| B1190-12 | Front Work Lights - Circuit Short to Battery |
| B1190-13 | Front Work Lights - Circuit Open |
| B1191-12 | Front Work Light 2 - Circuit Short to Battery |
| B1191-14 | Front Work Light 2 - Circuit Short to Ground or Open |
| B1192-12 | Front Work Light 3 - Circuit Short to Battery |
| B1192-14 | Front Work Light 3 - Circuit Short to Ground or Open |
| B11B0-54 | Travel Pedal Sensor - Missing Calibration |
| B11B0-93 | Travel Pedal Sensor - In Error |
| B11B1-16 | Travel Pedal Sensor Primary - Circuit Voltage Below Threshold |
| B11B1-17 | Travel Pedal Sensor Primary - Circuit Voltage Above Threshold |
| B11B2-16 | Travel Pedal Sensor Secondary - Circuit Voltage Below Threshold |
| B11B2-17 | Travel Pedal Sensor Secondary - Circuit Voltage Above Threshold |
| B11B5-54 | Brake Pedal Sensor - Missing Calibration |
| B11B5-93 | Brake Pedal Sensor - In Error |
| B11B6-16 | Brake Pedal Sensor Primary - Circuit Voltage Below Threshold |
| B11B6-17 | Brake Pedal Sensor Primary - Circuit Voltage Above Threshold |
| B11B7-16 | Brake Pedal Sensor Secondary - Circuit Voltage Below Threshold |
| B11B7-17 | Brake Pedal Sensor Secondary - Circuit Voltage Above Threshold |
| C1001-16 | Hub Controller Sensor Supply - Circuit Voltage Below Threshold |
| C1001-17 | Hub Controller Sensor Supply - Circuit Voltage Above Threshold |
| C1005-16 | Pump Controller Sensor Supply - Circuit Voltage Below Threshold |
| C1005-17 | Pump Controller Sensor Supply - Circuit Voltage Above Threshold |
| C1006-16 | Rear Controller Sensor Supply - Circuit Voltage Below Threshold |
| C1006-17 | Rear Controller Sensor Supply - Circuit Voltage Above Threshold |
| C100A-11 | ECU Power - Circuit Short to Ground |
| C100A-12 | ECU Power - Circuit Short to Battery |
| C100A-13 | ECU Power - Circuit Open |
| C1020-11 | Front Aux Base Solenoid - Circuit Short to Ground |
| C1020-12 | Front Aux Base Solenoid - Circuit Short to Battery |
| C1020-13 | Front Aux Base Solenoid - Circuit Open |
| C1020-19 | Front Aux Base Solenoid - Circuit Current Above Threshold |
| C1021-11 | Front Aux Rod Solenoid - Circuit Short to Ground |
| C1021-12 | Front Aux Rod Solenoid - Circuit Short to Battery |
| C1021-13 | Front Aux Rod Solenoid - Circuit Open |
| C1021-19 | Front Aux Rod Solenoid - Circuit Current Above Threshold |
| C1024-11 | Diverter Solenoid - Circuit Short to Ground |
| C1024-12 | Diverter Solenoid - Circuit Short to Battery |
| C1024-13 | Diverter Solenoid - Circuit Open |
| C1026-11 | Remote Hydraulics Output - Circuit Short to Ground |
| C1026-12 | Remote Hydraulics Output - Circuit Short to Battery |
| C1026-13 | Remote Hydraulics Output - Circuit Open |
| C102A-11 | Hydraulic Fan Solenoid - Circuit Short to Ground |
| C102A-12 | Hydraulic Fan Solenoid - Circuit Short to Battery |
| C102A-13 | Hydraulic Fan Solenoid - Circuit Open |
| C102A-19 | Hydraulic Fan Solenoid - Circuit Current Above Threshold |
| C1039-11 | High Flow Solenoid - Circuit Short to Ground |
| C1039-12 | High Flow Solenoid - Circuit Short to Battery |
| C1039-13 | High Flow Solenoid - Circuit Open |
| C103C-11 | Bobtach Engage Solenoid - Circuit Short to Ground |
| C103C-12 | Bobtach Engage Solenoid - Circuit Short to Battery |
| C103C-13 | Bobtach Engage Solenoid - Circuit Open |
| C103D-11 | Bobtach Disengage Solenoid - Circuit Short to Ground |
| C103D-12 | Bobtach Disengage Solenoid - Circuit Short to Battery |
| C103D-13 | Bobtach Disengage Solenoid - Circuit Open |
| C1050-12 | Switched Power Output - Circuit Short to Battery |
| C1050-14 | Switched Power Output - Circuit Short to Ground or Open |
| C1051-11 | Two Speed Solenoid - Circuit Short to Ground |
| C1051-12 | Two Speed Solenoid - Circuit Short to Battery |
| C1051-13 | Two Speed Solenoid - Circuit Open |
| C1061-11 | Brake 1 Solenoid - Circuit Short to Ground |
| C1061-12 | Brake 1 Solenoid - Circuit Short to Battery |
| C1061-13 | Brake 1 Solenoid - Circuit Open |
| C1061-19 | Brake 1 Solenoid - Circuit Current Above Threshold |
| C1062-11 | Brake 2 Solenoid - Circuit Short to Ground |
| C1062-12 | Brake 2 Solenoid - Circuit Short to Battery |
| C1062-13 | Brake 2 Solenoid - Circuit Open |
| C1062-19 | Brake 2 Solenoid - Circuit Current Above Threshold |
| C1090-00 | Hydraulic Main Filter Plugged |
| C1091-16 | Hydraulic Main Filter Switch - Circuit Voltage Below Threshold |
| C1091-17 | Hydraulic Main Filter Switch - Circuit Voltage Above Threshold |
| C1091-95 | Hydraulic Main Filter Pressure Switch - Incorrect Assembly |
| C1099-FA | Hydraulic Oil Temperature - High |
| C1099-FB | Hydraulic Oil Temperature - Extremely High |
| C109A-16 | Hydraulic Oil Temperature Sensor - Circuit Voltage Below Threshold |
| C109A-17 | Hydraulic Oil Temperature Sensor - Circuit Voltage Above Threshold |
| C10CA-77 | Swash Plate - Commanded Position Not Reachable |
| C10CA-F0 | Swash Plate - Not in Neutral |
| C10CB-16 | Swash Plate Sensor - Circuit Voltage Below Threshold |
| C10CB-17 | Swash Plate Sensor - Circuit Voltage Above Threshold |
| C10D0-54 | Drive Pump - Missing Calibration |
| C10D1-11 | Drive Pump Forward - Circuit Short to Ground |
| C10D1-12 | Drive Pump Forward - Circuit Short to Battery |
| C10D1-13 | Drive Pump Forward - Circuit Open |
| C10D1-19 | Drive Pump Forward - Circuit Current Above Threshold |
| C10D2-11 | Drive Pump Reverse - Circuit Short to Ground |
| C10D2-12 | Drive Pump Reverse - Circuit Short to Battery |
| C10D2-13 | Drive Pump Reverse - Circuit Open |
| C10D2-19 | Drive Pump Reverse - Circuit Current Above Threshold |
| C1182-A2 | Alternator Voltage System Voltage Low |
| C1182-A3 | Alternator Voltage System Voltage High |
| C1192-00 | Battery Voltage Extremely Low |
| C1193-00 | Battery Voltage Low |
| C1195-00 | Battery Voltage High |
| C1196-00 | Battery Voltage Extremely High |
| C11A0-11 | Servo Enable Solenoid - Circuit Short to Ground |
| C11A0-12 | Servo Enable Solenoid - Circuit Short to Battery |
| C11A0-13 | Servo Enable Solenoid - Circuit Open |
| C11F0-94 | Diverter Switch - Unexpected Operation |
| C1290-17 | PTO Speed Sensor - Circuit Voltage Above Threshold |
| C1291-FA | PTO Speed - High |
| C1291-FB | PTO Speed - Extremely High |
| C1292-FD | PTO - In Shutdown |
| C1293-92 | PTO Switch - Performance or Incorrect Operation |
| C1295-13 | Traction Control Speed Sensor - Circuit Open |
| C1295-16 | Traction Control Speed Sensor - Circuit Voltage Below Threshold |
| C1295-17 | Traction Control Speed Sensor - Circuit Voltage Above Threshold |
| C129A-13 | Main Speed Sensor - Circuit Open |
| C129A-16 | Main Speed Sensor - Circuit Voltage Below Threshold |
| C129A-17 | Main Speed Sensor - Circuit Voltage Above Threshold |
| C12B0-11 | Lift Spool Lock - Circuit Short to Ground |
| C12B0-12 | Lift Spool Lock - Circuit Short to Battery |
| C12B0-13 | Lift Spool Lock - Circuit Open |
| C12B5-11 | Tilt Spool Lock - Circuit Short to Ground |
| C12B5-12 | Tilt Spool Lock - Circuit Short to Battery |
| C12B5-13 | Tilt Spool Lock - Circuit Open |
| C12BA-11 | Box Spool Lock - Circuit Short to Ground |
| C12BA-12 | Box Spool Lock - Circuit Short to Battery |
| C12BA-13 | Box Spool Lock - Circuit Open |
| C1401-11 | AWS Solenoid 1 - Circuit Short to Ground |
| C1401-12 | AWS Solenoid 1 - Circuit Short to Battery |
| C1401-13 | AWS Solenoid 1 - Circuit Open |
| C1402-11 | AWS Solenoid 2 - Circuit Short to Ground |
| C1402-12 | AWS Solenoid 2 - Circuit Short to Battery |
| C1402-13 | AWS Solenoid 2 - Circuit Open |
| C1403-11 | AWS Solenoid 3 - Circuit Short to Ground |
| C1403-12 | AWS Solenoid 3 - Circuit Short to Battery |
| C1403-13 | AWS Solenoid 3 - Circuit Open |
| P0460-16 | Fuel Level Sensor - Circuit Voltage Below Threshold |
| P0460-17 | Fuel Level Sensor - Circuit Voltage Above Threshold |
| P100A-11 | Start Output - Circuit Short to Ground |
| P100A-12 | Starter Output - Circuit Short to Battery |
| P100A-13 | Starter Output - Circuit Open |
| P100B-16 | Starter Feedback - Circuit Voltage Below Threshold |
| P100B-17 | Starter Feedback - Circuit Voltage Above Threshold |
| P1061-97 | Air Filter Pressure - Component or System Operation Obstructed or Blocked |
| P1062-00 | Air Filter Pressure Derate Level 1 |
| P1063-00 | Air Filter Pressure Derate Level 2 |
| P1065-31 | Air Filter Switch - No Signal |
| P1100-FA | Engine Coolant Temperature - High |
| P1100-FB | Engine Coolant Temperature - Extremely High |
| P1121-00 | Fuel Filter Plugged Derate Level 1 |
| P1122-00 | Fuel Filter Plugged Derate Level 2 |
| P1130-F8 | Fuel Filter Inlet Pressure Sensor - Extremely Low |
| P1130-F9 | Fuel Filter Inlet Pressure Sensor - Low |
| P1131-16 | Fuel Filter Inlet Pressure Sensor - Circuit Voltage Below Threshold |
| P1131-17 | Fuel Filter Inlet Pressure Sensor - Circuit Voltage Above Threshold |
| P1134-12 | Fuel Lift Pump - Circuit Short to Battery |
| P1134-14 | Fuel Lift Pump - Circuit Short to Ground or Open |
| P1134-63 | Fuel Lift Pump - Circuit / Component Protection Time-Out |
| P113B-7B | Fuel Level - Low Fluid Level |
| U1015-62 | Throttle Encoder - Signal Compare Failure |
| U101A-08 | Keypad Throttle - Bus Signal / Message Failure |
| U101B-08 | Keypad Lights - Bus Signal / Message Failure |
| U101C-08 | Keypad Performance - Bus Signal / Message Failure |
| U1040-00 | Hour Meter Updated |
| U1050-00 | Hub Controller Interrupted Power Failure |
| U105A-00 | Pump Controller Interrupted Power Failure |
| U105B-00 | Rear Cab Controller Interrupted Power Failure |
| U107A-00 | Pump Controller Software Updated |
| U107B-00 | Rear Controller Software Updated |
| U1090-51 | Hub Controller - Not Programmed |
| U1090-57 | Hub Controller - Invalid / Incompatible Software Component |
| U1091-08 | Display - Bus Signal / Message Failure |
| U1091-51 | Display - Not Programmed |
| U1091-FD | Display - In Shutdown |
| U1092-08 | Cab Controller - Bus Signal / Message Failure |
| U1092-51 | Cab Controller - Not Programmed |
| U1092-57 | Cab Controller - Invalid / Incompatible Software Component |
| U1092-A2 | Cab Controller - System Voltage Low |
| U1092-A3 | Cab Controller - System Voltage High |
| U1096-08 | ECU - Bus Signal / Message Failure |
| U1096-56 | ECU - Invalid / Incompatible Configuration |
| U109A-08 | Pump Controller - Bus Signal / Message Failure |
| U109A-51 | Pump Controller - Not Programmed |
| U109A-57 | Pump Controller - Invalid / Incompatible Software Component |
| U109A-A2 | Pump Controller - System Voltage Low |
| U109A-A3 | Pump Controller - System Voltage High |
| U109B-08 | Rear Controller - Bus Signal / Message Failure |
| U109B-51 | Rear Controller - Not Programmed |
| U109B-57 | Rear Controller - Invalid / Incompatible Software Component |
| U109B-A2 | Rear Controller - System Voltage Low |
| U109B-A3 | Rear Controller - System Voltage High |
| U10D0-08 | Remote Control - No Operation |
| U10D0-57 | Remote Control - Invalid / Incompatible Software Component |
| U10D0-93 | Remote Control - No Operation |
| U1180-00 | Display Controller not receiving CAN from CAN Bus |
| U1181-00 | Display Controller cannot transmit CAN to CAN Bus |
| U1182-00 | Display CAN Error |
| U1183-00 | Display Controller no communication to Main Controller |
| U1184-00 | Display Controller no communication to Jog Shuttle |
